10 x 20 SHED 085 ASSEMBLY INSTRUCTIONS
Preparation of base
We recommend that the base onto which your building will stand should be at least 75mm larger
in each direction than the total floor size of the building.
Actual floor area of the building: 2970x3038 mm
Total height clearance: 2168mm
The chosen position in your garden for the siting of the building should be excavated to a depth of
75mm to allow a base of sand, on to which paving slabs can be evenly laid - THEY MUST BE
LEVEL AND FIRM.
Tools required
● Hammer
● Step ladder
● Sand paper
● Battery-powered drill/screwdriver
● 8mm drill
Important Safety Information
PLEASE READ PRIOR TO ASSEMBLY OF THE BUILDING
EVERY PRECAUTION IS TAKEN TO ENSURE THAT YOUR BUILDING HAS NO ELEMENT
INCORRECTLY PLACED OR POSSIBLY HAZARDOUS, HOWEVER PRIOR TO USE PLEASE
CHECK ALL SURFACES FOR THE FOLLOWING:
1. RAISED GRAIN, SPLINTERS: sand down timber to smooth finish
2. NAIL/SCREW/PIN HEADS PROUD: tap home to be flush with surface of timber
3. DAMAGED SCREW HEADS RESULTING IN SHARP SPLINTERS OF METAL: replace
4. SHARP ENDS OF NAILS/ SCREWS/PINS PROTRUDING THROUGH THE PANEL: remove
and reposition.
5. ENSURE ALL PARTS ARE SECURED AGAINST REASONABLE FORCE: remove and refit
6. ENSURE THERE ARE NO LOOSE PARTS: remove and refit/discard
We recommend that protective gloves be worn throughout
Our Help Line provides support and advice to customers of Summer Garden
Buildings after ordering. For advice before you buy you can phone us free 7 days a
week on 0800 9777828 or visit www.summergardenbuildings.co.uk
● Pencil
● Tape measure
● Gloves
● Sharp knife and saw

Advertisement

loading
Need help?

Need help?

Do you have a question about the 085 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Summer Garden Buildings 085

  • Page 1 10 x 20 SHED 085 ASSEMBLY INSTRUCTIONS Preparation of base We recommend that the base onto which your building will stand should be at least 75mm larger in each direction than the total floor size of the building. Actual floor area of the building: 2970x3038 mm...
  • Page 2: Parts List

    Parts List QTY DESCRIPTION QTY DESCRIPTION 24 Glazing 355x355mm 6 Casement stays 96 Beading 357mm 12 Casement stay pins 15 Cover strips 1720mm 12 Window hinges 1 Cover strip 2110mm 4 Rolls of felt 7mtr x 1mtr 2 Cover strip 1889mm 20 80mm screws 4 Fascia 1740mm 142 60mm screws...
  • Page 3 Floor Assembly Remove travel protection blocks from bottom edge of panels. 1. Ensure that your base is firm and absolutely level. 2. Take two sections of floor and secure together through floor bearers (990mm side) using 3 x 60 mm screws. You will need to turn the floor over to do this. Repeat for other two pairs.
  • Page 4: Wall Assembly

    Wall Assembly Please see truss assembly before beginning wall assembly. 1. Pre drill panels in 3 places, top, middle and bottom. 2. Decide which side of the building you want your window panels to go. Place one half of the back panel onto the floor ensuring the cladding has overhung the floor. Place side/window panel next to this and join together from the inside using 3 x 60 mm screws.
  • Page 5 Truss Assembly You can use framework of back panels as a template to construct the truss. Lay back panels down. 1. Take the two pieces of truss framework and the one piece of bracing bar framework and place together to make an ‘A’ shape. 2.
  • Page 6: Roof Assembly

    Roof Assembly 1. Staring at the back slide one 1036x1625 mm roof panel into position using the cut-out of the ridge as a guide. Make sure the panel is flush with the back of the building and resting on one half of the truss. Repeat for the other side. 2.
  • Page 7 Corner Strips 1. Fix the corner strips in position where the panels meet using 4 x 40 mm nails per strip. Place another 1720 mm strip in the centre of the double window panel and centre of plain panel. There are 3 longer cover strips, these are for the front and back panel joins.
  • Page 8: Door Assembly

    Door Assembly G Secure Walls 1. Place the doors on a flat level surface, outside of door face up. Check which side of the door the hinges are to be fitted. The diagonal door bracing should point to the door opening. 2.
  • Page 9 Pad Bolt 1. Place the pad bolt in position on the outside of the right hand door directly over the central horizontal brace. Ensure the edge is flush with the edge of the door. Secure using 4 x 25 mm screws using the round holes only. 2.
  • Page 10 Window Insert 1. Place one hinge on the inner part of the top of the window. The rounded part of the hinge should sit above the outer edge of the window. Secure the inner piece into position using 2 x 25 mm screws.
  • Page 11 Fascias and Diamonds 1. Nail the 4 fascia boards to gable using 3 x 40 mm nails per piece. 2. Nail the diamonds on top of and in the centre of the fascia board using 2 x 40 mm nails per diamond. Glazing 1.
  • Page 12 As a natural occurrence this is not covered by a guarantee. Summer Garden Buildings does not guarantee that this is the most recent version of these instructions or that all data has been accurately reproduced. You are advised to refer to the instructions supplied with the product before assembly.
