Matco Tools WBSS75 Quick Start Manual

WARNING
Study, understand and follow all instructions provided with
this product. Read these instructions carefully before
installing, operating, servicing or repairing this tool. Keep
these instructions in a safe, accessible place.
INTENDED USE OF THE TOOL
The Hub & Wheels Bearing Service Set is designed to remove
and install wheel hubs and bearings and remove bearing
races using the tools in this set. Do not modify or replace any
pieces of this kit with foreign parts. Do not use these tools
outside of the designed intent. Never modify the tools for any
other purpose or use.
WARNING
Caution: To help prevent personal injury
• Use of this product can expose you to chemicals including
ethylene glycol, gasoline vapors and engine exhaust, which are
known to the State of California to cause cancer, birth defects, or
reproductive harm. For more information, visit
www.P65Warnings.ca.gov. Always wear ANSI approved safety
equipment, safety glasses and clothing when using this product.
Study, understand, and follow all instructions provided with this
product. Failure to read and follow all warnings and operating
instructions may result in damages and serious injury or death.
• Always wear ANSI approved goggles when using this product.
(Users and Bystanders).
• Never use this tool for any application other than for
which it was designed.
• Only use accessories designed for this tool.
• Never alter or modify this tool in any way.
• Improper operation and/or maintenance of the tool, modification
of the tool, or use of the tool with accessories not designed for it
could result in serious injury or death.
• Always select the correct accessories of the correct size and design
for the job that you are attempting to perform.
• Always work in a clean, safe, well-lit, organized and adequately
equipped area.
• Do not begin repairs without assurance that vehicle is in secure
position, and will not move during repair.
HUB/WHEEL BEARING
SERVICE SET
Made in China
to Matco specifications
Page 1
(M) MIXED WARRANTY
(Lifetime and 1 year)
The manufacturer warrants this product to the original user against
defective material or workmanship for either a period of 1 year or
lifetime dependent on the part number. Ask your distributor for more
details.
The manufacturer reserves the right to determine whether the part or
parts failed because of defective material, workmanship or other
causes. Failures caused by accident, alteration, or misuse are not
covered by this warranty.
The manufacturer, at its discretion, will repair or replace product
covered under this warranty free of charge. Repairs or replacements
of products covered under this warranty are warranted for the
remainder of the original warranty period.
The manufacturer or its authorized service representatives must
perform all warranty repairs. Any repair to the product by
unauthorized service representatives voids this warranty. The rights
under this warranty are limited to the original user and may not be
transferred to subsequent owners.
The warranty is in lieu of all other warranties, expressed or implied,
including warranties of merchantability and fitness for a particular
purpose. Some states do not allow the exclusion or limitations of
incidental or consequential damages, so the above limitations may
not apply to you.
BEFORE USE
When unpacking, check the parts diagram and part number
listing on page 14 to make sure all parts are included. If any
parts are missing or damaged, please call your distributor.
PRODUCT INFORMATION:
Save time. Remove and install hubs, wheel bearings and
bearing races on most FWD, AWD, 4WD and many RWD
with IRS vehicles, all with in kit.
Heavy-duty. 1¼" drive 7/8" Grade 8 drive bolt with oversized
thrust bearing removes wheel bearings with ease.
Adaptable. Adjustable-position forged pulling brace arms
and brake caliper bridge bar allow for fitting around, and
pulling, most hub applications.
Specifications:
Bushing Range:
(Outside Diameter)
Sleeve Sizes:
Sleeve Plate Sizes:
Drive Bolt:
Bolt Rating:
Nut Size:
Hub Puller Adapter Sizes:
Caliper Bridge Brace Bar Size:
DO NOT DISCARD – GIVE TO USER
WBSS75
2.17", 2.32", 2.48", 2.62", 2.76", 2.81",
2.89", 2.95", 3.05", 3.21", 3.27", 3.48"
3" O.D. × 2.56" Long
3.31" O.D. × 2.56" Long
3.62" O.D. × 2.56" Long
4" O.D. × 2.48" Long
3.4" O.D. × 2.72" Step
4" O.D. × 3.2" Step
11" Long × 0.875"/9
SAE Grade 8
2.36" x 0.875" x 1.25 Hex
1.3" O.D. Small Hub Adapter
1.46" O.D. Medium Hub Adapter
1.75" O.D. Large Hub Adapter
5.0" Caliper Bolt Distance
5.5" 2nd Caliper Bolt Distance
1910280-14
