Frigidaire GLEB27T8A Factory Parts Catalog

Electric wall oven
Hide thumbs

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
GLEB27T8ABA
GLEB27T8A
GLEB27T8ASA
GLEB27T8A
WIRING DIAGRAM - # 318046110
OWNER'S GUIDE - # 318200919
TIMER INSTRUCTION SHEET - # 318200130
INSTALLATION INSTRUCTIONS - # 318201509
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917
FACTORY PARTS CATALOG
FACTORY NO.
COLOR
37056791F1061
black
37056791F1011
white
Publication No.
5995360863
011112
-EN/SERVICE /ECL
377
RANGE
MARKET
North America
North America
ELECTRIC
WALL OVEN
Model No.
GLEB27T8A
©2001 White Consolidated Industries, Inc.
All rights reserved
