- Page 1 ENOITALIA S.r.l. Instructions for use and technical manual Self-priming electric pumps “EURO” Enoitalia S.r.l. Via Provinciale Pisana, 162 Fraz. Pieve a Ripoli 50050 Cerreto Guidi- (FI) Tel: 0571 588031 Fax: 0571 588080 www.enoitalia.net e-mail: info@enoitalia.net...
- Page 2 This manual contains information on the reception, installation, operation, assembly, disassembly and maintenance of the Enoitalia electric pump. Enoitalia reserves the right to modify this manual without notice. INSTRUCTIONS FOR STARTER This manual contains useful information for the use and management of your pumps.
- Page 3 EC Declaration of Machinery Conformity Manufacturer and seller of the machine ENOITALIA s.r.l. Via Prov. Pisana, 162 Cerreto Guidi (Fi) MODEL SELF-PRIMING ELECTRIC PUMP Year of manufacture: 2018 The undersigned company hereby DECLARES at its own responsibility that the machine which this declaration refers to complies with the provisions of : ...
-
Page 4: Type Of Pump
TYPE OF PUMP: BELTED WITH TROLLEY COAXIAL - MECHANICAL VARIATOR - ELECTRONIC VARIATOR... - Page 5 1. DESCRIPTION The self-priming electric pump with rubber impeller is suitable for the transfer of delicate food liquids even in the presence of suspended bodies (such as wine, milk, oil, de-stemmed grapes, fruit juices), and a wide range of chemical substances. The electro pump is able to work in both directions of rotation.
- Page 6 indispensable, it is necessary to use only products that comply with current safety standards, respecting the flow limit in current value and maximum power. Pipe connection: the pipes must be rigid and reinforced, and must be fixed to the pump by means of special clamps, avoiding the formation of bottlenecks that could prevent the regular flow of the liquid.
- Page 7 On EURO 20-30-40-50-60 coaxial models with integrated electrical panel, the pump has an inverter installed on the electric motor. In addition to the stop position "0" on the rotation inverter, position 1 (clockwise rotation) and position 2 (counter clockwise rotation) are also indicated. To start the machine, simply turn the inverter in the required direction.
- Page 8 MODELS WITH MECHANICAL SPEED VARIATOR: This type of pump is available only with THREE-PHASE motorization, and has a separate control panel installed on the trolley. For the operation of the panel, see paragraph "Three-phase coaxial models with separate panel". Attached to this manual there is a specific section dedicated to the operation of this type of pumps. MODELS WITH ELECTRONIC SPEED VARIATOR: See specific paragraph at the end of the manual.
- Page 9 To operate the pump, after making the electrical connection, position the rotation inverter at position 1 in the desired flow direction. The pump will start running. When the delivery circuit is closed (usually with a tap or dispensing gun), the pump will continue to run for a few moments until the set pressure is reached. CAUTION: When first used, open the valve located above the buffer tank to allow all the air in the circuit to escape and avoid foam problems.
-
Page 10: Cleaning And Maintenance
3) CONTROL PANEL WITH ON / OFF RADIO CONTROL: This is an accessory available on all three-phase pump models (except EURO 20). On models with electronic variator, a specific radio remote control is provided. The ON / OFF radio remote control simply allows the pump to be switched on and off remotely, even if the direction and speed can not be changed. - Page 11 Check the transmission belts wear Check the sealing gaskets. For replacement, remember to clean both surfaces of the seal with alcohol to remove oil and grease remains Check the bearing Check the lubricating oil in models with speed variator. In case of any repair operations it is necessary to use the original spare parts by contacting the retailer or directly the manufacturer.
- Page 12 Carefully read this manual in its entirety before using the machine, and store it for any future reference The company Enoitalia S.r.l. is not responsible for damages resulting from any changes made by third parties to the machine ...
- Page 13 WIRED REMOTE CONTROL: with power selector and reversing and switching commands, it must be connected to the panel through the appropriate connector. The REMOTE mode must also be selected on the panel to activate operation with the remote control. ...
-
Page 14: Wired Remote Control
GEAR SELECTOR / STOP / INVERSION POTENTIOMETER PANEL CLOSURE WIRED REMOTE CONTROL MOTOR CONNECTOR... - Page 15 TIMER RANGES: Ranges hours da 0.1s a 1s da 0.1 min a 1 min da 0.1h a 1h da 1.0h a 10h da 0.5s a 5s da 0.5 min a 5 min da 0.5h a 5h da 5h a 50h Time range da 1.0s a 10s da 1.0 min a 10 min...
