Frigidaire FFC13C3AW1 Factory Parts Catalog page 7

134a series
Hide thumbs

Advertisement

A = FFC13C3A (FFC13C3AW1)
B = FFC15C3A (FFC15C3AW2)
POS. NO
1
4
5
22
27
28
29 #
30
32
42
43A
47
55 #
86
# = Fast-moving Parts
* = Non-Illustrated Parts
FFC13C3AW1, FFC15C3AW2
SYSTEM
PART NO
DESCRIPTION
5303925238
A B
Condenser
216634500
A B
Drier-filter
216806900
A B
Harness-main
216056400
A B
Clip,compressor mtg ,SPRING
5308002681
A B
Grommet,compressor
5303212615
A B
Support,compressor
216856700
A B
Compressor,w/o electricals
216649319
A B
Controller
216694500
A B
Clip,controller
216232700
A B
Washer,flat ,1"OD x 0.531"ID
5303212614
A B
Clip,harness mount
216629600
A B
Screw,hex washer head ,10-16 x 0.500 ,tapping
218909901
A B
Capacitor,run ,50/60 Hz ,220 VAC ,15 microfarad
216036600
A B
Screw,ph washer head ,8-32CA x 0.500 ,thread forming
7
Publication No.
5995378469
09/02
