Summary of Contents for Outdoors MG880
- Page 4 Mounting Brackets, MG880 Marine Grill Connecting Gas Line Or Bottle Adapter, All Models For Stand Alone Operation: For Coach Connection: Remove pins holding Locate hose connecting arms in position. fuel system from coach. Rotate arms as shown. Slide retaining sleeve ...
-
Page 5: Horizontal Position
Horizontal Position Tabletop Position (See Figure A) (See Figure B) Hang bracket on white aluminum mounting strip located on Open 2 folding arms on bracket, make sure they lock in side of RV. position. Open 2 folding arms on bracket, make sure they lock in ... -
Page 6: Lighting Your Grill
Lighting Your Grill Burner Flame Pattern NOTE: Follow the setup instructions prior to using your grill. The Side-Kick burner has been factory set for the correct air and gas mixture. The correct flame pattern is shown below. Check to make sure the control knob is in the OFF position. ... - Page 7 Re-Lighting Your Side-Kick Removing Burner and Venturi Tube Should your burner flame be accidently extinguished. Turn Side-Kick bottom side up. Remove screw “B”(see diagram below) Do Not Lose Washer. Immediately make sure the control knob is in the OFF position. Turn nut “A”...
-
Page 8: Parts Breakdown
Valve Assembly Handle Assembly (1 of 3) (comes with all hardware) Bracket Assembly If parts not listed here have failed then the grill must be replaced. When calling Outdoors Unlimited for parts, please provide the model number and name of part. -
Page 10: Maintenance
The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of ½ psi (3.5kPa). Outdoors Unlimited 2101 Industrial Parkway The appliance must be isolated from the gas supply piping system...
