- Page 1 Operating instructions Automated latch release Automatic door lock Window hardware Door hardware Sliding door hardware Ventilation and building technology...
-
Page 3: Table Of Contents
Operating instructions Automated latch release Contents Intended use....................2 Improper use....................2 Safety notes....................2 Switching the acoustic signal on and off............3 Locking and unlocking the door..............4 Operating the system with optional external devices........4 Programming....................5 Infra-red access keys..................6 Programming in the infra-red master key............ -
Page 4: Intended Use
Automated latch release Operating instructions Intended use The automated latch release is used in conjunction with automatic locking systems for unlocking doors by motor. It is suitable for installation in timber, aluminium, steel and PVC front doors for residential and public buildings. All assembly and electrical installation work must be carried out according to our assembly and installation instruc- tions. -
Page 5: Switching The Acoustic Signal On And Off
Operating instructions Automated latch release Switching the acoustic signal on and off In its "supplied" state, the automated latch release beeps as it draws the latch electrically into the changeover function. It emits a constant beep for as long as terminal 4 receives an "open" signal. In some cases this constant beeping is undesi- rable, e.g. -
Page 6: Locking And Unlocking The Door
Automated latch release Operating instructions Locking and unlocking the door Night mode Locking the door: When the door clicks shut, the hookbolts in the additional lock cases automatically engage. Unlocking the door: The door can be unlocked by turning the profile cylinder or the indoor lever handle, and can be opened by the automated latch release. -
Page 7: Programming
Operating instructions Automated latch release Programming Programming the handheld wireless transmitter › Unscrew the cover on the receiver to access the programming button. 11 12 13 12 24 ac / dc › The green LED L1 lights up. › Press down button P1 until the green LED L2 lights up. ›... -
Page 8: Infra-Red Access Keys
Automated latch release Operating instructions Infra-red access keys Infra-red eye In the infra-red eye there is a red LED which indicates whether the door is locked or open. Solid light Door is open Flashing Opening, or: fault (double speed) Door is locked Fig. -
Page 9: Programming In The Infra-Red Master Key
Operating instructions Automated latch release Programming in the infra-red master key › Retract all locking elements. › Open the door and hold it open. › Switch off the operating voltage. › Press and hold down the "open" button (terminal 2 (+24 V) with terminal 4 ("open")) ›... -
Page 10: Replacing The Batteries
Automated latch release Operating instructions Replacing the batteries Risk of chemical burns from leaking battery acid WARNING - Batteries must be kept out of the reach of children due to a risk of swallowing. If they are swallowed, seek immediate medical attention. -
Page 11: Disposing Of Batteries
Operating instructions Automated latch release Disposing of batteries The law requires that all spent standard and rechargeable batteries be returned to their manufacturer; they must not be disposed of as household waste. Dispose of the batteries as required by the relevant authorities. Hand them in for recycling. These batteries will be recycled as they may contain e.g. -
Page 12: Liabilty
Automated latch release Operating instructions Liability Intended use Any use of this product that is not in accordance with its intended use, or any adaptation of or modification to the product and its associated components for which our express consent has not been obtained, is strictly prohibited. We accept no liability whatsoever for any material losses or injury to people caused by failure to comply with this stipulation. - Page 13 Operating instructions Automated latch release Last update: 01.08.2013...
-
Page 14: 42551 Velbert
Telefax: +49 2051 278-167 42551 Velbert post@siegenia-aubi.com GERMANY www.siegenia-aubi.com Hungary Phone: +36 76 500810 SIEGENIA-AUBI worldwide: Austria Phone: +43 6225 8301 Italy Phone: +39 02 935 3601 Belarus Phone: +375 17 312 1168 Poland Phone: +48 7744 77700 Russia Phone: +7 495 7211762...
