Summary of Contents for TECO-Westinghouse N3
- Page 2 QUICK START GUIDE This guide provides the essential steps to verify that your N3 drive and motor are working properly. You will use the keypad to start and stop the drive and set up the motor speed. Check Inverter Nameplate Verify that this is the model you intended to use.
- Page 3 Remove Front Cover & Lower Access Plate N3 - QUICK START GUIDE...
- Page 4 Locate the power terminal strip. Check the AC voltage rating shown on the Inverter nameplate with the AC incoming voltage. Caution: Applying voltage higher than the rated N3 AC input voltage will damage the drive and could cause personal injury. N3 - QUICK START GUIDE...
- Page 5 Connect 3 Motor Leads to Terminal Strip Check the motor leads to insure they are wired to match the 230 Volt or 460 Volt output as shown on the N3 inverter nameplate. Caution: Applying higher than rated voltage to the motor will damage the motor.
-
Page 6: Apply Ac Power
Apply AC Power Apply AC power to the drive and observe the keypad. N3 - QUICK START GUIDE... - Page 7 This step is done without the motor connected to the machinery in order to prevent damage from reverse rotation of the motor shaft. If the motor is connected, do not apply any additional load to the machine. N3 - QUICK START GUIDE...
- Page 8 Continued N3 - QUICK START GUIDE...
- Page 9 Adjusting Inverter Speed 60Hz Example: N3 - QUICK START GUIDE...
- Page 10 Stop the Inverter You have just completed all the steps in the Quick Start Guide. N3 - QUICK START GUIDE...
- Page 11 Refer to N3 Instruction Manual You are now ready to refer to the easy-to-read TECO N3 Instruction Manual for topics regarding installation, environmental consideration, basic set-up adjustments, remote control, and advanced adjustments that allow you to customize the N3 for your application.
- Page 12 Should your N3 AC Inverter not start properly, follow the instructions below. Remove power and carefully follow steps 1 through 8 as shown in the N3 Quick Start Guide If the N3 again fails to start; remove power from the N3.
