Elements Storm Batten 5ft 60W - Connect
Installation and Operating Instructions
7200
3 YEARS
60W
LUMENS
Please read and follow the instructions before operating your light
and save this manual for future reference.
Package includes:
1 x Elements Storm Batten 5ft 60W - Connect
1 x Cable Gland
2 x Mounting Bracket
4 x Screws
4 x Wall Plugs
1 x Manual
Features:
• Equipped with rubber protection Gland and nylon cover protector
• Wiring specification: only use H07RN-2 x 1.0mm2 (WARNING: Do Not Use PVC Cable)
• LED Lamp
• Class II Luminaire.
Safety:
• Electrical work, including installation and repair, must always be completed by a qualified technician.
• Disconnect the lamp from the mains supply and let the product cool down before you replace the light source.
• Never touch the light source when the lamp is turned on.
• In case of product failure, disconnect the lamp from the mains supply.
• The product is suitable for connecting through to multiple units up to a maximum of 500W.
INS-300967-V1
TIME LED is part of Pitacs Limited. For customer support contact:
Bradbourne Point, Bradbourne Drive, Tilbrook, Milton Keynes, Buckinghamshire MK7 8AT
T: +44 (0)1908 271155 F: +44 (0)1908 640017 E: info@TIMELED.co.uk W: www.TIMELED.co.uk
Advertisement
Table of Contents
Related Manuals for TIME LED 300967
Summary of Contents for TIME LED 300967
- Page 1 • The product is suitable for connecting through to multiple units up to a maximum of 500W. INS-300967-V1 TIME LED is part of Pitacs Limited. For customer support contact: Bradbourne Point, Bradbourne Drive, Tilbrook, Milton Keynes, Buckinghamshire MK7 8AT T: +44 (0)1908 271155 F: +44 (0)1908 640017 E: info@TIMELED.co.uk W: www.TIMELED.co.uk...
- Page 2 Product Code 300967 Colour Temp 5000K Daylight Size (mm) 1530x68x65 Material Lamp Dimmable Watts Voltage/Hertz 170-265V 50Hz Lumens 7200lm Warranty 3 Years Lifespan 30,000 Hours IP Rating IP65 Energy Rating Beam Angle 120° Application: Suitable for use in: • Outdoor and moisture exposed environments •...
- Page 3 2) To connect the product: • Twist the waterproof lock anti-clockwise and pull open the power connection carrier. • Insert the power cable through the IP Gland. • Lift the levers on the connectors and insert the live (brown) and neutral (blue) cable as shown. •...
- Page 4 • This product is warranted to be free of defects in materials, design and workmanship for 3 years from the date of purchase (conditions apply, please see TIME LED website for further details). If a suspected fault should develop in this time, please contact us via the address below.
