INSTALLATION MANUAL
Automatic swing door opener Olide-120B
AUTOMATIC DOOR SPECIALISTS
INSTALLER NOTES:
The programming of the Open&Close stopping points will occur after the initial
hardware installation. An uninstalled unit will result in constant motor rotation.
For support, please email us: tech@olideautodoor.com
Advertisement
Table of Contents
Related Manuals for Olide 120B
Summary of Contents for Olide 120B
- Page 1 INSTALLATION MANUAL Automatic swing door opener Olide-120B AUTOMATIC DOOR SPECIALISTS INSTALLER NOTES: The programming of the Open&Close stopping points will occur after the initial hardware installation. An uninstalled unit will result in constant motor rotation. For support, please email us: tech@olideautodoor.com...
-
Page 2: Table Of Contents
4.10 C onnection with the touchless hand sensor switches ................15 4.11 Connecting to wireless touchless sensor switch Olide-508,Olide-512 ..........16 4.12 Connecting to wired touchless sensor switch Olide-514,Olide-513 and Olide-513......16 4.13 Connecting to wired touchless sensor switch Olide-514,Olide-513 and Olide-513N......16 4.14 Connecting to wired narrow handicap push button 515................. -
Page 3: Technical Parameters
1 Technical Parameters Voltage: 110-220 VAC +/-10% Power Consumption: Opening Time: 3-7 sec. @ 90 degrees Hold Open Time: 1-30 sec. Adjustable 450mm / 17.7" Max. Door Frame Depth: Min. 660mm / 26" Door Width: Max. 1200mm / 47.2" 120 degrees Max. -
Page 4: Components
2 Component Sensor cable hole Base Plate: Power cable hole Motor Assembly: Cover Plate: Pull Arm(Option for inswing opening) Push Arm(Option for outswing opening) Pull Arm(Option for frameless glass inswing opening) Push arm glass clamp... -
Page 5: Installations
3 Installation Installation example Pull Arm The door opens to the inside toward the unit using the pull arm assembly. Push Arm The door opens to the outside away from the unit using the push arm assembly. -
Page 6: Installation Of Base Plate
3 Installation Installation of base plate hole 0.88"(22.5mm) 1.2"(30.5mm) 5.90"(150mm) 5.90"(150mm) 6.49"(165mm) 2.0"(52mm) 18.2"（464.5mm) 1.18"(30mm) 1.5"(38.5mm) 0.59"(15mm) As the picture shows, the base plate should be mounted to the frame with eight wood screws or eight M6-15 countersunk screws. Please note that 20mm sensor cable hole is always to the right side and that the power cable access is always to the left. -
Page 7: Installation Of Pull Arm
3 Installation 3.3 Installation of Pull arm 29(1.44") 240（9.44") 240(9.44") 160(6.3") （ 0.78" Fix the slide rail of pull arm on the door panel as shown using three round head wood Screws (if the door panel is steel, please use M6*15 cross recessed head screws.) Attach the slide rail of the pull arm on the door panel as shown... -
Page 8: Installation Of Push Arm
3 Installation 3.4 Installation of Push arm 35(1.29") 50(1.96") 290(11.42") Fix the support holder of push arm on the door panel as shown using two round head wood screws (if the door panel is steel, please use M6*15 cross recessed head screws.) 12.40"(315mm) Loosen this 3 bolts and adjust the push arm length according to the door depth(L) until the angle between... - Page 9 3 Installation 3.4 Installation of Push arm Stop screw Adjust the stop screw position slotted hole to allow full opening of the door. Do not exceed 90°.
-
Page 10: Installation Of Push Arm For Frameless Glass Door
3 Installation 3.5 Installation of Push arm for frameless glass door Clasp the door with door clamp tightly,then fix the clamp with M5*8 Hexagon socket set screws. M5*8 Set screws M5*8 Set screws Please connect the push arm to the door clamp with the M5*8 Hexagon socket set screws. - Page 11 3 Installation 3.6 Installation of Pull arm for frameless glass door Clasp the door with door clamp tightly,then fix the clamp with M5*8 Hexagon socket set screws. M5*8 Set screws Connect the pull arm to the motor.
-
Page 12: Installation Of Operation System
3 Installation 3.7 Installation of operation system Hook the component assembly onto the base plate as shown. Attach it with 8 allen head screws 3.8 Installation of Cover Opening the cover... -
Page 13: Connection The Operation System With The Push Arm
3 Installation 3.9 Connect pull arm to the operation system 3.10 Connect the push arm to the operation system. Motor output shaft... -
Page 14: Electrical Connections
Electrical Connections Control panel details Power wiring: Please connect the 110V-240V AC power input according the left picture. 4.1 Connecting with keypads... -
Page 15: Connections With A Microwave Sensor
Electrical Connections 4.2 connecting to microwave sensors 4.3 connecting to PIR sensors 4.4 Connecting to safety motion top scans... -
Page 16: C Onnections For Push Buttons
Electrical Connections 4.5 Connecting to plastic push buttons 4.6 Connecting to wiring disabled push buttons 4.7 Connecting to wireless handicapped push buttons... -
Page 17: Connections For Magnetic Locks
Electrical Connections 4.8 Connecting to magnetic locks （Important Notes:As maglocks need constant power-You will need to press the LOCK button on the keychain remote control to initialize for it.It will work normally afterwards.） 4.9 Connecting to electrcal locks (Important Notes:As maglocks need constant power-You will need to press the LOCK button on the keychain remote control to initialize for it.It will work normally afterwards.）... -
Page 18: Connecting To Wireless Touchless Sensor Switch Olide-508,Olide-512
Electrical Connections 4.11 Connecting to wireless touchless sensor switch Olide-508,Olide-512 4.12 Connecting to wired touchless sensor switch Olide-514,Olide-513 and Olide-513N 4.13 Connecting to wired touchless sensor switch Olide-514,Olide-513 and Olide-513N... -
Page 19: Connecting To Wired Narrow Handicap Push Button 515
Electrical Connections 4.14 Connecting to wired narrow handicap push button 515... -
Page 20: Double Door Synchronous Settings
Electrical Connections 4.15 Double door synchronous connections double door synchronous : Controller “A” Controller “B” 3 pin connector. sync in sync in sync out sync out Interlock: Controller “B” Controller”A” 6 Pin Connector safety sesnsor close safety sensor close safety sensor open safety sensor open interlock input interlock input... -
Page 21: Wireless Push Buttons Settings
Electrical Connections 4.16 Wireless push buttons settings The wireless push button need to encoded with the door opener Steps: 1. To delete:Press the "encode"button until the buzzer sound ceases,then release the "encode"button. 2. To pair:Press the "encode"button once-the buzzer will sound. Now press the "PRESS"... -
Page 22: Remote Control Settings
Electrical Connections 4.17 Remote control settings Hold-open Lock Automatic Reset The remote control are pre-encoded to work with the door opener. Nevertheless,here is the process for encoding the remote with the opener. 1. To delete all codes: Hold the “Encode” button on the component assembly until the buzzer is silent. 2. -
Page 23: Parameters Adjustment
Parameters Adjustment 5.1 Hand programmer instruction Display screen Increase Decrease Function Selection Test Display Screen guide and function display F – 1 work parameters F – 2 door parameters os = opening speed n1 single/double door od = opening low speed angle n2 master/slave cs = closing speed n3 synchronize settings... -
Page 24: Adjustment Steps
Parameters Adjustment 5.2 adjustment steps manual push force adjust Note:If you want to adjust the manual push force for push&go function,just adjust the closing force accordingly. -
Page 25: Trouble Shooting
6 Trouble shooting Symptoms Remedies The door opens in the wrong direction. Turn the power off, manually open the door halfway. Turn the power back on,check to see the door closes in the correct direction.If not change the opening direction using the Handheld Programmer.
Need help?
Do you have a question about the 120B and is the answer not in the manual?
Questions and answers
How to program the door to stay open longer
To program the Olide 120B door to stay open longer, use the hand programmer. Adjust the "opening hold time" parameter (ok=opening holdtime) found in the settings. Refer to pages 22–23 of the manual for detailed steps.
This answer is automatically generated
i am trying to wire in the plastic push button . i have tried the 2 and 3 posts and the 2 and 4 posts but nothing works. will this push button work if i have the remotes working? bob
i am using the remote controls as per page 21 of your manual can i also use the wireless push button as per page 20 at the same time
