Siegenia-AUBI TSBR0030 Quick Start Manual

Technical information

Material number
TSBR0030- _ _ _ _ _ _
* Specified dimensions are only valid when using surface-mounted hinge sides whose turning points correspond to those of SIEGENIA-AUBI hinge sides. For different turning points, adjust
dimensions so that a sash opening angle of 100° is not exceeded.
Please observe: Guidelines/notes on the product and on liability (VHBH directive as well as the other applicable documents
listed herein - Directive can be downloaded at www.beschlagindustrie.de/ggsb/richtlinien.asp). Specifications
from the profile manufacturers/system owners (PVC, light metal) or DIN 68 121 "Wooden profiles for windows
and portal doors"

WARNING

on the hinge side or its screw connections, which can cause them to fail. This poses a risk of injury or death
caused by the sash falling out.
› Select and fasten load-bearing hardware on the hinge side
its fastenings even in the case of incorrect operation of the sash when fixed in the turn position.
› Ensure that the selected combination of window profile, load-bearing hinge-side hardware – also for SIEGENIA-AUBI
sides – and its screw connections can withstand incorrect operation. To do this, apply loads to a sash fixed in the turn position
in both directions (closing/opening) and for several opening angles.
› Attach the operating label included with delivery near the window handle to discourage incorrect operation.
•

Proper use:

Continuously adjustable fixing of inward-opening window sashes of side-hung and turn-and-tilt windows in the
turn position for the purpose of airing out the dwelling for a short time with fully open windows.
• Maintenance to be performed according to our care and maintenance instructions.
• * Friction stay accessories bag, see profile data sheet, ZMBR
H52.TIPFSBR_001EN
Brake stay
Description
Brake stay TZS size 2
Incorrect operation (moving a sash fixed in the turn position before first releasing
the catch) can cause extreme forces to be transferred to the load-bearing hardware
Dimensions (mm)
Sash rebate width (mm)
645 - 1245 132
to prevent damage to the load-bearing hardware and/or failure of
*
TITAN iP
*
A B
104
B
A
Last update: 2 Dec. 2011
4
hinge
