- Page 1 Keystone Pool Assembly Manual...
- Page 3 INTRODUCTION The Installation of the Radiant Keystone Series Semi-Inground pool is not hard, nor complicated. Although, installation conditions might differ from this guide, it is important to consult with the manufacturer before making any changes that might disturb the integrity of the pool. Failure to follow these instructions will void all warranties.
-
Page 4: Tools Needed
TOOLS NEEDED Tape measure, 100ft. Flint File Pool trowel Transit Utility Knife Hose with spray nozzle Square Level Cloth rag Long handled pointed shovel Socket Set Rubber Mallet Short handle square shovel 9/16” Open End Wrench Coping Saw Pick or Mattock Power Drill Screwdrivers,... - Page 5 KEYSTONE SERIES POOL COMPONENTS STRAIGHT PANEL POOL COMPONENTS COMPONENT Straight Wall Panel - Form straight sides of pool. Top Channel - Support top of straight walls and provide attachment for coping. Bottom Channel - Provide base and structural support for straight walls.
-
Page 6: Important: Before You Begin
IMPORTANT: BEFORE YOU BEGIN The selection and preparation of the pool site is your responsibility. The manufacturer can only suggest the proper techniques, indicate the important considerations and emphasize the precautions and cannot be held responsible for damages to your pool that may result from failure to carefully follow all pool specifications. -
Page 7: Wall Panel Assembly
WALL PANEL ASSEMBLY Be sure that bottom channel and wall panels are free of debris before beginning assembly. Once bottom track is assembled, begin assembling wall panels. Always start with the end 45 corner connections first, working towards the middle as shown. It is important that the final panel assembled is a straight panel connection. - Page 8 A-FRAME & BACKBRACE ASSEMBLY 3/8" X 3/4" Aluminum Bolt 3/8" Nut, 3/8" Washer Position backbraces and attach A-Frames in their proper locations around the pool. Please refer to dig specifications for spacing and placement. Assemble as shown. A-Frame Assembly 3/8" X 2 1/2" Aluminum Bolt 3/8"...
- Page 9 PREPARING POOL FLOOR Bring the required amount of clean and washed masonry sand into the interior of pool area at this time. Refer to the chart below for the required amount. Sand Amt Pool Size (cubic yds) 26’ CTAGON 15’ x 29’ 12"...
- Page 10 SKIMMER ASSEMBLY Countersunk Bolts (4) Slide skimmer face through pre-cut skimmer opening, keeping skimmer body on outside of pool wall. Fasten assembly by inserting 2” countersunk bolts through corner holes in mounting plate, through pre-cut holes in pool wall and through skimmer mounting brackets, securing with hex nuts.
- Page 11 LIGHT NICHE MOUNTING PLATE ASSEMBLY (OPTIONAL) To install the light niche mounting plate assembly you must place the mounting plate on the inside of the pool. Light niche goes behind the mounting Pool plate. Be sure to align the niche to the hole pat- Interior tern on the mounting plate.
- Page 12 STRAIGHT PANEL TO STEP 45 CONNECTION (OPTIONAL) Top Channel Backbrace Connection Clip Wall Panel Due to variations in flange length Grecian Stair Adaptor from different step manufacturers, a flange extension plate is provided to Step Flange Flange Extension Plate ensure adequate connection between Thermoplastic Step pool wall and step.
- Page 13 CONCRETE COLLAR GUIDE Radiant Pools recommends a 6” to 8” inch concrete collar around the entire pool (fig.1). It is also recommended that a thicker (8”-12”) concrete collar is poured at each A-frame location (fig.2). It is strongly recommended that the concrete not be poured directly on the wall or flood behind the pool wall.
-
Page 14: Completing Installation
INSTALLING FACEPLATES Once the water level reaches 2”-3” from the return and skimmer, install the faceplates. Carefully locate the screw holes in for each opening. Once located, carefully puncture the liner with an icepick or nail. Attach faceplate with 1” screws and hand tighten evenly till snug. Using a razor knife, carefully trim the liner out of the openings for the skimmer and return. -
Page 15: Important Safety Information
IMPORTANT SAFETY INFORMATION WARNING: DO NOT DIVE OR JUMP . IT IS NOT DESIGNED FOR DIVING OR JUMPING. YOUR POOL IS APPROXIMATELY 4’ DEEP . IF YOU DIVE OR JUMP INTO YOUR POOL YOU RUN THE RISK OF PERMANENT INJURY OR DEATH. Enclosed in the liner box is the safety envelope. - Page 16 Trojan Leisure Products, LLC. 440 North Pearl Street • Albany, NY 12207 toll-free: 866-697-5870 • fax: 518.432.6554 www.radiantpools.com...
