ABS Air/ Water Hose Reel Enclosed 3/8" x 10m
HRAWE3815
⚠
Read the following precautions and instructions before you begin the assembly or using.
Keep these instructions in a convenient location for future reference.
OPTIONAL
Simple quick stuck bracket
The quick stuck bracket can
be fixed to the walls or ceilings
easily
STM AUSTRALIA
T 1300 131 531
1/615 WARRIGAL RD
F 1300 308 508
ASHWOOD VIC 3147
E ENQUIRIES@STM.NET.AU
AUSTRALIA
W WWW.STM.NET.AU
PRODUCT SIZE
346mm
High Quality Germany Flexible Hose
High strength ABS engineering plastics cover
• ABS Plastic outer casing
• Complete with pivot bracket
• Provided with hose ratchet stop device
• Easily removable if constant traction is required
• Fully enclosed structure, light, anti dust and corrosion resistance
• Special material coil spring, pull close freely
• Brass joint and durable
Hose I.D.
Hose Length
Working Pressure
Inlet Connection
Outlet Connection
Hose Type
153mm
3/8" (10mm)
10M
30 bar / 435 PSI
F3/8" G
M3/8" G
Germany Flexible Hose
9mm
77mm
Advertisement
Table of Contents
Related Manuals for STM HRAWE3815
Summary of Contents for STM HRAWE3815
- Page 1 ABS Air/ Water Hose Reel Enclosed 3/8" x 10m HRAWE3815 High Quality Germany Flexible Hose High strength ABS engineering plastics cover • ABS Plastic outer casing • Complete with pivot bracket • Provided with hose ratchet stop device • Easily removable if constant traction is required •...
- Page 2 HRAWE3815 ABS Air/ Water Hose Reel Enclosed 3/8" x 10m WARNING Before use, please note and understand all the contents of the specification, before you use it. Internal containing spring, Prohibit non professional personnel to open, failure to comply with these instructions could result in personal injury or property damage.
- Page 3 HRAWE3815 ABS Air/ Water Hose Reel Enclosed 3/8" x 10m PARTS LIST AND DIAGRAM Part Number Description Part Number Description Self-tapping ST3*12 Plastic gear Side cover Lock nut M6 Retainer Self-tapping ST3*12 Valve body Left drum cover O-ring Shaft Valve cove...
