Summary of Contents for ARKY CORE PLUS
- Page 1 MANUAL...
-
Page 2: Table Of Contents
Changing the pinlock code after attachment Attachment/location Step-by-step instructions for attachment Schematic view of attachment Power adapter 10 Pictograms/stickers Opening the ARKY Core Plus 2 Closing the ARKY Core Plus Step-by-step instructions for emergencies After using the AED Maintenance and cleaning Specifications... -
Page 3: General Information
• Take into account the minimum clearance space and applicable fire safety regulations. • Always keep the area under the ARKY Core Plus clear. • Do not fit the ARKY Core Plus ARKY Core Plus close to adiators or other sources of heat. -
Page 4: Installation
Always state the type designation and serial number when contacting customer service or your supplier. PLEASE NOTE Never fit the ARKY Core Plus in full sunlight. It should ideally be situated in a shaded location on a flat wall. Take into account the minimum clearance space and applicable fire safety regulations. -
Page 5: Setting The Pinlock Code
Changing the pinlock code PCB reset button PLEASE NOTE Press code To use the pinlock, the ARKY Core Change the code before suspending the cabinet. When setting a new code, the Press ok Plus must be powered by a suitable cabinet must be supplied with power. -
Page 6: Changing The Pinlock Code After Attachment
Remove the (opened) cabinet from the to which the ARKY Core Plus is wall. The cabinet can be lifted slightly to being fitted. The minimum bearing allow it to be removed from the wall. -
Page 7: Step-By-Step Instructions For Attachment
PLEASE NOTE 9 Route the power cable through the cable inlet and feed through as far as possible. a Never fit the ARKY Core Plus in full sunlight. It should ideally be situated in a shaded location on a flat wall. -
Page 8: Schematic View Of Attachment
(with enclosed fixing materials) The minimum voltage requirements for building-related installation: 100 - 240 V/AC, 50/60Hz. Never place the power adapter outside. 13 If the ARKY Core Plus has been connected correctly, the LED strip in the cabinet will A Wall light up. -
Page 9: Power Adapter
10 Pictograms/stickers 2 ARKY Core Plus 3 Power adapter Always place the power adapter inside • Only connect the ARKY Core Plus to a power source/mains grid that can be switched off and locked (always disconnect the power supply for maintenance and/or troubleshooting). -
Page 10: Use
U S E Opening the ARKY Core Plus 2 Closing the ARKY Core Plus Open the ARKY Core Plus The base moves down Centre the AED on the Place a hand on either side of the base and push upwards until the base locks firmly into by entering the correct automatically. -
Page 11: Step-By-Step Instructions For Emergencies
7 Follow the instructions on the AED Cleaning the ARKY Core Plus • Clean the surfaces of the ARKY Core Plus with a soft, damp cloth. Do not use chemical- based products or cleaning agents as these may damage the cabinet’s plastic enclosure. -
Page 12: Specifications
Alarm Power supply/voltage limits If the correct code is entered on the pinlock Power adapter: (when the ARKY Core Plus is powered by Meanwell GST120A24-P1M a suitable power supply), the cabinet will open and an acoustic alarm will sound. Input: 100-240VAC, 50/60Hz The alarm will switch off automatically Output: 24V –... - Page 13 ARKY +31 (0)50 31 16 085 Verlengde Bremenweg 12 sales@arkycase.com 9723 JV Groningen www.arkycase.com The Netherlands...
