- Page 1 All manuals and user guides at all-guides.com CR-AS18 YL(S) SERVICE MANUAL RADIO RECEIVER S/M Code No. 09-997-333-5N1...
-
Page 2: Specifications
All manuals and user guides at all-guides.com SPECIFICATIONS Frequency range FM: 87.5-108 MHz AM: 530-1,605 kHz Maximum output 160 mV (EIAJ 4 ) Power source DC 3 V using two R6 (size AA) batteries Speaker Diameter 57 mm, 4 Z Maximum dimensions 115.5 (W) x 69 (H) x 30 (D) mm Weight... -
Page 3: Electrical Main Parts List
All manuals and user guides at all-guides.com ADJUSTMENT ELECTRICAL MAIN PARTS LIST REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 87-008-462-010 CER,FIL SFT10.7MS23H-A S2-310-010-100 DISCRMINATOR FILTER 10.7MHZ S4-316-190-000 IC,CXA1619AM S1-210-015-301 JACK,HP 3.5MM S1-110-013-900 COIL,AIR FM 3-5.5-0.5 87-003-108-010 COIL,0.68UH DIODE... -
Page 4: Schematic Diagram
All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM A MAIN C.B L7,TC4 L3,TC1 L2,TC2 L5,TC3 AM TRACKING ADJ. FM TRACKING ADJ. FM FREQ.RANGE ADJ. AM FREQ.RANGE ADJ. PVC1(TC1~4,VC1A~D),VC1A~D TUN L7(AM BAR ANT.) 10uF/10V FM ANT. VC1D VOL1 50KB 3.3uF/50V R6(AA)X2 FRONT END 10MHz... - Page 5 All manuals and user guides at all-guides.com WIRING...
-
Page 6: Mechanical Exploded View
All manuals and user guides at all-guides.com MECHANICAL EXPLODED VIEW 1/1 POINTER, COVER PVC, COVER MAIN CB PLATE,BATT SPONGE... -
Page 7: Color Name Table
All manuals and user guides at all-guides.com MECHANICAL MAIN PARTS LIST REF. NO PART NO. KANRI DESCRIPTION 1 S0-801-180-100 LENS,DIAL 2 S0-101-460-100 CAB,FRONT 3 S0-503-380-000 KNOB,RTRY TUN 4 S1-700-780-000 GEAR,TUNING ABS 5 S0-700-420-000 POINTER 6 S1-010-020-000 SLIM MYLAR SKR 57MM 0.2W 4OHM 7 S0-503-360-000 KNOB,RTRY VOL 8 S0-901-160-000... - Page 8 All manuals and user guides at all-guides.com 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 Printed in Singapore 931196...
