Smart-Bus SB-DN-D0403 Instruction Manual

SB-DN-D0403
Leading Edge Dimmer 4Ch 3A
Instruction Manual
Features
4 x 3A Leading Edge Dimming
Suitable for use with incandescent
lamps and most types of dimmable
electronic transformers, Total box Load
is 10 A
Surge Protection
Each module has capacitors and
voltage-sensitive resistors for surge
protection power line
Green Product
Bus enabled , Powered by 15-32 VDC
Consumption 30mA/24VDC
Data line Short Protection
Protection for Bus Power Polarity
Change, or connect to data terminal
Broadcast Address Button
To broadcast the Module Address to
the Programming software
Life statues LED
LED Indicator, blinking to indicate that
Module powered and bus connected
Areas and Scenes
Up to 4 independent areas, each with
up to 12 scenes, with Fade time of 0
seconds to 60 minutes
Channel Maximum Level
Low threshold, high threshold and
maximum threshold available to suite
different loads of each channel.
Single Phase Input 85-260 VAC
1 phase at 10A
Frequency 50/60 HZ
Suitable for 220 / 110 VAC Lighting
Over Heat Protection
Big Heat sink with Built in temp sensor
when temp exceed 81±2 C, module will
limit output to 80% of original
Overload Protection
Each channel
replaceable 4 A time delay fuse.
Emergency bypass switch
4 Momentary Button to switch each channel
ON/OFF
LED Indicator
To Indicate the Channel statues ON or
OFF
Simple Installation
Din Rail Mount, Standard 35mm guide
rail mounting , with Elegant Plastic
Labeling Tag for Module Name
Sequence Feature
Up to 6 Sequence of 12 steps each 1.0
to 60 minutes With Optional steps times,
and Running modes.
Restore Function
Device restored to previous scene or
Specific scene after Power Restore to
the Module
