Technical Specifications - Fancom FB.1 Manual

4.

Technical specifications

Mains power
Mains voltage
Mains power frequency
Max. Current
Electronic fuses (dim. 5x20mm)
Phase monitoring fuse 4x (dim. 5x20mm)
Input
FB.1
FB.8 /.16
Output
Audio or visual signal
Relay contact
Manual operation FB.1/.8/.16
3-position selector
switch
Reset
FB.8/.16
Battery
Power supply for the audio or visual signal
Housing
Plastic housing type with screw closure
Dimensions (LxWxH)
Weight (unpackaged)
Operating environment
Operating temperature range
Storage temperature range
Relative humidity
D-E circuit (NC contact)
1-2 circuit (NO contact)
8/16 signalling contacts (normally-open (NO) or normally-closed (NC) contacts)
12Vdc via battery (max. 1A.)
1× NO-P-NC, for telephone dialler, for example, 30Vac/60Vdc, max. 2A
1× NO, activates switch in 0 position, 30Vac/60Vdc, max. 2A
0-A-T
Pushbutton for turning the audio or visual signal off
8/16 switches (on-off) for turning on/off
signalling input
1~ 230Vac (-10% - +6%)
3~ + N 230-400Vac (-10% - +6%)
50/60Hz
1~ 25mA
Type slow, 50mA
Type slow, 4A
12Vdc - 1.2Ah
IP54
300×240×140mm
FB.1 2.75 kg
FB.8 2.9 kg
FB.16 3.0 kg
0°C to +40°C
-10°C to +50°C
< 95%, not condensing
9
