- Page 1 Installation Guide for Intel Pentium 4 , AMD Athlon XP, Athlon 64 GH-PCU21-VG...
-
Page 2: Table Of Contents
Table of Content Checklist .......................... 3 Specification ........................4 Feature ........................... 4 Installation Instructions for Intel Pentium 4 Clips ..............5 Installation Instructions for AMD Athlon XP Clip ..............6 Installation Instructions for AMD Athlon 64 Clip ..............7 Power Installation and 3.5” Fan Speed Controller Installation ......... 8 Power Installation and PCI Fan Speed Controller Installation .......... -
Page 3: Checklist
Checklist (1) GH-PCU21 -VG Cooler (2) GH-PCU21-VG user's manual (7) P4 Clips (3) Heat Sink Paste (8) K7 Clip (4) Speed Control & 3.5” front panel (9) K8 Clip (6) Power cable (5) PCI rear panel (10) Screw Before use, please remove the bottom protective layer of the cooler. Please make sure the computer is turned off and its power disconnected prior to installation. -
Page 4: Specification
Specification — Heat Sink Dimension: 83 x 89 x 93mm — Rated Speed: 2000~4000 rpm — Rated Voltage: 5~12V — Noise:19.2~37.2 dBA — Bearing Type: 2 Ball Bearing Feature — Unique patent for K8, K7 and P4 platform designs — Smart IC controller for noise and cooling —... -
Page 5: Installation Instructions For Intel Pentium 4 Clips
Installation Instructions for Intel Pentium 4 Clips Figure 1 Please add an adequate layer of heat sink paste on the surface of the CPU. Figure 1 Figure 2 Figure showing the correct installation of the cooler atop the CPU. Figure 2 Figure 3 Hook the clip on one end of the cooler with the insert space at the CPU base (as seeing left Figure 3).Firmly push downwards... -
Page 6: Installation Instructions For Amd Athlon Xp Clip
Installation Instructions for AMD Athlon XP Clip Figure 1 Please add an adequate layer of heat sink paste on the surface of the CPU. The picture on the right shows the three insert spaces on the cooler bracket where the CPU clips attach. Figure 1 Attention!! The indication arrow on the cooler must align with the central CPU clip. -
Page 7: Installation Instructions For Amd Athlon 64 Clip
Installation Instructions for AMD Athlon 64 Clip Figure 1 Please add an adequate layer of heat sink paste on the surface of the CPU. Figure 1 Figure 2 Figure showing the correct installation of the cooler atop the CPU. Figure 2 Figure 3 Align the three insert spaces of the clip with the three juts on the CPU socket and then push firmly downwards to hold the clip in... -
Page 8: Power Installation And 3.5" Fan Speed Controller Installation
Power Installation and 3.5” Fan Speed Controller Installation Figure 1 Connect the power cable of the power supply to the end of the 4-pin connector cable provided. Figure 1 Figure 2 Connect the other end of the 4-pin connector cable to the PCB 4-pin connector on the cooler. -
Page 9: Power Installation And Pci Fan Speed Controller Installation
Power Installation and PCI Fan Speed Controller Installation Figure 1 Disassemble the turn knob, bolt and fan speed controller from the 3.5” front panel and reassemble these parts onto a PCI rear panel in sequence. Figure 1 Figure 2 Place the PCI rear panel with the fan speed controller in the selected PCI slot.
