- Page 1 UICK TART UIDE t-Boss 7400 ACDC Track Driver Genesis Technologies Inc. www.genesisusa.com • 5812 South 129th E. Ave. Tulsa, Oklahoma 74134 10041PUB903 20120925...
- Page 2 Thank you for purchasing the t-Boss 7400 ACDC Track Driver. It is our goal always to provide quality products and service at a fair price, and treat every customer in a fair and forthright manner. We believe this is the only way to endure in the railroad industry marketplace over the long-term.
-
Page 3: Product Orientation
The t-Boss 7400 ACDC Track Driver is a self-contained and compact unit specifically designed to drive four independent and electrically isolated ACDC track circuits. The t-Boss 7400 is easily installed and provides front-panel indicators to aid in troubleshooting track circuit problems and the DC battery power source. - Page 4 7400XP can provide about 34% greater driving capability. t-Boss 7400 Familiarization The t-Boss 7400 ACDC Track Driver is self-contained in a durable, compact steel enclosure. It is easily mounted on the equipment wall of a signal bungalow or cabinet. For rack mounting, an adapter plate is available for standard rack hole spacing.
- Page 5 T1, T2, T3 and T4 track circuit outputs and track circuits. When the t-Boss 7400 is initially powered-up, the LED Front Panel Indicators cycle through a self-test. If the battery voltage is within the permissible operating range, all track outputs are then powered up.
- Page 6 The TRACK STATUS Indicators show the status of each of the t-Boss 7400 track outputs and its respec- tive track circuit. LED indications are: Ÿ...
- Page 7 Quick Start User Guide t-Boss 7400 ACDC Track Driver Genesis Technologies Inc. Page 5 www.genesisusa.com...
- Page 8 Quick Start User Guide t-Boss 7400 ACDC Track Driver t-Boss 7400 Track Driver - Typical Hookup Wiring Diagram Genesis Technologies Inc. Page 6 www.genesisusa.com...
-
Page 9: Installation
Opposite phase and polarity of adjacent track circuits is accomplished by installing ring-10 track diodes with opposite polarity to those of adjacent circuits. Also, the t-Boss 7400 track output labeled as “+” should be connected to the positive side of the circuit. This is best understood by examining the provided wiring diagram and using it as a guide for your wiring hook-up. -
Page 10: Minimum Wire Size
Field wiring to the rails should be AWG #6. Circuit resistance between the t-Boss 7400 and the rails should be kept as low as reasonably possible as this helps to ensure adequate rail-wheel shunting. - Page 11 Pre-cutover Testing and Cutover Once you have the t-Boss 7400 ACDC Track Driver operating, check the voltage to the rails. In dry weather conditions with good ballast you should see 2.5 to 4.5VAC, depending on the adjustment of the track circuit limit resistor.
-
Page 12: Specifications
(Nm) Three-Year Limited Warranty Genesis warrants all new products for three-years against parts failure and workmanship unless the warranty terms are specifically stated otherwise on the invoice and packing slip for that product when shipped. Warranty is explicitly for parts and workmanship and not for design or function.
