Warnings Programmable control devices such as the EZ7-TouchPLC Junior units are not fail-safe devices and such as must not be used for stand-alone protection in any application. Unless proper safeguards are used, unwanted start-ups could result in equipment damage or personal injury. The operator must be made aware of this hazard and appropriate precautions must be taken.
This manual provides information on installation, wiring and getting started with editor software. Editor software provides help on software. Following documents have more detailed information on the Panel and PLC: 1. EZ Series Touch Panel Software Page 4 of 35 EZ7-TouchPLC Junior...
EZ7DT-T7C-FR EZ7 7” Inch Display Only EZ7DT-T8C-FR EZ7 8” Inch Display Only EZ7DT-T10C-FR EZ7 10” Inch Display Only EZ7DT-T12C-FR EZ7 12” Inch Display Only Cable EZ7DT-CBL-012 Cable between Front and back of EZ7, 12” Page 5 of 35 EZ7-TouchPLC Junior...
1 USB port for programming, 1 USB port for Datalogging and 1 microSD slot for additional data storage USB & microSD Ports Built-in USB, RS232 and Ethernet Ports Communication Ports UL, CUL, CE Agency Approval 8.048” x 6.146” x 4.325” External Dimensions (204.41 x 156.11 x 109.87mm) Weight 2 lbs Page 6 of 35 EZ7-TouchPLC Junior...
2. If not already done, please Install EZTouch Editor on the PC. See below. 3. Run EZTouch Edit and start creating project 4. Transfer the project to the panel and start working with screens. Page 7 of 35 EZ7-TouchPLC Junior...
Enhancement of a system’s noise level immunity and its tolerance to other environmental hazards can be accomplished by following proper system installation guidelines. The recommendations are of a general nature and constitute good industrial installation practice. Page 8 of 35 EZ7-TouchPLC Junior...
Page 9
Earth. This not only provides for safe operation, it will also drain out any conducted RFI to Earth, away from the CPU's signal ground. Page 9 of 35 EZ7-TouchPLC Junior...
Page 10
Primary power leads to the control equipment (Base power terminals) should be made with a two wire twisted cable with approximately 12 turns per foot. The length of these cables should be kept to a minimum, and to the greatest extent possible, such cable runs should be kept separate from other wiring. Page 10 of 35 EZ7-TouchPLC Junior...
The EZ7-TouchPLC is stud mounted. All the necessary mounting hardware is provided with the unit. Both the processor and the TOUCHPLC screen have studs with nuts provided. Below is a full installation guide with step by step instructions. Page 12 of 35 EZ7-TouchPLC Junior...
Page 13
1. Use the provided screen with screw holes indicators to drill holes in your control cabinet. 2. Once all the holes have been drilled in the cabinet. Take the Processor Box and plug in the provided HDMI cable into its connector port. Page 13 of 35 EZ7-TouchPLC Junior...
Page 14
Processor Box to the inside of the Control Cabinet. Also make sure that the HDMI cable is pulled through the large middle hole. 4. Now connect the cable to the Front Display screen, make sure that the cable is pulled through the large middle hole. Page 14 of 35 EZ7-TouchPLC Junior...
Page 15
5. Now insert all studs through their respective holes, and use provided nuts (Hex-head nut, size 10-32 requiring 3/8” nut driver/wrench) to secure the front to the cabinet. 6. When looking from bottom or top the screen should look like the image below. Page 15 of 35 EZ7-TouchPLC Junior...
Blinking Red / Continuously Red Some Panel Issue has occurred. Please try a power cycle, if that does not fix the issue please contact Tech Support. No Light Power source not connected or inadequate Page 16 of 35 EZ7-TouchPLC Junior...
6.2.3 I/O Module Information For information on I/O module specification and wiring information please check the Click here respective I/O modules wiring instruction insert which comes with product, or to go online and to download datasheets. Page 17 of 35 EZ7-TouchPLC Junior...
The CPU reads the status of all inputs, and stores them in an image table. Image Table is EZ7-TouchPLC Junior internal storage location where it stores all the values of inputs/outputs for ONE scan while it is executing ladder logic. The CPU uses this image table data when it solves the application logic program.
(see how to set IP address later in the document) If Ethernet is to be used, you need to know EZ Unit’s IP address. Specify this address her Finally click “Click to Start Designing Page 19 of 35 EZ7-TouchPLC Junior...
Page 20
Once again, a dialog box will appear. Enter "O1” as the address string. Click OK. Click on Instructions > Line to wire “NO Contact” and “NO Coil.” Your screen should look like this when finished: Page 20 of 35 EZ7-TouchPLC Junior...
Page 21
3. Click anywhere on the screen to place the Button object. Double click the icon to open its object dialog box if you need to adjust the object's appearance or attributes. Clicking "Simulates Press" will allow you to toggle between on and off states. Page 21 of 35 EZ7-TouchPLC Junior...
RS-232 port on the PC, a USB to RS-232 converter may be used to connect the programming cable to the PC. 2. Select in the drop down (that appears next to Serial radio button after the option is chosen) COM port on Page 22 of 35 EZ7-TouchPLC Junior...
Page 23
3. After confirming the mode to transfer the project, click Start to write the project data from the PC to the EZ7 Series TouchPLC. When finished, a Transfer Completed message will be displayed. Click OK to continue and the project is now transferred. Page 23 of 35 EZ7-TouchPLC Junior...
SD- System Discretes 1-64 READ_WRITE DISCRETE SD10 XR- Index Registers NONE READ_WRITE WORD XR10 #R – Value Registers READ_WRITE WORD #R1 - #R4 Note: Does not Support Access to a Bit of Word (E.g.: R100/ 0, R100/5…etc) Page 24 of 35 EZ7-TouchPLC Junior...
Discrete Inputs are denoted using an “I” pre-fix (e.g. I1, I4, etc.). The maximum number of physical Inputs available in an EZ7-TouchPLC Junior is 24. Hence, you may only use I1 – I24 in your main logic. Note: All the discrete type EZ7 Inputs are mapped to Discrete Input bits. In the example above, the output bit O1 will be turned on when input I1 allows power through the rung.
Page 26
The Index Register data type is represented by an “XR” prefix (e.g. XR1, XR2 etc.). There are 4 XR memory locations available in EZ7-TouchPLC Junior. “XR” is a Read- Write data type and it is mainly used to point to the correct address of “R”...
The EZ7-TouchPLC Junior will arrive with a factory-programmed IP Address that may need edited to be compatible with your LAN network. Once the IP Address has been adjusted to the LAN, the EZ7-TouchPLC Junior can receive programming instructions through either the serial port (COM1) connection or via the Ethernet. Follow the steps below to use the editing software to update the IP Address information though a COM port on the EZ7-TouchPLC Junior.
Page 28
Click Set-up > Ethernet Set up. A dialog box will appear displaying the current IP parameters. Once the dialog box appears, select 'Configure Ethernet Attributes.' Type in the necessary changes and click 'Set Ethernet Parameters.' Click OK. Next, save the project. Page 28 of 35 EZ7-TouchPLC Junior...
AVG devices connected to the local area network (LAN) even if a device’s IP address is not on the same subnet. To download this free utility please visit our website at www.ezautomation.net and click on the downloads tab. 1. Install the IP Config Utility.
Press 1 then Mon. c. Press 1 then 3, followed by Yr. 4) Once finished, press Exit to return to the previous screen. Pressing Exit again will bring you back to the main screen. Page 30 of 35 EZ7-TouchPLC Junior...
2. A new screen will appear. Press each box individually to ensure that the touchscreen is properly responding. 3. Once finished, press Exit to return to the previous screen. Pressing Exit again will bring you back to the main screen. Page 31 of 35 EZ7-TouchPLC Junior...
2. The upper left corner will then display the firmware currently enabled on the unit. To update firmware: There are several methods to update the firmware for an EZ7-TouchPLC Junior unit. Previously, it was explained how to update firmware through an OEM Packager file. Alternatively, the user can follow the steps below to update firmware through the EZ Series Software and a COM port on the EZ7-TouchPLC Junior unit.
Page 33
5. After the project loads, click Setup > Upgrade Firmware. A dialog box will appear requesting the firmware file you would like to load to the unit. 6. Use Browse to locate the appropriate firmware version. Page 33 of 35 EZ7-TouchPLC Junior...
If you encounter difficulties while using our EZ7 Series TouchPLC device, please consult the table below. Additional assistance is also available within the Panel Editor Programming Software Help. Alternatively, you may also find answers to your questions on our website www.ezautomation.net. Problem...
Page 35
Out of Warranty Services If your EZ7-TouchPLC Junior is out of warranty, contact EZ Automation at 1-877-774-EASY for an evaluation of repair costs. You can then decide whether it is more economical to proceed with the repairs or to upgrade your system with a new unit.
