Summer Garden Buildings Hipped Summerhouse 270 Assembly Instructions Manual

Our Help Line provides support and advice to
customers of Summer Garden Buildings after
ordering. For advice before you buy phone us
free 7 days a week on 0800 9777828 or visit
www.summergardenbuildings.co.uk

Before assembly

•
We recommend that time is taken to read the
instructions before starting assembly, then
follow the easy step by step guide.
The instruction sheet is only a guide to
the assembly. Certain items may not be
shown to scale.
•
Check all components prior to assembly
•
This product should be assembled by no
less than 2 people.
•
Never attempt to erect the assembly in
high winds.
•
Drill components where indicated.
•
Some of the components may have sharp
edges wear protective work gloves while
handling components.
No. Components
1 Large floor panel
2 Small floor panel
3 Back and side panel
4 Small back panel
5 Window side panel
6 Right-hand front panel
7 Right-hand doors
8 Left-hand front panel
9 Left-hand doors
10 Door header panel
11 Shiplap door header board
12 Right triangular roof panel
13 Rectangular roof panel
14 Left triangular roof panel
15 Roof centre block
16 Inside roof cover
17 Capping
18 Coverstrips
(1920x48x12mm)
19 Long angled felt batten
(right)
20 Long angle felt batten
(left)
21 Short angle felt batten
(right)
22 Short angle felt batten
(left)
23 Short bargeboard
(835x40x12mm)
24 Long bargeboard
(1325x40x12mm)
25 Door weather strips
(1760x40x12mm)
26 Door beading strips
(1775x9x9mm)
27 Door glazing
(284 x 306mm)
28 Side window glazing
(193 x 304mm)
29 Front window glazing
(200 x 304mm)
30 Beading
(306mm)
31 Beading
(252mm)
32 Beading
(106mm)
33 Large side roof felt
(2.31 x 1m)
34 Small side roof felt
(0.9 x 0.46m)
35 Large front/back roof felt
36 Small front/back roof felt
(1.4 x 0.46m)
37 Acorn finials
Fixing Kit
No.
38 Tower bolts
39 Tower bolt mounting block
40 Door handles
41 Metal handle bar
42 Door lock kit
43 63mm screws
44 50mm screws
45 38mm screws
46 32mm screws
47 25mm screws
48 30mm black countersunk screws
49 25mm brass screws
50 19mm round head screws
51 Washers
52 38mm nails
53 25mm nails
54 10mm felt nails
Hipped Summerhouse 270
Assembly Instructions
x 2
Drill
Gloves
Recommended tools
Qty.
for assembly
2
•
Cross head screw driver
1
•
Hammer
4
•
Sharp knife
1
•
Drill
2
•
3mm diameter drill bit
1
•
8mm diameter drill bit
1
•
12mm diameter drill bit
1
•
Spirit level
1
•
Silicon sealant
2
•
Step ladder
2
4
2
4
1
1
1
8
3
3
1
1
2
6
3
2
12
18
6
72
24
48
2
2
2
(2.9 x 1m)
2
2 8
Qty.
6
3
2
1
1
34
94
12
12
78
8
4
36
4
62
288
200
Caution
This product
contains glass.
Wear protective
work gloves while
handling these
components.
35
37
17
15
16 29
41
40 21
9
26
25
7
6
38 39
33
14
20
30
31
28
32
27
42
22 23
5
2
1
English SS132H
34 36
13
12
19
24
10
11
4
3
18
