Frigidaire FFC13C4AW2 Factory Parts Catalog page 5

134a series
Hide thumbs
1
2
3
4
5
6
7

Advertisement

A = FFC13C4A (FFC13C4AW2)
B = FFC15C4A (FFC15C4AW2)
# = Fast-moving Parts
* = Non-Illustrated Parts
FFC13C4AW2, FFC15C4AW2
POS. NO
PART NO
1
5303208488
1A
216818900
3
216502600
4
216073905
6
216110900
6
216111000
7
216111500
7
216111600
11
216110800
18
216707200
21 #
216714601
27
216629600
28
216039600
28
216035200
30
216110700
59
216080300
71
5303302714
75
216034301
*
5303305324
CABINET
DESCRIPTION
A B
Latch,lid catch
A B
Support,lock catch clip
A B
Plug,drain ,interior
A B
Plug-drain,exterior
A -
Breaker
- B
Breaker,hinge side
A -
Breaker,lock side
- B
Breaker,lock side
A B
Breaker,chest end ,(2)
A B
Knob,temp control
A B
Control temperature
A B
Screw,hex washer head ,10-16 x 0.500 ,tapping
A -
Hinge
- B
Hinge
A B
Breaker,corners
A B
Basket
A B
Screw,8-18x3/4 ,(2)
A B
Panel,access ,white
A B
Paint,touch-up ,white
5
Publication No.
5995378535
09/02
