Frigidaire GLGR341A Factory Parts Catalog

Gas dryer
Hide thumbs

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
GLGR341AS2
GLGR341A
MARKET
North America
WIRING DIAGRAM - # 131703900
OWNER'S GUIDE - # 131883500
INSTALLATION INSTRUCTIONS - # 131751700
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917
FACTORY PARTS CATALOG
SERIES
COLOR
Gallery
white
Publication No.
5995381687
021115
-EN/SERVICE /ECL
361
DRYER
VOLTS
120
GAS
DRYER
Model No.
GLGR341A
©2002 Electrolux Home Products, Inc.
All rights reserved

Advertisement

loading

  Related Manuals for Frigidaire GLGR341A

  Summary of Contents for Frigidaire GLGR341A

  • Page 1 PRODUCT NO. BASE MODEL NO. GLGR341AS2 GLGR341A MARKET North America WIRING DIAGRAM - # 131703900 OWNER’S GUIDE - # 131883500 INSTALLATION INSTRUCTIONS - # 131751700 ELECTROLUX HOME PRODUCTS, INC. P.O. BOX 212378, Augusta, GA 30917 FACTORY PARTS CATALOG SERIES COLOR...
  • Page 2 Publication No. GLGR341AS2 5995381687 CABINET/DRUM 11/02...
  • Page 3 Housing,gas heater assy ,w/seal 131477000 Screw,shaft/baffle mt ,10-16AB x 0.375 ,special 131469100 Bracket,hinge ,rear ,top panel mtg. 134122532 Drum,dryer ,galvanized stl. ,service kit 131963900 Glide,drum 5303015671 Screw,hex washer head ,8-18 x 0 .375 ,cup point 131382300 Screw,quadrex head ,10-14 x 1.00 ,vane mtg.,special...
  • Page 4 Publication No. GLGR341AS2 5995381687 FRONT PANEL/LINT FILTER 11/02...
  • Page 5 POS. NO 26 # 58 # 58*# # = Fast-moving Parts * = Non-Illustrated Parts GLGR341AS2 FRONT PANEL/LINT FILTER PART NO DESCRIPTION 134063300 Seal,air duct 131397000 Plug,dome ,white 131621900 Duct,air 131622202 Cover,lint housing 131633200 Plug,white 131063700 Clip,wiring 134036400 Seal,felt ,upper 5308027429 Adhesive,high temp 134134700...
  • Page 6 Publication No. GLGR341AS2 5995381687 CONTROLS/TOP PANEL 11/02...
  • Page 7 131629400 Buzzer,mini 131629600 Wiring Harness,mini buzzer 131168200 Screw,pan head ,8-18B x 0.31 131205100 Screw,#8 pan head ,10-10B x 0.500 ,cr/sq drive 134086802 Panel,dryer top ,white ,console mtg 131243800 Screw,pan hd locking ,8-32CA x 0.375 ,brkt-to-top pnl Publication No. 5995381687 11/02...
  • Page 8 Publication No. GLGR341AS2 5995381687 MOTOR 11/02...
  • Page 9 POS. NO 10 # 15 # 23 # 25 # 28 # # = Fast-moving Parts * = Non-Illustrated Parts GLGR341AS2 MOTOR PART NO DESCRIPTION 131435200 Lock,blower housing 131451600 Tube,exhaust ,rear ,w/mtg bracket 131456800 Tube,exhaust ,side/bottom ,Optional Kit 131775600 Housing,blower assy ,cover & wheel 131749800 Spacer,idler 131298400...
  • Page 10 Publication No. GLGR341AS2 5995381687 BURNER 11/02...
  • Page 11 POS. NO 55 # 69 # 70 # 71 # 72 # 73 # 74 # 77 # 79 # 80 # # = Fast-moving Parts * = Non-Illustrated Parts GLGR341AS2 BURNER PART NO DESCRIPTION 131168200 Screw,pan head ,8-18B x 0.31 131715500 Clip,ignitor mtg 131243700...

  • Page 12: Wiring Diagram

    Publication No. GLGR341AS2 5995381687 WIRING DIAGRAM 11/02...
