PRODUCT NO.
BASE MODEL NO.
FFC15M6CW5
FFC15M6CW
MARKET
North America
WIRING DIAGRAM - # 216700200
OWNER'S GUIDE - # 216657700
SERVICE DATA SHEET - #216700200
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O.Box 212378, Augusta, GA 30917
FACTORY PARTS CATALOG
SERIES
134A
.
Publication No.
5995345062
001017
-EN/SERVICE /GS
365
FREEZER
COLOR
VOLTS
white
115
FREEZER
Model No.
FFC15M6C
©2000 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Related Manuals for Frigidaire FFC15M6C
Summary of Contents for Frigidaire FFC15M6C
- Page 1 SERVICE DATA SHEET - #216700200 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O.Box 212378, Augusta, GA 30917 FACTORY PARTS CATALOG SERIES COLOR 134A white Publication No. 5995345062 001017 -EN/SERVICE /GS ©2000 White Consolidated Industries, Inc. All rights reserved FREEZER VOLTS FREEZER Model No. FFC15M6C...
- Page 2 Publication No. FFC15M6CW5 5995345062 DOOR 10/00...
- Page 3 POS. NO 47 # 53 # # = Fast-moving Parts * = Non-Illustrated Parts FFC15M6CW5 DOOR PART NO DESCRIPTION 216481201 Gasket-door,white 5303925107 Lock Assy 216388700 Key,lock 216687004 Panel-inner lid,white 216141101 Plug button,white 216129924 Lid,white 216208100 Bezel-nameplate 216683000 Insert-bezel 216472300 Switch-light plunger 216608600 Bulb-light,40W ,130V 216684000...
- Page 4 Publication No. FFC15M6CW5 5995345062 CABINET 10/00...
- Page 5 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FFC15M6CW5 CABINET PART NO DESCRIPTION 5303208488 Latch-door 216080800 Support,lock 216269500 Adapter-drain 216502600 Plug-drain,interior 216073900 Plug-drain,exterior 216111000 Breaker,hinge side 216111600 Breaker,lock side 216110800 Breaker,white ,ends 216591602 Knob,temp control 216562400 Control-temperature 216629600 Screw-hinge 216035200 Hinge...
- Page 6 Publication No. FFC15M6CW5 5995345062 SYSTEM 10/00...
- Page 7 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FFC15M6CW5 SYSTEM PART NO DESCRIPTION 5303925238 Condenser 216634500 Drier-filter 216676800 Wiring Harness 216056400 Clip-spring mtg 5308002681 Grommet,compressor 5303212615 Support-compressor 216511100 Compressor,w/o electricals 216649301 Controller 216649200 Clip,controller 216232700 Washer-flat 5303212614 Clip-harness 216629600 Screw-hinge 218909901...
