The scope of the TFA1-298 control panel is to build analog systems for the automatic detection of fi re, able to cover all the needs
of small and medium-sized plants.
User interface
The front panel of the control panel hosts the user interface, consisting of 16 LED, a graphic color display and a keypad for management
of the fi re detection system. The user interface integrates also a voice synthesis function that uses a customizable vocabulary.
Access levels
The control panel manages 4 levels of access: level 1 (not protected by code), level 2 (user), level 3 (installation and maintenance personnel
and level 4 (manufacturer).
Monitored system mode
The control panel provides for the monitored system mode, subject to the recognition of a level 2 code.
The monitored system mode is indicated by the relevant LED on the control panel and the relevant icon on the repeater panel.
System confi guration
The confi guration of the system can be performed locally through the control panel or remotely using a personal computer and the
programming software.
Detection loop
The detection loop of the control panel can handle up to 199 detectors and 99 modules (maximum confi guration in closed-loop mode).
Detectors
The control panel can directly manage the addressable detectors of the Tecnofi re product line.
Conventional detectors can be managed through addressable interfaces.
Modules
The control panel can manage different types of specialized modules: input modules, output modules, sirens, call points, optical-acoustic
alarm devices, additional power supplies.
Telephone communicator
A total of 5 external PSTN telephone communicators with optional GSM-GPRS interface can be connected for transmitting voice, SMS,
GPRS notifi cations of alarms and signaling.
Repeater
The repeater panel has the task of repeating alarm signaling and decentralizing system management.
The repeater provides a 7 inches touch screen and a voice synthesis function.
Synoptic repeater
The synoptic repeater panel performs the same functions as the repeater and, in addition, it manages dynamically or on request
up to 32 fl oor plans with up to 32 interactive icons each.
Additional power supply
The system provides for the use of additional power supplies, which allow to increase the power supply and autonomy of the system.
The power supplies can be freely distributed within the infrastructure of the loop. The Tecnofi re power supplies are constantly supervised
by the control panel and comply with the applicable standard EN 54-4-A2:2006.

3 - SYSTEM SPECIFICATIONS
