GasFinder2 Operation Manual
July 17th 2017
BOREAL LASER INC.
GasFinder2
P o r t a b l e S y s t e m
Operation Manual
Menu ver. V1.10.c
Part No. NDC-200023-C
12846 146 Street NW • Edmonton, Alberta • CANADA • T5L 2H7
Phone: +1 780 488 5173 • Fax: +1 780 488 0780 • www.boreal-laser.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GasFinder2 and is the answer not in the manual?

Questions and answers

Related Manuals for BOREAL LASER GasFinder2

Summary of Contents for BOREAL LASER GasFinder2

  • Page 1 Boreal Laser Inc. GasFinder2 Operation Manual July 17th 2017 BOREAL LASER INC. GasFinder2 P o r t a b l e S y s t e m Operation Manual Menu ver. V1.10.c Part No. NDC-200023-C 12846 146 Street NW • Edmonton, Alberta • CANADA • T5L 2H7...
  • Page 2 Boreal Laser Inc. makes no representations or warranties with respect to the contents of this document. Boreal Laser Inc. assumes no responsibility for errors or omissions or any damages resulting from the use of the information contained in this document. Information in this document is subject to change without notice.
  • Page 3 • Refer all servicing to qualifi ed personnel only. The equipment contains no user servicable parts. Disclaimer Boreal Laser Inc. assumes no liability or responsibility for issues or harm resulting from the use of this equipment.

  • Page 4: Table Of Contents

    Boreal Laser Inc. GasFinder2 Operation Manual July 17th 2017 BOREAL LASER INC. BOREAL LASER INC. GasFinder2 O p e r a t i o n M a n u a l Contents Section 1. System Description ..................1.1 Specifi cations ....................... 1.3 GasFinder2 ..........................
  • Page 5 Appendix K — Accessories ..................9.15 Section 10. Drawings ..................... 10.1 1.Universal Enclosure base – PK1023UE – A Rev. D ..........10.3 2.GasFinder2.0 Enclosure – JB0102UE – Rev. Rev A ..........10.5 3.GasFinder2.0 Dimensions – GF-D-3D-0003 – A ............. 10.7...
  • Page 6 Boreal Laser Inc. GasFinder2 Operation Manual July 17th 2017 Plastic Enclosures Power Supply Battery Roof line installation in a fi xed location Measuring through a duct Measuring on smelter fl oor Measuring landfi ll gas...
  • Page 7 Boreal Laser Inc. GasFinder2 Operation Manual July 17th 2017 Large X-Y Mount for Small X-Y Mount for tripod fi xed location Thermostat Cold Air Diffuser Air Valve Air Inlet Vortex Cooler Air Filter Vortex Cooler with GasFinder2 GasviewOP Software Display...
  • Page 8 Extended warranty is available, see your Boreal Laser Inc. sales contact for information. Procedure for returning the GasFinder2 If the unit has to be returned for service or repair, please contact Boreal Laser Inc. for a return material authorization (RMA) number and form. An email will be sent containing complete instructions on how to package the unit and containing a shipping address.

  • Page 9: Section 1. System Description

    It is possible to alter some of the parameters of the GasFinder2 remotely by using the GasViewOP software or another terminal program. These can be conected with the GasFinder2 using...
  • Page 10 • Retrorefl ectors (Retros) are passive units and refl ect the laser signal back to the GasFinder2. For short distances (up to 50m), refl ective tape can be used. For greater distances gold plated, corner cube retros should be used.

  • Page 11: Specifi Cations

    Boreal Laser Inc. GasFinder2 Operation Manual — System Description July 17th 2017 Specifi cations GasFinder2 Weight 5.2kg (11.5lbs) Dimensions (L x W x H) 290 x 195 x 150mm (11.4 x 7.7 x 5.9 inches) See Section 10 Power Requirements...

  • Page 12: Accessories

    (conforms to Class 1 as per IEC 60825-1) and will not damage eye tissue. However, it is the recommendation of Boreal Laser Inc. that, as with ANY LASER SYSTEM, the user/ operator should avoid staring directly into the output aperture of the instrument.

  • Page 13: Section 2. Pre-Installation Checks

    12V battery or a power supply module which converts the local supply voltage (110V/220VAC) to 12VDC. • Accessibility : safe access to the rear of the GasFinder2 should be possible. • Path : locations should be chosen such that a line of sight path to the proposed refl ector location is unobstructed by traffi...

  • Page 14: Tools And Equipment

    Boreal Laser Inc. GasFinder2 Operation Manual — Pre Installation July 17th 2017 Tools and Equipment A. Required: • Site-specifi c personal protective equipment. • Set of assorted cable ties if cabling is required. • Ladder and/or man-lift (as appropriate). B. Optional/Recommended: •...

  • Page 15: Section 3. Installation

    Note that the laser beam is infra-red and is not visible to the eye. Sequence of the Installation: The preferred sequence is to install the retro refl ector fi rst and then the GasFinder2. This ensures that when the GasFinder2 is mounted, it can be aligned at the same time.
  • Page 16 fi tting on the top of the X-Y mount. There will be an audible click when the attachment is secure. 9. Use the swivel mount to align the GasFinder2 roughly with the retro and then tighten the locking screws on the rotating base.

  • Page 17: Fixed Location

    Boreal Laser Inc. GasFinder2 Operation Manual — Installation July 17th 2017 Fixed Location Retrorefl ectors (Retros) The retrorefl ector is a vital part of the system and choosing the correct type is necessary for the correct operation of the system. Refer to page 3.4 for details on choosing a retro.
  • Page 18 Window materials will depend on the site conditions and the gas to be measured. Lexan is normally supplied but window glass, boro-silicate and sapphire are used under specifi c circumstances. Contact Boreal Laser Inc. for more information.

  • Page 19: Gasfinder2

    Concrete Column 2. Open the GasFinder2 carrying case and attach the alignment scope to the channel on the top of the GasFinder2 with the thumb screws attached to the scope (the scope end with the adjusting ring faces the operator).

  • Page 20: General

    Light Value / Distance item. • Using the continuous red beam now being emitted from GasFinder2, the X-Y mount can be adjusted so that the red beam is refl ected back from the retro. • As soon as the Light Value indicates a reading above 100, the visible laser use can be discontinued and the maximisation of the Light Value reading used for precise alignment.

  • Page 21: Adjusting The Aiming Scope

    Boreal Laser Inc. GasFinder2 Operation Manual — Installation July 17th 2017 Adjusting the Aiming Scope Aiming Scope Cross Hairs If the cross hairs on the scope do not line up with the Cross Hair Adjustments Focus centre of the retrorefl ector, they can be adjusted by...

  • Page 22: Divergence

    July 17th 2017 Divergence The laser beam, when it is emitted from the GasFinder2, is about 1.5mm in diameter. It diverges at about 1.5 milli-radians, so at 100m the diameter of the beam is 150mm and at 600m the diameter is about 1m. This divergence allows for a small movement of the Gasfi...

  • Page 23: Section 4. Data Input/Output

    Boreal Laser Inc. GasFinder2 Operation Manual — Data I/O July 17th 2017 Section 4. Data Input/Output DB15 Connector Signal Signal PCDSR PCRX PCRTS PCTX PCCTS PCDTR +5VDC RCVR Data I/O connector Ramp Monitor as viewed on rear panel I sink (-)

  • Page 24: Serial Communications

    July 17th 2017 Serial Communications The GasFinder2 will transmit serial data at 300 / 1200 / 2400 / 4800 / 9600/ 19200 / 38400 / 57600 / 115200 / 230400 baud, no parity, 8 bits, one stop bit, (i.e., 9600,N,8,1) after each scan.

  • Page 25: Date And Time Fi Elds

    When data is viewed using HyperTerminal or any similar data terminal program, the extension is .txt and the data is a true representation of the raw data from the GasFinder2 where the $GFDBG string does not have a date and time fi eld.

  • Page 26: Data Transmission

    July 17th 2017 Data Transmission The data cable carries the RS232 signal from the GasFinder2 to the computer which stores and displays the data. The cable length should not exceed 30m. If a longer distance is required, other options are available: This is the standard output and allows a twisted pair of wires 1.

  • Page 27: Downloading Data

    GasFinder2 Operation Manual — Data I/O July 17th 2017 Downloading Data The serial data from the GasFinder2 can be viewed using a computer that has a serial port. Boreal Laser Inc. has developed the GasViewOP program to view and log the data. This program is described fully in the GasViewOP manual.

  • Page 28: 4-20Ma Details

    Boreal Laser Inc. GasFinder2 Operation Manual — Data I/O July 17th 2017 4-20mA details Note that in a dual gas system, Gas B does not have a 4-20mA output. • 4 mA is equivalent to the lowest value of gas programmed, usually 0 ppmm.

  • Page 29: Section 5. Operating Instructions

    Section 5. Operating Instructions Start Up 1. These start up instructions assume that the GasFinder2 has been set up in accordance with the procedures specifi ed in Section 3, and the unit is connected to the power supply and pointing at a retrorefl ector.
  • Page 30 ESC key. The display will now show the entered distance. Note that the GasFinder2 does not measure the distance to the retrorefl ector. The distance, in metres, must be entered manually. It is measured from the front panel of the Gasfi...

  • Page 31: Menu Details

    This item is explained in detail on page 5.2, item (f) in this manual. 4. Path Temperature: Set this value to the average temperature Path Temperature of the path between the GasFinder2 and the retro. Celcius 5. Altitude: Set this value to the Altitude of the path above sea Altitude level.
  • Page 32 Gas Detection Limits 9. Gas Detection Limits: this item shows the limit for the gas ppmm concentration. This item is only displayed when the GasFinder2 has a dual gas system. Min. acceptable R2 10. Min acceptable R2: this item allows the user to specify the value of the confi...
  • Page 33 Hyperterminal. For a large download the baud rate on both the GasFinder2 and the computer should be set to a high value in order to keep the memory download time to a reasonable level.

  • Page 34: System Menus

    Internal Arrays Xfer allows the instrument’s internal array <enter> confi guration and various other parameters to be downloaded to a fi le. The operator can transmit this fi le to Boreal Laser Inc. for analysis. 16.Sample / ref. scan: this item selects the number of times Sample / ref.
  • Page 35 If the voltage falls below 11.5V, a fl ashing ‘B’ will appear in the Battery Voltage ‘B’ top right corner of the display. If the voltage falls below 11.0V the GasFinder2 will shut down 11.4 to protect the electronics. The data will be stored and can be retrieved when power is restored.

  • Page 36: 31.Password Protected Menus

    Boreal Laser Inc. GasFinder2 Operation Manual — Operating Instructions July 17th 2017 30.Service Menus Service Menus These menus are accessible only for Boreal Laser personnel and Auth Personnel Only their representatives. 31.Password Protected Menus Password Protected These menus are accessible only for Boreal Laser personnel and Menus their representatives.

  • Page 37: Section 6. Maintenance

    July 17th 2017 Section 6. Maintenance GasFinder2 Note. If the GasFinder2 is working correctly it is best to leave it alone while keeping a check on the parameters mentioned below. The GasFinder2 requires little maintenance and there are no user-serviceable parts.

  • Page 38: Retrorefl Ectors

    Gently wipe clean with a dry, soft tissue. These cans are available from camera shops and electronic stores. ™ A suitable anti-static solution is “Novus No.1”, used by plastic fabricators and it can be obtained directly from Boreal Laser Inc.

  • Page 39: Section 7. Troubleshooting

    Solution: - (enter System Parameters, and scroll to the Serial Communications window) Verify that CheckSum is enabled on the Computer and the GasFinder2. Verify that the data cable is connected and the cable is OK (see Appendix H) Check that on the DB15 connector the voltage between pins 5 and 12 is 5V.
  • Page 40 If the display still shows Cal. Err!, collect an Arrays Transfer File (see page 7.3) and send it to Boreal Laser Inc. together with 30 minutes of data from the .gvl text fi le. This will allow Boreal Laser Inc. to diagnose the problem.

  • Page 41: Array Transfers

    July 17th 2017 Array Transfers The internal arrays and the various parameters stored internally in the GasFinder2 are a very important diagnostic tool. In cases of suspected problems with the equipment, if data from an Arrays Transfer File together with 30 minutes of .gvl data are sent (emailed) to <support@boreal-laser.com>, a diagnosis and solution can often be made without the...
  • Page 42 The fi le containing the data can be saved by clicking on File in the top left of the tool bar and saving it to a specifi c location. It can then be sent to Boreal Laser Inc. for diagnosis.

  • Page 43: Stability Of Support Structures

    July 17th 2017 Stability of Support Structures The diameter of the laser beam when it exits the GasFinder2 is about 1.5mm and the divergence is approximately 1.5mrad (milliradians). This means that at a distance of 100m the beam diameter is 1.5 x 100 = 150mm (6”). Similarly, at a distance of 1,000m, the beam diameter would be 1,500mm (59”).

  • Page 44: Types Of Supports

    Note that guy wires can sometimes oscillate and cause movement. Platform Separation Note: It is critical that the platform for the GasFinder2 is not connected to the same platform that the operator stands on GasFinder mounted separately from for installation or maintenance work.

  • Page 45: Alignment Procedures For A Moving Building

    This is seen, especially on sunny days, as a diurnal variation in the GasFinder2 light level. This variation is caused by the expansion and contraction of the metal structure carrying the laser mount, which twists with respect to the longitudinal axis of the original laser path.
  • Page 46 At 400m, the diameter of the beam is about 600mm, so the area of the beam may be larger than the enclosure. To fi nd the edges of the beam, the GasFinder2 has to be traversed horizontally and vertically until the light level drops.

  • Page 47: Section 8. The Basics Of Laser Gas Detection

    Boreal Laser Inc. GasFinder2 Operation Manual — Tutorial July 17th 2017 Section 8. The Basics of Laser Gas Detection Tuneable Diode Laser Laser is an acronym for: Light Amplifi cation by Stimulated Emission of Radiation In principle, the laser is a tube with a mirror at each end.

  • Page 48: Gas Detection With A Laser

    Boreal Laser Inc. GasFinder2 Operation Manual — Tutorial July 17th 2017 Gas Detection with a Laser Every gas is composed of atoms or molecules. If the target gas is hydrogen fl uoride, then one atom of hydrogen would have combined with one atom of fl uoride to give one molecule of hydrogen fl...

  • Page 49: Retrorefl Ectors

    Boreal Laser Inc. GasFinder2 Operation Manual — Tutorial July 17th 2017 Retrorefl ectors The laser beam is transmitted to a retrorefl ector made with a special type of corner cube arrangement. This causes the signal to be refl ected directly back to the detector in the transmitter enclosure.

  • Page 50: Glossary Of Common Terms And Abbreviations

    Boreal Laser Inc. GasFinder2 Operation Manual — Tutorial July 17th 2017 Glossary of Common Terms and Abbreviations. absorption lines Dark lines in the spectrum due to absorption of the light. absorption wavelength The wavelength at which a gas absorbs light.

  • Page 51: Appendix A - Menu Structure

    Boreal Laser Inc. GasFinder2 Operation Manual — Appendices July 17th 2017 Appendix A — Menu Structure GasFinder2 Warm_up GasFinder2 Warm_up Appendix A Menu Structure Ver. 1.10.c HF 60 Ver. 1.10.c CO2 120 ppmm Calibrating Calibrating Low Light ppm HF Light...
  • Page 52 Boreal Laser Inc. GasFinder2 Operation Manual — Appendices July 17th 2017 This page left intentionally blank.

  • Page 53: Appendix B - Status Codes

    GasFinder2 Operation Manual — Appendices July 17th 2017 Appendix B — Status Codes When the GasFinder2 is used in conjunction with ‘Hyperterminal’ or Boreal Laser’s ‘GasView2’ data-logging program, the data stream which is sent to the fi le is as follows: $GFDTA 122.8...

  • Page 54: Appendix C - Explanation Of Ppmm

    10 ppm. A point sensor measures directly in ppm. Open path monitors, like the GasFinder2, measure the total amount of a specifi c gas, for example HF, in the path of the laser beam between the transmitter unit and a refl ector.

  • Page 55: Appendix D - Explanation Of R2

    This is the sample waveform. The GasFinder2 also has a similar signal from the stored waveform of the calibration gas. These curves are then digitised and compared as two numeric arrays.
  • Page 56 Boreal Laser Inc. GasFinder2 Operation Manual — Appendices July 17th 2017 Explanation of R (continued) A typical plot of concentration versus R will give the following graph: With lower levels of sample gas, the R decrease, and equal zero when there is no gas present.

  • Page 57: Appendix E - Conversion From Ppm To Mg/Nm3

    Boreal Laser Inc. GasFinder2 Operation Manual — Appendices July 17th 2017 Appendix E — Conversion from ppm to mg/nm (Parts per million to milligrams per normalised cubic metre) In this example Hydrogen Fluoride (HF) is used to illustrate the conversion.

  • Page 58: Appendix F - 2-Way Serial Communication

    July 17th 2017 Appendix F — 2-Way Serial Communication All GasFinder2 gasfi nders with software version 1.09b(July 2012) or later have the ability to be controled remotely with commands passed through the data cable. This cable requires three conductors and is marked with a yellow band. The remote control enables the user to alter various parameters without entering the menu in the GasFinder2 with the ensuing time delay while the system recalibrates.

  • Page 59: Appendix G - Calibration

    GasFinder2 Operation Manual — Appendices July 17th 2017 Appendix G — Calibration The GasFinder2 is shipped already calibrated and does not require any calibration in the fi eld. The calibration of the GasFinder2 is done by passing a known concentration of gas through a test cell, which is placed in the path of the laser beam.

  • Page 60: Appendix H - Cables

    Appendix H — Cables Cable Connections, Data The data cable carries the RS232 signal between the GasFinder2 and the computer, which stores and displays the data. It also enables the GasViewOP program to alter various parameters in the GasFinder2 remotely. The cable supplied by Boreal Laser Inc. is marked with a yellow band, The cable length should not exceed 30m.

  • Page 61: Appendix I - Log To Memory

    Clear Memory Log: Pressing Ent will erase all data stored in the memory. Switching the GasFinder2 off does not erase the data. Data can only be erased using Clear Memory Log.
  • Page 62 ‘Average Window’ should be calculated and entered. When the GasFinder2 is in Menu Mode, the data output is set automatically to once per sample. This can appear confusing if the Average Interval is set to a value other than one.

  • Page 63: Appendix J - Remote Data Transmission

    July 17th 2017 Appendix J — Remote Data Transmission In some circumstances it may be convenient to send the data output of the GasFinder2 to a computer which is not connected directly to the GasFinder2. For this purpose Boreal Laser Inc.

  • Page 64: Appendix K - Pre-Ship Parameterss

    Boreal Laser Inc. GasFinder2 Operation Manual — Appendices July 17th 2017 Appendix K — Pre-Ship Parameters Pre-Ship Checkout Sheet for GasFinder 2.0 Aug 2012 Checked by Date Serial # Software version Coldfire v1.10.c Main Menu Setting Password Protected menu Setting Concentration Units Ref.

  • Page 65: Appendix K - Accessories

    Boreal Laser Inc. GasFinder2 Operation Manual — Appendices July 17th 2017 Appendix L — Accessories GasFinder2 Power Supply Aiming Scope Battery Range Finder binocular Battery Cable GasFinder2 Manual Battery Charger Calibration Documentation Power Supply (Single channel) Power Supply ( Dual Channel) Software Power Supply (Class1, Div.2 DIN Rail mount...
  • Page 66 Boreal Laser Inc. GasFinder2 Operation Manual — Appendices July 17th 2017 9.16...

  • Page 67: Section 10. Drawings

    Boreal Laser Inc. GasFinder2 Operation Manual — Drawings July 17th 2017 Section 10. Drawings 1. Universal enclosure base – PK1023UE-A Rev D 2. Universal enclosure – JB0102UE-A Rev A 3. GasFinder2 Dimensions – GF-D-3D-0003-A 10.1...
  • Page 68 Boreal Laser Inc. GasFinder2 Operation Manual — Drawings July 17th 2017 This page intentionally left blank. 10.2...
  • Page 70 Boreal Laser Inc. GasFinder2 Operation Manual — Drawings August 2011 This page intentionally left blank. 10.2...
  • Page 72 Boreal Laser Inc. GasFinder2 Operation Manual — Drawings August 2011 This page intentionally left blank. 10.2...
  • Page 74 Boreal Laser Inc. GasFinder2 Operation Manual — Drawings August 2011 This page intentionally left blank. 10.2...
