Frigidaire FFC13C2AW0 Factory Parts Catalog page 7

134a series
Hide thumbs

Advertisement

A = FFC13C2A (FFC13C2AW0)
B = FFC15C2A (FFC15C2AW0)
# = Fast-moving Parts
* = Non-Illustrated Parts
FFC13/15C2AW0
POS. NO
PART NO
1 #
5303925238
4
216634500
5
216551800
22
216056400
27
5308002681
29 #
216784300
30
216649313
32
216649200
55 #
216787800
85
216533500
86
216036600
*
5303212614
*
5303212615
SYSTEM
DESCRIPTION
A B
Condenser
A B
Drier-filter
A B
Harness,electrical
A B
Clip-spring mtg
A B
Grommet,compressor
A B
Compressor,w/o electricals
A B
Controller
A B
Clip,controller
A B
Capacitor-run
A B
Wire,ground
A B
Screw,rwhd (gx-ca) ,8-32 x 1/2
A B
Clip-harness
A B
Support-compressor
7
Publication No.
5995357117
10/01
