Frigidaire FFU20IC8CW1 Factory Parts Catalog

Upright freezer

Download this manual

PRODUCT NO.

BASE MODEL NO.

FFU20IC8CW1

FFU20IC8CW

MARKET

North America

WIRING DIAGRAM - # 216917400

OWNER'S GUIDE - # 216802800 / ENERGY GUIDE - # 216795508

SERVICE DATA SHEET - # 216917400

ELECTROLUX HOME PRODUCTS, INC.

P.O BOX 212378, AUGUSTA , GA 30917

FACTORY PARTS CATALOG

SERIES

COLOR

134A

white

Publication No.

5995392056

030623

-EN/SERVICE /MLR

365

FREEZER

VOLTS

115

UPRIGHT FREEZER

Model number:

FFU20IC8CW1

Page 1 PRODUCT NO. BASE MODEL NO. FFU20IC8CW1 FFU20IC8CW MARKET North America WIRING DIAGRAM - # 216917400 OWNER’S GUIDE - # 216802800 / ENERGY GUIDE - # 216795508 SERVICE DATA SHEET - # 216917400 ELECTROLUX HOME PRODUCTS, INC. P.O BOX 212378, AUGUSTA , GA 30917...
Page 2 Publication No FFU20IC8CW1 5995392056 DOOR P08D0366 06/03...
Page 3 POS. NO 79 # # = Fast-moving Parts * = Non-Illustrated Parts FFU14FC4CW1 DOOR PART NO DESCRIPTION 216522312 Gasket-door,white 5303925107 Lock Assy 216702900 Key,lock 216528113 Panel-inner door,frzr 216531230 Panel-outer door,white 5303271076 Door Stop 5303313518 Washer,sealing 216893400 Handle 218755503 Screw-shoulder,#10 AB ,handle mounting 5303269745 Nut-anchor,door hdl screw 5303271077...
Page 4 5995392056 138A 06/03 CABINET 137A P08C0650...
Page 5 POS. NO 13 # 14 # 16 # 21 # 137A 138A # = Fast-moving Parts * = Non-Illustrated Parts FFU14FC4CW1 CABINET PART NO DESCRIPTION 216503100 Screen-drain 216325600 Fan Blade 216604100 Breaker Kit w/corners 216603600 Breaker Kit w/corners,lock catch 216603300 Breaker Kit w/corners,32"...
Page 6 5995392056 06/03 SYSTEM P08S0347...
Page 7 POS. NO 14 # 15 # 15A# 54 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts FFU14FC4CW1 SYSTEM PART NO DESCRIPTION 5300083897 Condenser 5308000110 Strap-evap/heater,aluminum ,(2) 216634500 Drier-filter 216888700 Harness-main 216730700 Heater-defrost 216737300 Evaporator 216783200 Heat Exchanger,suct/cap tube 216727600 Insulator-evap,styrofoam 216727700...
