Air Operated Waste Oil Drainer
Instruction Manual
WARNING:
Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety
rules and other basic safety precautions may result in serious personal injury.
Save these instructions in a safe place and on hand so that they can be read when required.
Keep these instructions to assist in future servicing.
Advertisement
Related Manuals for STM DITI AOD3090E
Summary of Contents for STM DITI AOD3090E
- Page 1 Air Operated Waste Oil Drainer Instruction Manual WARNING: Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Save these instructions in a safe place and on hand so that they can be read when required. Keep these instructions to assist in future servicing.
-
Page 2: General Safety Regulations
GENERAL SAFETY REGULATIONS WARNING: The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions or situations that could occur. It must be understood by the operator that common sense and caution are factors that cannot be built into this product, but must be supplied by the operator. -
Page 3: Technical Details
TECHNICAL DETAILS Item No. DITI AOD3090E DITI AOD3065E 1/4"quick plug 1/4"quick plug Air inlet Extension funnel 90L/24Gal 65L/17Gal Capacity 1 bar/14.5psi 1 bar/14.5psi Max draining pressure 2000mm/78.7" 2000mm/78.7" Draining hose length 18L/4.8Gal 18L/4.8Gal Collection bowl capacity 606mm/23.8" 606mm/23.8" Extension funnel diameter... - Page 4 Fig.1: Insert the tube(N) into Fig.2: Assemble the handle(B) Fig.3: Assemble the supporting the reservoir, then turn the and the air inlet fitting, turn off tube, ball valve (P), oil handwheel(O) clockwise the ball valve(H). collecting bowl, filtrating plank direction and tighten. and extension funnel orderly.
-
Page 5: Limited Warranty
DRAINING Fig.6: Close all the valves Fig. 7: Connect the air supply. Fig.8: Open the valve (H) for (P、H、I), put the spout (M) draining. into the waste oil tank, then open the valve (I). H(Open) (Close) (Close) 1 bar I(Open) LIMITED WARRANTY 1. - Page 6 EXPLODED AND PARTS LIST Part No. Description Q'ty Part No. Description Q'ty Oil collecting bowl assembly Ball valve Reservoir Quick plug Tool tray Discharging hose assembly Safety valve #：Optional accessories *：Wearing parts...
- Page 7 OIL COLLECTING BOWL ASSEMBLY & PART LIST 1-14 1-13 1-12 1-11 1-10 Part No. Description Q'ty Part No. Description Q'ty Check nut Supporting tube Compression spring *1-9 Ball valve *1-3 O-ring 1-10 Sealing bush 1-11 Retainer sleeve *1-5 O-ring 1-12 Oil collecting bowl Expansion cover 1-13...
- Page 8 Butterfly valve 2-12 Elbow Swivel fitting 2-13 Bolts 2-14 Tube with lable Wheel 2-15 Clip Caster #：Optional accessories *：Wearing parts T 1300 131 531 STM AUSTRALIA F 1300 308 508 1/615 WARRIGAL RD E ENQUIRIES@STM.NET.AU ASHWOOD VIC 3147 W WWW.STM.NET.AU AUSTRALIA...
