INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE: DO NOT discard this manual!
Model:
SL-7BV
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fitter.
A CO detector shall be installed in the room where the
appliance in installed.
Installation Manual
Installation and Appliance Setup
Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or the
gas supplier.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
Pour demander un exemplaire en français de ce Manuel
du propriétaire, visitez www.heatnglo.com/translations.
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
1

Advertisement

Table of Contents
loading

Summary of Contents for HEAT GLO SL-7BV

  • Page 1 Pour demander un exemplaire en français de ce Manuel du propriétaire, visitez www.heatnglo.com/translations. Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 2: Table Of Contents

    D. Install Attic Insulation Shield ..... . . 17  = Contains updated information. Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 3: Installation Standard Work Checklist

    _____________________________________________________________________________________ _________________________________________________________________________________________________ _________________________________________________________________________________________________ Comments Communicated to party responsible ____________________ by ______________________on ___________ (Builder / Gen. Contractor/) (Installer) (Date)  = Contains updated information. 2395-982 Rev. B 5/16 Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 4: Product Specific And Important Safety Information

    Glass reproductive harm. For more information go to: www. meeting this requirement is available from the factory. P65Warnings.ca.gov. Please contact your dealer or distributor to order. Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 5: Getting Started

    Non-corrosive leak check solution 1/2 - 3/4 in. length, #6 or #8 Self-drilling screws Caulking material (300ºF minimum continuous exposure rating) One 1/4 in. female connection (for optional fan). Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 6: Inspect Appliance And Components

    Call a qualified service technician to inspect the appliance and to replace any part of the control system and/or gas control which has been under water. Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 7: Negative Pressure

    Recommended Recommended Location Location Marginal Location Location Recommended Location NOT Recommended Windward Leeward Multi-level Roofs Figure 2.1 Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 8: Framing And Clearances

    GAS LINE ACCESS ACCESS 21-1/2 32-1/16 33-9/16 37-5/8 3-9/16 6-7/8 16-5/16 8-3/8 1/2 30-3/4 15-3/8 15-13/16 5-1/16 2-3/16 37-7/8 SL-7BV mm 1040 917 Figure 3.1 Appliance Dimensions Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 9 FIRESCREEN DECORATIVE FRONT 28-3/4 35-15/16 1-5/8 2-5/8 30-5/8 32-1/4 SL-7BV FS-7 Figure 3.2 Decorative Front Dimensions - Firescreen Front Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 10: Clearances To Combustibles

    ALCOVE INSTALLATION TOP VENT TOP VENT Model Minimum Inches 45-1/2 64-3/8 See Section 16-1/4 SL-7BV 11.B for Alcove Millimeters 1156 1067 1635 Installation Figure 3.3 Appliance Locations Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 11: Constructing The Appliance Chase

    (or an equivalent method may be used) to achieve maximum air tightness. Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 12: Termination Location And Vent Information

    Over 20/12 to 21/12 ..........8.0 * H minimum may vary depending on regional snowfall. Refer to local codes. Figure 4.1 Minimum Height From Roof To Lowest Discharge Opening Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 13: Vent Information And Diagrams

    45 DEGREES OFFSETS EXCEEDING ELBOW 45 DEGREES ADAPT HORIZONTAL LIMITATIONS 90 DEGREES ELBOW Note: Maximum horizontal distance is 50% vertical vent height. Figure 5.3 Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 14: Vent Clearances And Framing

    2 in. (51 mm) above insulation. BOTTOM CLEARANCE Attic shields must meet specified clearance and be se- cured in place. Use B-vent manufacturer’s firestops to provide adequate clearances. Figure 6.1 Pipe Clearances Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 15: Appliance Preparation

    • Check handle operation. Pull handle out to open, and in to close. NAILING TABS BOTH SIDES Figure 7.3 Proper Positioning, Leveling And Securing Of An Figure 7.2 Outside Air Kit Installation Appliance Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 16: Non-Combustible Material

    A non-combustible board is factory-installed above the fireplace opening. Do not remove. FACTORY-INSTALLED NON-COMBUSTIBLE BOARD DO NOT REMOVE 3 IN. Figure 7.4 Facing Materials Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 17: Venting And Chimneys (Installing Vent Pipe)

    2 in. (51 mm) above insulation. Attic shields must meet specified clearance and be se- cured in place. B-VENT COMPONENT SCREW 10-5/8 IN. COLLAR FLUE OUTLET COLLAR Figure 8.1 Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 18: Electrical Information

    Copper ground attached GRN wire to GRN screw with inside box GRN wire Figure 9.1 Junction Box Detail - generic Fireplace Shown Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 19 3 volts. 120 VAC is REMOTE RECEIVER required at junction box unless equipped with battery back-up. Figure 9.3 Intellifire Pilot Ignition (IPI) Wiring Diagram with Remote Receiver Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 20 Junction Box BLUE Power Switch Box Supply Figure 9.6 Detail of Fan Wiring with Rheostat Wires Knockout Figure 9.4 Junction Box Wired to Wall Switch or BC10 Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 21: Gas Information

    Check with your local gas utility to determine proper orifice • If substituting for these components, please consult size. local codes for compliance. Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 22: Air Shutter Setting

    NOTICE: Flames should not appear orange or stretch to the top refractory. If sooting occurs, provide more air by opening the air shutter. DETAIL A DETAIL A Figure 10.1 Air Shutter Adjustment Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 23: Finishing

    3 IN. 1 IN. 1 IN. 0 IN. 0 IN. HIGH TEMPERATURE (300º F / 149º C MIN.) TOP & SIDE SEAL JOINT Figure 11.1 Facing Materials Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 24: Mantel And Wall Projections

    Dimension Diagram (Figure 3.1). Figure 11.6 Non-combustible Mantel Leg or Wall Projections (Acceptable on both sides of opening) Figure 11.3 Minimum Vertical and Maximum Horizontal Dimensions of Non-Combustibles Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 25: Decorative Front Finishing

    4 IN. MAXIMUM THICKNESS 4 IN. MAXIMUM THICKNESS Stop finishing material flush with fireplace surround opening. Figure 11.7 Firescreen Decorative Front NON-COMBUSTIBLE ZONE Figure 11.6 Non-Combustible Zone Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 26: Appliance Setup

    Clean/vacuum any sawdust that may have accumulated inside the firebox or underneath in the control cavity. LATCHES (BOTH BOTTOM AND TOP) GLASS ASSEMBLY Figure 12.1 Fixed Glass Assembly Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 27: Install Logs And Embers

    TOP RIGHT LOG left and rear right logs, utilize the “voids” in the rear left and rear right logs for proper placement. Figure 3. Log Assembly Components Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 28 1-1/2 inch gap between the right end of the rear right log and the right side of the firebox. See Figure 5. SIDE GAP REAR GAP Figure 5. Install Rear Right Log Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 29 • Place lava rock in front of and to the sides of the burner. • Lava rock CANNOT be placed on the burner. Figure 8. Install Burner Log Figure 10. Log Set Complete - Lava Rock Installed 2395-935 Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 30: Install Fixed Glass Assembly

    LATCHES (BOTH BOTTOM AND TOP) GLASS ASSEMBLY Figure 12.2 Fixed Glass Assembly Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
  • Page 31: Reference Materials

    Please contact your Heat & Glo dealer with any questions or concerns. For the location of your nearest Heat & Glo dealer, please visit www.heatnglo.com. Printed in U.S.A. - Copyright 2019 Heat & Glo • SL-7BV Installation Manual • 2395-980 Rev. i • 4/19...
