Programming Remote Control/Clearing Receiver (EP3)
9,*$#,3% '$()*$ +),*#)%
5$3#, 2:**),
'$()*$ +),*#)% 5-6 5"78*
-;*$#,3% '$()*$ +),*#)% 5$3#, 2:**),
<:,4$#&"4$ )= >)?$# :,"* 0),*#)%%$#@
Programming Remote Control:
1. Press and hold the internal or external remote control
learn button until the remote control LED light on the
receiver board turns on.
2. Once the LED light turns on, release the remote control
learn button.
3. While the LED light is on, press and hold any button on
the remote control. The LED light will blink twice and then
turn off. The remote control is now programmed and linked
to the receiver board. Repeat the programming procedure
for any subsequent remote.
Endless Pools
-./ '$0$"1$# 2)3#4
!"#$%$&& '$()*$ +),*#)%
Service Instruction
D90038_en 0918
Advertisement
Table of Contents
Related Manuals for Endless Pools EP3
Summary of Contents for Endless Pools EP3
- Page 1 Programming Remote Control/Clearing Receiver (EP3) Service Instruction -./ '$0$"1$# 2)3#4 9,*$#,3% '$()*$ +),*#)% 5$3#, 2:**), '$()*$ +),*#)% 5-6 5"78* -;*$#,3% '$()*$ +),*#)% 5$3#, 2:**), <:,4$#&"4$ )= >)?$# :,"* 0),*#)%%$#@ Programming Remote Control: 1. Press and hold the internal or external remote control learn button until the remote control LED light on the receiver board turns on.
- Page 2 Programming Remote Control/Clearing Receiver (EP3) Service Instruction Clearing Receiver: 1. Press and hold the internal or external remote control learn button until the remote control LED light on the receiver board starts blinking rapidly. 2. Continue to hold the remote control learn button until the LED light goes out.
Need help?
Do you have a question about the EP3 and is the answer not in the manual?
Questions and answers
Went through the instructions to pair a new remote with the EP3 receiver board several times and remote still is not paired. What next?
To pair a new remote with the Endless Pools EP3 receiver board, follow these steps:
1. Press and hold the internal or external remote control learn button until the remote control LED light on the receiver board turns on.
2. Release the remote control learn button once the LED light is on.
3. While the LED light remains on, press and hold any button on the remote control.
4. The LED light on the receiver board will blink twice and then turn off, indicating successful pairing.
If troubleshooting is needed, ensure the receiver board is powered, repeat the process, or perform a factory reset by holding the “SW2” button on the receiver board for about 30 seconds until the heartbeat light blinks rapidly, then wait 2-3 minutes for a reboot.
