- Page 1 All Day - New Day SPEGELSKÅP MIRROR CABINET SPEJLSKAB SPIEGELKAST SPEILSKAPETS Assembly instructions Montage vejledning Montagehandleiding Monteringsveiledning Remove "badmeubel" Monteringsanvisning...
- Page 2 1) (GB)Fix the aluminium bar to the wall 2) (GB)Hang the mirror cabinet (N)Fest monteringsskinnen på veggen ved hjelp av vater. Skinnen plasseres (N)Heng speilskapet på monteringsskinnen. sentrert. (S)Lyft spegelskåpet och häng upp det på monteringsskenan. (S)Rikta in monteringsskenan på väggen i våg och markera med en penna var (DK)Hægt spejlskabet på...
- Page 3 5) (GB)If you want to change the shelf position, you have to remove the shelf with supports and replace at the requested position. (N)For å endre plassering av hyllene, ta ut hyllene og flytt hyllefestene til ønsket sted. (S)För att ändra placering av hyllorna: Dra hyllorna rakt ut, flytta om konsolerna till önskad höjd och skjut tillbaka hyllorna i konsolerna. (DK)Hvis placeringen af hylderne vil ændres, så...
- Page 4 ALL DAY ALL DAY ALL DAY ALL DAY 1136 ALL DAY 1136 1100...
- Page 5 Ip20 (GB) This product is IP20 rated suitable for installation in ZONE 3. All installation must comply with guidelines which are based on a zonal concept. The diagram above illustrates this concept and must be followed to ensure the safe installation of bathroom lighting. These regulation apply to domestic installation only. Installations must be made in accordance with the current IEE wiring regulations and relevant buildings regulations.
- Page 6 WIRING DIAGRAMS Before any operation ensure the domestic electrical mains supply to which the mirror is being connected is turned off. LED Driver MAIN SUPPLY LUMINARIE a_switch button b_switch socket Wiring Diagram LUMINARIE SWICH BUTTON Live supply is Brown live Live supply is Brown neutral Neutral supply can be Blue or Black...
