IMPORTANT SAFETY INFORMATION WARNING: DO NOT DIVE OR JUMP . IT IS NOT DESIGNED FOR DIVING OR JUMPING. YOUR POOL IS APPROXIMATELY 4’ DEEP . IF YOU DIVE OR JUMP INTO YOUR POOL YOU RUN THE RISK OF PERMANENT INJURY OR DEATH.
INTRODUCTION The Installation of the Radiant Metric Series Oval pool is not hard, nor complicated. Although, installation conditions might differ from this guide, it is important to consult with the manufacturer before making any changes that might disturb the integrity of the pool. Failure to follow these instructions will void all warranties. Read and follow all manufacturers’...
Page 4
TOOLS NEEDED Orange Marking Metal File Tape measure, 100ft. Spray Paint Utility Knife Pool trowel Square Transit/Laser Level String Hose with spray nozzle Level Cooking Spray Duct Tape Step Drill Bit Cloth rag Rubber Mallet COOKING SPRAY Long handled pointed shovel Socket Set Hacksaw Short handle...
Page 6
Standard Splines - Used at curved panel joints to join walls together. Straight Panel Spline Connector - Join straight panels together. Standard Metric Coping - Secures liner & gives finished appearance. Hold Down Plates - reinforces structural stability Structural Bracing - for Straight Wall Panels...
Page 7
SELECTING POOL LOCATION he selection and preparation of the pool site is your responsibility. The manufacturer can only suggest the proper techniques, indicate the important considerations, emphasize the precautions, and cannot be held responsible for damages to your pool that may result from failure to carefully follow all pool specifications. 1.
LEVELING AND LAYOUT GROUND PREPARATION Establish ground level (benchmark) of the pool. A sturdier pool will result when the pool rests on undisturbed earth. It is better to have to remove an inch or two by hand than to have to build up after the excavator had gone too deep. Any voids beneath the wall panels cause by large rock removal, etc., must be filled and properly compacted.
Page 9
Dig trenches 8” deep for all pool sizes. Level the bottom of the trench so that the top of the 8” concrete block is level with benchmark. NOTE: IF INSTALLING METRIC OVAL WITH HOPPER, PLEASE REFER TO SEPARATE INSTRUCTIONS FOR TRENCH LAYOUT.
Page 10
PATIO BLOCK LAYOUTS 12’ POOLS: There will be 2 patio blocks set at each radius end. LEVEL AREA TRENCH 1. Mark a 6 foot semi-circle from points M and N. LEVEL AREA 2. Mark a Mid-line thru M and N crossing the TRENCH 6’...
Page 11
PATIO BLOCK LAYOUTS 18’ POOLS: There will be 3 patio blocks set at each radius end. 1. Mark an 9 foot semi-circle from points M and N. 2. Mark a Mid-line thru M and N crossing the 9’ semi- circles 3.
Page 12
CHANNEL ASSEMBLY AND LAYOUT The bottom channel, once assembled, creates the framework for all remaining assembly and must be done next. Bottom channels come with welded extensions at one end to connect tracks together. To assemble, align holes on extension over holes in channel track. Insert 3/8” x 3/4” bolts with 9/16”...
Page 13
CONCRETE BLOCK AND CHANNEL LAYOUTS 1. Top of concrete blocks must be adjusted to the benchmark of the pool. Using sand or stone dust, blocks must be level as well as the proper height to allow the channel to lay flat. 2.
Page 14
CONCRETE BLOCK AND CHANNEL LAYOUTS CHANNEL 15” 8”x 8”x16” STANDARD 12” CONCRETE BLOCK 35” ” INSIDE POOL 12’ 6” CHANNEL 12 x 24 & 16 x 28 POOLS: 35” BLOCK PLACEMENT 13” • 4 BLOCKS ON EACH SIDE TOP SURFACE OF BLOCKS •...
Page 15
STRAIGHT WALL PANEL AND CONNECTOR ASSEMBLY NOTE: Use of cooking spray is recommended on the first few inches of the splines to ease assembly. DO NOT use petroleum based lubricants (WD-40). Ease of spline installation depends on level and parallel wall joints. STRAIGHT PANEL STANDARD STANDARD...
Page 16
RADIUS WALL PANEL ASSEMBLY RADIUS PANEL ASSEMBLY Locate the wall panel that is cut for the skimmer and return fitting. The location for the panel should be adjacent to the electrical supply and provide ease of Return Cut-Out access once the pool is installed. Place an anchor plate centered on a patio block.
Page 17
A-FRAME AND STRUCTRUCAL BRACE INSTALLATION A-FRAME AND STRAP INSTALLATION Pool Wall Inside Pool Extended “T” Spline A-Frame 2” Flathead Through Boltsand T-Nuts Channel Trench w/concrete block supporting channel There are as many A-Frames on a side as straight panel joints. 27”...
Page 18
CONCRETE REQUIREMENTS Follow Table Below For Concrete Requirements. Use Standard Swimming Pool Collar Mix Concrete. CHECK LEVEL PLUMB AND SQUARE OF POOL ONE FINAL TIME BEFORE POURING CONCRETE Fill trench to top of the A-Frame horizontal inside of the pool and to top of weld point on A-Frame on the outside of the pool (Fig.
Page 19
PREPARING POOL FLOOR The pool interior must be prepared to provide a smooth surface and protection for the vinyl liner. Check inside of pool area for debris, stones, sharp objects, etc. Using the prescribed amount of masonry sand per pool (as shown in the chart below) will provide a 2”...
Page 20
SKIMMER ASSEMBLY Place the U shaped foam insert into the panel cut out with open side up. Fig. C Install the rubber sandwich gasket on the gray mounting plate, making sure the gasket straddles Skimmer Cut-Out Mounting Plate both sides of the mounting plate. Fig. D Gasket Place the gray mounting plate with gaskets on the pool interior side of the panel cut-out, with the...
Page 21
RETURN FITTING ASSSEMBLY Pool Pool Interior Exterior The return fitting kit includes 3 parts: inlet fitting, inlet plate and back nut. Install the inlet fitting into the pre-cut hole, slide the inlet plate over the exposed threads and then thread the back nut onto the fitting. Inlet Fitting DO NOT OVERTIGHTEN.
Page 22
INSTALLING LINER Standard 2” Coping Clear all sticks and sharp objects from an area near the Liner Bead pool that is as large as the pool itself. Remove the liner Bead Track from its carton and unfold and open the liner. Refold the liner so that it can easily be carried to the pool and unfold from the outside of the pool.
INSTALLING FACEPLATES Once the water level reaches 2”-3” from the return and skimmer, install the faceplates. Carefully locate the screw holes for each opening. Once located, carefully puncture the liner with an icepick or nail. Attach skimmer faceplate with 1” screws and hand tighten evenly in order as shown in skimmer faceplate image below.
Page 25
INGROUND: LEVELING THE EXCAVATION Establish the Benchmark of the pool. The finished height of the pool includes the wall height, coping and the decking (pavers, wood deck etc.). The Benchmark will determine the depth of the excavation where the panels will rest. With the shape of the pool excavation marked out, its height relative to the ground must be determined.
Page 26
INGROUND: WALK-IN STEP INSTALLATION Prepare and Position Step Install leg supports for the steps. For steps supplied by Radiant Pools, instruction will be provided. If steps are purchased separately through another provider, verify compatibility by talking with a Radiant Pools representative. Be sure to check step manufacturer’s instructions as the step supports will vary by manufacturer.
Page 27
INGROUND: WALK-IN STEP INSTALLATION Radius Step to Radius Wall Panel Installation Components (item # KS-52-RWSA) • (2) Seam Connectors • (2) 52” Standard splines for interior side of pool • (2) each: 40 ½” Extended T splines and 10” Standard Splines for exterior side of pool •...
Page 28
Transition with Mixed Coping End caps are available for installation of CP2 and Metric plastic coping combination. The End Cap provides a clean finish to the concrete and fits inside the CP2 coping before the lower profile of the Standard 2” or Premium 4”...
Page 29
INGROUND: SKIMMER ASSEMBLY Gaskets Pan Head Screw Place a gasket on both sides of the gray mounting plate. Be sure to align all holes. (fig.C) Position the gray mounting plate over Countersunk Bolt the panel cutout on the interior side of Skimmer Skimmer the pool.
Page 30
CONCRETE COLLAR GUIDE Check with local building codes before installing your Radiant Metric Oval pool inground. Radiant Pools requires a minimum of 8” concrete collar around the entire pool if any point of the pool wall is 26” or greater in the ground (fig. 2). An example of a semi-inground pool requiring a concrete collar is shown below (fig.1).
Page 31
BACKFILL AND DRAINAGE Before backfilling, check with electrician for pool bonding. Sonotubes may be installed at the time of collar pour to support the deck. Backfill may go directly against a Radiant pool wall. Crushed stone/gravel 3/8” - 3/4” in diameter is recommended.
Page 32
440 North Pearl Street Albany, NY 12207 1-800-RADIANT rev 02/2016...
