xit404 NIKON AF-S Assembly Instructions

NIKON 105VR LENS NIKON 105VR LENS
SLIDE FOCUS RING
ONTO LENS IN THE
UNLOCKED POSITION
LENS WITH FOCUS LENS WITH FOCUS
RING ATTACHED RING ATTACHED
ORIENT GEAR IN THE
UNLOCKED POSITION
RED LATCH
105VR 105VR
GEAR
Revsion 2.0 - APR2013
NIKON AF-S MICRO-NIKKOR 105mm VR f/2.8G
FOCUS RING AND GEAR ASSEMBLY INSTRUCTIONS
ALIGN SURFACE OF ALIGN SURFACE OF
FOCUS RING WITH FOCUS RING WITH
THE RUBBER ON LENS THE RUBBER ON LENS
GRAY/RED
FOCUS RING
UNLOCKED UNLOCKED
POSITION
ROTATE FOCUS ROTATE FOCUS
RING INTO RING INTO
LOCKED POSITION LOCKED POSITION
Thank you for purchasing Xit 404's Nikon AF-S Micro 105VR Focus
Ring/Gear set or Teleconverter Gears. On the back is our warranty
information to help you prolong the life of this product.
Assembling the Focus Ring and Gear
Look at the drawing to the left and note which end of the lens the
Focus Ring slides onto. Then follow the instructions below.
1. Make sure your Focus Ring is in the unlocked position. Slide the
FOCUS RING PROPERLY
LOCATED ON LENS
2. Once on the lens, grasp the Focus Ring, then press and hold the
3. Slide the Gear on from the back of the lens. Align the white dot
GREY GREY
LATCH LATCH
Disassembling the Focus Ring and Gear
1. Remove the Gear by pressing and holding the red latch on the
2. Pull the Gear Ring off the lens.
3. Remove the Focus Ring by reversing steps 1 and 2 above. The white
SHOWING THE SHOWING THE
UNLOCKED POSITION
Focus Ring onto your lens from the front and align the front of the
gray ring with the edge of the rubber ring on the lens, see picture
on left.
gray latch on the Focus Ring while twisting the gray and red rings
in opposite directions until the white dots line up. (Note: the locked
icon). The Focus Ring is now locked onto the lens.
on the Gear with the unpainted red dot on the Focus Ring. Then
press the two parts together. Once the the two parts are fully
mated, while holding the Zoom Ring twist the Gear until the white
dots line up (note: the locked icon). The Gear is now locked onto
the Focus Ring. Follow this step for assembling the 1.4x and 2x
teleconverters Gears as well.
Gear. Then twist it until the white dot on the Gear is lined up with
unpainted red dot on the Focus Ring. (Note: the unlocked icon).
dot and the unpainted red dot will not be lined up after step 2,
allowing you to slide the Focus Ring off your lens.
ROTATE GEAR INTO ROTATE GEAR INTO
LOCKED POSITION LOCKED POSITION
PRODUCT CODE: GN210100
