Tip Flicker
Ejector Sleeve
Nozzle
Model
Information
To Pick Up Ovation
1. Allow body to fill your palm
2. Rotate adjustable hook
To Install a Tip
1. Insert nozzle into tip
2. Lightly press down until
a "click" is heard
F1
See www.vistalab.com for Operator's Guide with complete instructions.
Plunger
Calibration Set Screw
Body
Volume Indicator
to rest comfortably on
your forefinger
Quick Reference Guide for
F2 Fixed-Volume Pipettes
&
Hook
To Aspirate & Dispense
1. For one stroke pipettes, fully depress plunger to
the bottom and for two stroke pipettes, depress
plunger to the 1st stop.
2. Place tip in sample and release plunger
3. Wait one second, then remove tip from sample
4. For one stroke pipettes, fully depress plunger to
the bottom. For two stroke pipettes, depress
plunger to 1st stop, wait one second and then
fully depress plunger.
To Eject a Tip
1. Point nozzle down
2. Press Tip Flicker
