"The mission of Boston Whaler
is to
®
provide consumers with the
safest, highest quality, most durable
boats in the world"
Revision A - 07/17/06
INFORMATION IN THIS PUBLICATION IS BASED ON THE LATEST PRODUCT SPECIFICATIONS AVAILABLE AT PRINTING, BOSTON WHALER
®
BOATS, INC. RESERVES THE RIGHT
TO MAKE CHANGES AT ANY TIME WITHOUT NOTICE, IN THE COLORS, EQUIPMENT, SPECIFICATIONS, MATERIALS AND PRICES OF ALL MODELS, OR TO DISCONTINUE MODELS.
SHOULD CHANGES OR MODIFICATIONS TO THE MODELS BE MADE BOSTON WHALER
®
IS NOT OBLIGATED TO MAKE SIMILAR CHANGES OR MODIFICATIONS TO MODELS
SOLD PRIOR TO THE DATE OF SUCH CHANGES. THE FOLLOWING ARE REGISTERED TRADEMARKS OF THE BRUNSWICK CORPORATION:
320 OUTRAGE, BOSTON WHALER
®
. MRP #1839958
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for whaler 320 Outrage
Summary of Contents for whaler 320 Outrage
- Page 1 Revision A - 07/17/06 INFORMATION IN THIS PUBLICATION IS BASED ON THE LATEST PRODUCT SPECIFICATIONS AVAILABLE AT PRINTING, BOSTON WHALER ® BOATS, INC. RESERVES THE RIGHT TO MAKE CHANGES AT ANY TIME WITHOUT NOTICE, IN THE COLORS, EQUIPMENT, SPECIFICATIONS, MATERIALS AND PRICES OF ALL MODELS, OR TO DISCONTINUE MODELS.
- Page 2 Fisher motoring away in the remaining half of the boat. And through the years many other demonstrations have proved the toughness and durability of the Boston Whaler hull. And though you may never cut your boat in half, this only goes to show one thing, people whose livelihood and lives depend on boats consistently choose Boston Whaler because of their seaworthiness, dependablility and the inherent safety of a hull that won’t sink even if severely damaged.
-
Page 3: Table Of Contents
Helm Seat Track Maintenance Empty Tank Propeller Information Hoses & Fittings Propeller Assembly Tank Cleaning Section 9-Getting to know your Boston Whaler Remote Oil System (Optional) Static Electricity and the Fuel System Trim Tabs-Operation/Maintenance Ethanol-Blended Fuel Mooring Points/Lifting Section 4-DC Electrical System... -
Page 4: Section 1-320 Outrage
Structural Hull Defect in material or workmanship which is reported within five (5) years (60 months) from the date of the first retail purchase of the Boston Whaler Boat. The “Hull” shall mean the single fiberglass molded shell and integral structural components. -
Page 5: Adss Operation/Maintenance
The new owner must fill out and send in a Boston Whaler warranty transfer form, accessible from www.whaler.com, a copy of the bill of sale, and a $50.00 fee to Boston Whaler, 100 Whaler Way, Edgewater, Florida 32141, within 30 days of purchase. -
Page 6: Construction Standards
320 Outrage-Owner’s Manual Construction Standards “THE MISSION OF BOSTON WHALER IS TO PROVIDE CONSUMERS WITH THE SAFEST, HIGHEST QUALITY, MOST DURABLE BOATS IN THE WORLD”. We are dedicated to creating a superior product providing you with comfort, performance, safety and dependability. All... -
Page 7: Section 2-General Arrangement & Specifications
320 Outrage-Owner’s Manual 9’10” 8’11” 1’10” 35’6” 32’2” 10’2” Hardtop removed for clarity Specifications & Dimensions Overall Length 32’2” 9.80 m NOTICE Trailerable Length 35’6” 10.8 m Specified measurements are approximations and are Bridge Clearance 9’10” 3.00 m subject to variance. -
Page 8: Standard Features
320 Outrage-Owner’s Manual Standard Features Heavy Duty Rubrail Anchor Locker w/ Drain Bow Navigation Lights, (P&S) Stainless Steel Fwd. Cleats, (P&S) Welded Stainless Steel Low Profile Interior Rail Forward Bolsters Forward Seat, (Storage Under) Forward Port Seat, (Storage Under) Forward Starboard Seat, (Storage Under) - Page 9 320 Outrage-Owner’s Manual Standard Features Prep Station Transom Shower Prep Station, Tackle Center Hardtop, Fiberglass Pull-out Sprayer with Sink Lifejacket Storage Prep Station Rodholder, (2) Electronics Box Prep Station Livewell Hardtop Courtesy Lights Prep Station Livewell Access Map Light (RED)
-
Page 10: Notable Options
320 Outrage-Owner’s Manual 16 17 320 Outrage, Notable Options VHF Radio Antenna ® Sirius Satellite Radio Antenna GPS Antenna Radial Outriggers (P&S) 4KW radome* Radar Pedastal (with Spotlight Option Only) Spotlight, Halogen Bow Tow Eye Additional Northstar 6000i Display Navman 7100 VHF Radio... -
Page 11: Storage
320 Outrage-Owner’s Manual Storage Underside of T-Top, (looking up) WARNING No Ventilation is provided. Fuel vapors are a fire and explosion hazard. To avoid injury or death, DO NOT store fuel or flammable liquids in any of these areas. 108 Gal. (409L), Forward Insulated Fishbox 80.5 Gal.(305L) Forward Locker Starboard... -
Page 12: Through-Hull Fittings
If the through hull fittings need to be replaced, it is Garboard drain plugs and fishbox drain plugs need recommended that an authorized Boston Whaler ® to be in place before the boat goes into the water. dealer perform this type of repair. Through hull fit-... -
Page 13: Deck Occupancy
320 Outrage-Owner’s Manual Deck Occupancy Accommodation deck: This area of the boat is inside the cockpit and includes helm seating. Movement in this area should be done with extreme caution while the boat is underway. A sudden shift in boat direction can cause a loss of balance and lead to injury or death. -
Page 14: Canvas Arrangment
320 Outrage-Owner’s Manual 320 Outrage Canvas Arrangement (Optional) Bait Prep Station Cover, Black Console Cover, Black Weather Curtain Visor, Black or White Weather Curtain Sides, Black or White Weather Curtain Wing, Black or White DANGER Standard Seating Arrangement Injury and possible death can occur while sitting in ar- Helm &... -
Page 15: Label Locations
MRP# 1746869 CAUTION It is important to replace any damaged or ON UNDERSIDE OF COVER ENSURE PROPER DRAIN PLUG INSTALLATION. unreadable label. Call your Boston Whaler REMOVAL OF FISHWELL DRAIN PLUGS COULD RESULT IN SWAMPING. dealer for replacement labels. MRP# 1743504... - Page 16 320 Outrage-Owner’s Manual 320 Outrage, Label Locations NOTICE It is important to replace any damaged or unreadable label. Call your Boston Whaler dealer for replacement labels. CAUTION WARNING NOTICE ENSURE PROPER DRAIN PLUG INSTALLATION. WARNING DO NOT LEAVE TRANSOM REMOVAL OF FISHWELL DRAIN PLUGS COULD...
-
Page 17: Section 3-Fuel System
Fuel Fill the warranty. Follow engine manufacturer’s recommen- dations regarding the types of fuel and oil to use. The 320 Outrage has fuel fills for each tank, located on the port/starboard sides amidship on the gunwales, CAUTION each is marked “GAS”, and is opened by use of a Leaking fuel is a fire and explosion hazard, inspect the special key that is included with the owner’s manual... -
Page 18: Fuel Vent
320 Outrage-Owner’s Manual EMPTY TANK: Fuel Vent A fuel tank with levels less than 1/4 full can cause problems by stalling an engine due to fuel starvation The fuel tank(s) Deck fill plates have integrated fuel tank or by allowing sediment and dirt to enter the fuel vents which serve as a pressure/vacuum release, safety supply lines. -
Page 19: Tank Cleaning
Here are some helpful sug- Remote Oil System (Optional) gestions to keep you safe from static electricity while The 320 Outrage may be equipped with a remote oil refueling your boat. system. This system consists of two 3-Gal.(11.3L) •... -
Page 20: Ethanol-Blended Fuel
Before introduc- ing gasoline with ethanol into your fuel tank, ask your dealer if any components have been added or replaced Condensation that are not recommended by Boston Whaler, Mercury Upper Phase (water+fuel+ethanol) or may not be ethanol-compatible. Lower Phase (water+ethanol) - Page 21 320 Outrage-Owner’s Manual ADDITIVES MAINTENANCE There is no practical additive known that can prevent or Periodically inspect for the presence of water in the fuel correct phase separation. The only solution is to keep tank. If any is found, all water must be removed and the water from accumulating in the tank.
-
Page 22: Section 4-Dc Electrical System
NOTICE Always store the battery in the the battery box. Use the straps and clamp to keep the box secure while underway. Battery Information Your 320 Outrage is equipped with Battery Deck has a Direct Current (DC) electrical sys- Boxes been tem. -
Page 23: Dual Battery Switches
The bilge pump will still draw power from the batter- ies, even if the switches are set to “OFF”. Your 320 Outrage uses a battery selector switch to control delivery of DC power from two batteries. The battery switches are located below the breaker panel on the aft bulkhead inside the console. -
Page 24: Instrument Panel Wiring Diagram
This owner’s manual contains schematics for your boat. These electrical schematics were generated by technicians in our Engineering Department and are for reference and to be used by service technicians. Boston Whaler® does not recommend that you attempt to work on ELECTRICAL... -
Page 25: Main Breaker Panel Wiring Diagram
320 Outrage-Owner’s Manual Main Breaker Panel Diagram Hull Wiring Diagram Section 4 - Electrical System... -
Page 26: Adss Wiring Diagram
320 Outrage-Owner’s Manual Active Deck Suspension System(ADSS) Wiring Diagram Waste System-Inland Waters Diagram Waste System-Overboard Discharge Diagram Anchor Windlass Wiring Diagram Section 4 - Electrical System... -
Page 27: Instrument Panel Arrangement
FAVORITES HOME PORT STBD NAV-FUEL SETTINGS SYSTEM START START STOP STOP 320 Outrage, Instrument Panel Arrangement Starboard Fishbox Pump-out Instrument Panel, Blank Forward Fishbox Pump-out Horn Freshwater Pump Port Ignition Raw Water Pump Port Start Livewell Pump Starboard Ignition Livewell Light... - Page 28 320 Outrage-Owner’s Manual System View Monitor Arrow Trackpad/Select Key Home Key Water Pressure Indicator Clock Engine Gear Position Air Temperature Indicator Home Page Directory Symbol Engine RPM Indicator Favorites Directory Navigation/Fuel Directory Propulsion Directory Settings Directory Vessel Directory System Directory...
-
Page 29: Ignition Shutdown Switch
The 320 Outrage can be fitted with two (2) electric erator. If an emergency arises where the engine(s) receptacles for powering electric downriggers. The... -
Page 30: Main Breaker Panel
320 Outrage-Owner’s Manual 320 Outrage, Main Breaker Panel PORT MASTER STARBOARD MASTER IGNITION IGNITION Breaker Panel SWITCHED BREAKERS Port master Ignition Switch HORN NAV/ANCH TRIM TABS STEREO HELM 12V RECEPTACLE Starboard Master Ignition Switch 5 Amp Breaker for Horn switch... -
Page 31: Engine Starting Procedure
Instrument Panel NEUTRAL. Check the levers for neutral position be- fore starting the engines. The 320 Outrage is equipped with dual outboard en- gines for propulsion. STBD START... -
Page 32: Navigation Lighting
Your 320 Outrage comes equipped with navigation lighting for your safety. Regulations state that all boats no matter the size must display navigation lights. -
Page 33: Shore Power
320 Outrage-Owner’s Manual CAUTION To minimize shock hazard, follow these instructions: • Turn off boats shore connection switch before con- necting the Power cord corset. • Connect the cordset to the boat inlet first, then to the Male shore outlet. Close boat inlet cover tightly to prevent plug end water intrusion. -
Page 34: Section 5-Water & Waste System
320 Outrage-Owner’s Manual Freshwater System Your 320 Outrage is fitted with a 40 NOTICE Gal. (151L) freshwater tank. The Be sure to fill the water tank from a source known to freshwater system includes: Pump, provide safe, pure drinking water. -
Page 35: Maintenance
320 Outrage-Owner’s Manual MAINTENANCE: Very little maintenance is required for the freshwa- ter system, other than annual disinfecting and win- terizing. Periodically check the entire system to as- sure that the hose connections, tube fittings, electri- cal connections and mounting bolts are properly se-... -
Page 36: Raw Water
320 Outrage-Owner’s Manual Raw Water NOTICE The seacock MUST be in the OPEN position. Running the pump dry may cause damage to the unit. The Raw water system includes the pump, seacock and connections that will service the livewell and raw water connection port. -
Page 37: Head System
Lock with padlock of a shore side discharge. (not supplied). Your 320 Outrage has a head compart- ment located in the console. It is fit- ted with a VacuFlush® waste contain- HEAD... -
Page 38: Standard Waste Panel
320 Outrage prior to using the to this regulation. (40CFR 140.3) Section 5 - Water & Waste System... -
Page 39: Section 6-Bilge System
Each pump discharges water over- charge of the battery. board via a thru-hull fitting. The 320 Outrage bilge pump system MAINTENANCE: consists of: (1)-1100 GPH pump and The bilge pump is a completely sealed unit and main-... -
Page 40: Section 7-Livewell System
MAINTENANCE: The 320 Outrage is equipped with an 45 Gal. Maintenance of the livewell system will require pe- (170L)livewell bucket that is located aft of the helm pi- riodic inspection of the raw water intake strainer, lot seat. -
Page 41: Section 8-Propulsion System
Special care and attention must be and fittings for wear and/or damage. taken to ensure proper performance of the steering Your 320 Outrage may be equipped system and should include the following: with a teleflex, hydraulic steering sys- •... -
Page 42: Power Steering Information
320 Outrage-Owner’s Manual Power Steering Information The Verado four-stroke engine uses an enclosed hy- Shroud draulic pump unit. The pump is electrically oper- ated to provide hydraulic pressure to the steering system pump. The pump is located in the aft bilge which can be accessed through the hatch in the bot- tom of the motorwell. -
Page 43: Gear Shift & Throttle Control
Digital Throttle/Shift (DTS)® its reactions at speed will make boating for you safer and more enjoyable. Your 320 Outrage has the option of using a state of the art “drive-by-wire”gear shift and throttle control The 320 Outrage is equipped with a system. -
Page 44: Power Trim Operation
Helm Seat Track Maintenance The power trim & tilt system allows you to raise and The helm seats on the 320 Outrage are independently lower the engine(s) outdrive for trailering, launch- adjustable for your comfort. There is a handle on the ing and beaching. -
Page 45: Propeller Information
Disconnect power by moving the battery switch to the not be as efficient. The 320 Outrage uses propellers “OFF” position prior to removing the propeller. that are designed to counter-rotate, which means that NOTICE the port engine’s propeller rotates the opposite di-... -
Page 46: Trim Tabs-Operation/Maintenance
Stainless steel hinge Low voltage electric motor in corrosion-proof casing Wiring to helm mounted switch Electric trim tab switch (w/indicator Optional) 20 Amp Breaker, (located on the main breaker panel). DOWN DOWN Section 9 - Getting to know your Boston Whaler... -
Page 47: Section 9-Getting To Know Your Boston Whaler
The 320 Outrage has (6) 10 inch cleats; two located at sider. the bow, two located amidship and two located at the •... -
Page 48: Hull Maintenance
If blisters are present in the hull; prior to waxing. Check with your Boston Whaler ® they need to be properly cleaned and dried out be- dealer on a compatible rubbing compound for your fore any barrier protection can be applied. -
Page 49: Painted Hull Care (Bottom)
320 Outrage-Owner’s Manual Vinyl Cushion Care Your cushions on the 320 Outrage are made of a du- Make sure that there is enough paint left to cover rable vinyl material called OMNOVA and is protected areas that were not accessible, (slings, jackstands etc.) by a finish called PreFixx. -
Page 50: Engines
ELECTRICAL SYSTEM: in proper working order. If you have stubborn clean- The battery should be removed from the boat. Re- ing cases call your Boston Whaler® dealer for proper move the negative (-) cable first, then the positive cleaning procedures. -
Page 51: Trailer (Optional)
There is a safety chain that attaches to the bow eye and will keep the boat Your 320 Outrage has the option of being fitted with from sliding off the trailer in the event that the winch a galvanized trailer. -
Page 52: Section 10-Anchoring Information
Setting the Anchor There is no best way to set an anchor. Experiment to The 320 Outrage is equipped with an anchor storage see how it performs. One method is to turn the rode compartment located in the bow of the boat. Wind and around a bitt or a cleat and slowly pay out as the boat sea conditions can affect the boat. -
Page 53: Anchor Windlass
320 Outrage-Owner’s Manual Anchor Windlass LOWERING-Pushing the top part of the switch down DANGER will power the anchor windlass DOWN. Make cer- Use the anchor windlass switch on the helm when tain that the anchor lanyard carabiner is detached possible. Use care when operating the anchor wind- from the chain and is clear of any moving parts of lass with the hand-held remote. -
Page 54: Section 11-Maintenance Log & Notes
320 Outrage-Owner’s Manual After the scheduled services are performed, fill out the areas below. Maintenance Record E n g i n e Serviced Maintenance Performed D a t e H o u r s Notes Section 11 - Maintenance Log & Notes... - Page 55 320 Outrage-Owner’s Manual ACTIVE DECK SUSPENSION SYSTEM OPERATION MANUAL Section 12 - ADSS...
- Page 56 320 Outrage-Owner’s Manual ADSS The Active Deck Suspension System (ADSS) is a The system consists of three main components: A) The main suspension chassis located beneath the revolutionary, patented shock absorption system helmsman. designed to drastically reduce the amount of impact loading felt by the passengers on the boat.
