WaterCompass FM300 Ultrasonic Flow Monitor
Installation Instructions
WC-FM300-US-25, WC-FM300-US-37, WC-FM300-US-50, WC-FM300-US-75,
WC-FM300-US-100, WC-FM300-US-125, WC-FM300-US-150, WC-FM300-US-200
Introduction
This document covers installation for
the WC-FM300-US Ultrasonic Flow
Monitor for pipe sizes of 1/4 - 2".
The WaterCompass FM300 Ultrasonic Flow
Monitor is a customized product made up of an
integrated WT2W-H20 Flow Decoder, a clamp-
on flow monitor and a 30 V power supply.
The monitor sends real-time flow data to the
WaterCompass Data Collector that is viewed from
the WaterCompass dashboard. Hourly summation
of flow data is stored for analysis and reporting.
Before you begin, review the safety precautions
at the end of this installation guide.
Pre-Configured Settings
To ensure accuracy, the Flow Monitor will be
pre-configured with the following settings:
Pipe size (varies)
Pipe type (varies)
Flow direction (right)
K-value (60.1)
If the values relating to pipe size, K-value, flow
direction and pipe size have to be changed
for any reason, please contact Customer
Support for additional assistance.
Contact Information:
WaterCompass Customer Support
800-362-8774
support@hydropoint.com
Materials Provided
• WaterCompass Data Collector
• WaterCompass Flow Monitor w/integrated flow decoder
• 30 V dc power supply
• 4 wire nuts
Equipment Needed
• Caliper
• Philips head screwdriver with long shaft
• Torx screwdriver (for pipes larger than 2")
• 2 J-Box
• Power cable
• 2-Wire
• Zip ties
1
800 362 8774
|
hydropoint.com
|
support@hydropoint.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WaterCompass FM300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HydroPoint WaterCompass FM300

  • Page 1 WaterCompass FM300 Ultrasonic Flow Monitor Installation Instructions WC-FM300-US-25, WC-FM300-US-37, WC-FM300-US-50, WC-FM300-US-75, WC-FM300-US-100, WC-FM300-US-125, WC-FM300-US-150, WC-FM300-US-200 Introduction Materials Provided This document covers installation for • WaterCompass Data Collector the WC-FM300-US Ultrasonic Flow Monitor for pipe sizes of 1/4 - 2”. • WaterCompass Flow Monitor w/integrated flow decoder The WaterCompass FM300 Ultrasonic Flow •...
  • Page 2: Installation Overview

    WATERCOMPASS FM300-US FLOW MONITOR: INSTALLATION INSTRUCTIONS 1/4 - 2” Installation Overview This installation manual is intendeded to WATERCOMPASS DATA COLLECTOR INSTALLATION detail the process a contractor should follow to install an FM300 Flow Monitor on-site, as welll as outlining basictroubleshooting steps.
  • Page 3: Wall Mounting Instructions

    WATERCOMPASS FM300-US FLOW MONITOR: INSTALLATION INSTRUCTIONS 1/4 - 2” Step 1: Mount the WaterCompass Data Collector Enclosure Wall Mounting Instructions Use the template enclosed with the Water Compass Data Collector for assistance when mounting the enclosure to a wall. Locate the 2 mounting holes on the back of the enclosure.
  • Page 4 WATERCOMPASS FM300-US FLOW MONITOR: INSTALLATION INSTRUCTIONS 1/4 - 2” Step 2: Connect the WaterCompass Data Collector to AC Power The WaterCompass Data Collector incorporates a dual voltage power supply and can be connected to a single phase 120 V ac or single phase 220 V ac source. Please refer to the 120 V ac or 220 V ac diagrams on pages 5-6 for proper connections.
  • Page 5 WATERCOMPASS FM300-US FLOW MONITOR: INSTALLATION INSTRUCTIONS 1/4 - 2” Step 2: Connect the WaterCompass Data Collector to AC Power, cont. 120 V AC Applications For 120 V ac wire applications, connect the conductors as illustrated below from the primary side of the transformer to wiring from an approved electrical source.
  • Page 6 WATERCOMPASS FM300-US FLOW MONITOR: INSTALLATION INSTRUCTIONS 1/4 - 2” Step 2: Connect the WaterCompass Data Collector to AC Power, cont. 220 V AC Applications For 220 V ac single-phase applications connect the conductors as illustrated below from the primary side of the transformer to wiring from an approved electrical source.
  • Page 7 WATERCOMPASS FM300-US FLOW MONITOR: INSTALLATION INSTRUCTIONS 1/4 - 2” Step 3: Activate the WaterCompass Data Collector Activate the Data Collector by calling Customer Support at 1-800-362-8774 or by emailing support@hydropoint.com. Please be sure to have the following information when calling to activate the Data Collector: •...
  • Page 8 WATERCOMPASS FM300-US FLOW MONITOR: INSTALLATION INSTRUCTIONS 1/4 - 2” Step 5: Attach the Flow Monitor to the Pipe Before beginning, take some time to familiarize yourself with the part names and functions of the flow monitor. Caution: During the installation process, it is very important to not slide the bracket with the rubber backing against the pipe.
  • Page 9 WATERCOMPASS FM300-US FLOW MONITOR: INSTALLATION INSTRUCTIONS 1/4 - 2” Step 5: Attach the Flow Monitor to the Pipe, cont. Unscrew the retaining nut and remove the power cord connector from the top of the FM300-US Flow Monitor. Using a Phillips-head screw driver, remove the two screws at either end of the flow monitor.
  • Page 10 WATERCOMPASS FM300-US FLOW MONITOR: INSTALLATION INSTRUCTIONS 1/4 - 2” Step 5: Attach the Flow Monitor to the Pipe, cont. Taking the flow direction into consideration, reposition the monitor on the mounting bracket and realign the mounting holes. Replace the screws on either end of the sensor.
  • Page 11 WATERCOMPASS FM300-US FLOW MONITOR: INSTALLATION INSTRUCTIONS 1/4 - 2” Step 6: Connecting the Flow Monitor to the 2-Wire Path Note: The Flow Monitor being installed may look different than what is pictured. The wiring connections and process remain the same.
  • Page 12 WATERCOMPASS FM300-US FLOW MONITOR: INSTALLATION INSTRUCTIONS 1/4 - 2” Step 8: Validate Proper Flow Stability Turn on the power to the Flow Monitor. The Stability indicator lights up on the lower left of the display after the initial installation. 2. The stability indicator shows the rough stability of detection.
  • Page 13 WATERCOMPASS FM300-US FLOW MONITOR: INSTALLATION INSTRUCTIONS 1/4 - 2” Step 9: Program the WT2W-H20 Decoder that is connected to the Flow Monitor In order for the decoder to communicate with the WaterCompass Data Collector, you will need to program it using the the Station...
  • Page 14 Step 9: Program the WT2W-H20 Decoder that is connected to the Flow Monitor WATERCOMPASS FM300-US FLOW MONITOR: INSTALLATION INSTRUCTIONS 1/4 - 2” Step 9: Program the WT2W-H20 Decoder that is connected to the Flow Monitor, cont. Disconnect the decoder 2-wire from the station decoder programming terminal block.
  • Page 15 WATERCOMPASS FM300-US FLOW MONITOR: INSTALLATION INSTRUCTIONS 1/4 - 2” Step 10: Enter the K Value into the WaterCompass Data Collector Press FLOW. Press* to configure. 2. Press --> until the SELECT FLOW SENSOR 2. Press --> to Edit. screen displays (screen 02-07-02).
  • Page 16: Step 13: Update Controller Firmware

    WATERCOMPASS FM300-US FLOW MONITOR: INSTALLATION INSTRUCTIONS 1/4 - 2” Step 12: Verify the Flow in GPM on the WaterCompass Data Collector Press FLOW. 2. The Flow Sensor will display. If flow is being red, you should see the flow sensor listed followed by the number in GPM’s.
  • Page 17: Appendix A: Selecting An Installation Location

    WATERCOMPASS FM300-US FLOW MONITOR: APPENDIX A Appendix A: Selecting an Installation Location How to Select an Installation Location Some important factors must be considered BEFORE installing the FM300-US Flow Monitor. Read and follow the guidelines below to ensure that the flow monitor is installed in just the right location to deliver the results you need.
  • Page 18 Install in a room where there is 120V power The WaterCompass FM300-US Flow Monitor runs on DC power. It is best to install the device in a room where there is a power outlet or where power conduit can be tapped into for use.
  • Page 19 WATERCOMPASS FM300-US FLOW MONITOR: APPENDIX A Appendix A: Selecting an Installation Location, cont. Power Requirements for the Flow Monitor • Power Supply Length Limit: 2500 feet • Power Supply Voltage: 20-30 V dc 2amp • Current Consumption: 100mA or less-load current excluded. When including the load current, add 200mA to this value.
  • Page 20: Appendix B: Points To Be Checked After Installation

    WATERCOMPASS FM300-US FLOW MONITOR: APPENDIX B Appendix B: Points to be Checked After Installation Is the unit connection cable attached as shown? Are the screws tightened firmly? Are the alignment guides touching the lower brackets? Are the scales on both sides...
  • Page 21: Appendix C: Changing Flow Direction

    WATERCOMPASS FM300-US FLOW MONITOR: APPENDIX C Appendix C: Changing Flow Direction Unlock the flow monitor. Press and hold the mode button and the down arrow together until UNLOCK displays. Press and hold the Mode button until the current verbage on the screen begins flashing.
  • Page 22 WATERCOMPASS FM300-US FLOW MONITOR: APPENDIX C Appendix C: Changing Flow Direction, cont. Press and hold the Mode button to save the changes. Lock the Flow Monitor back up to prevent further changes. Press and hold the mode button and the down arrow together until LOCK displays.
  • Page 23: Appendix D: Troubleshooting Decoders

    WATERCOMPASS FM300-US FLOW MONITOR: APPENDIX D Appendix D: Troubleshooting Decoders A multimeter is needed when troubleshooting decoders. The decoder is not responding Symptom: No Connect on OXR controller. Check connections and polarity from decoder to controller. Ensure that black to black is connected and red to red is connected.
  • Page 24: General Cautions

    WATERCOMPASS FM300-US FLOW MONITOR: SAFETY PRECAUTIONS SAFETY PRECAUTIONS FOR THE FM300-US FLOW MONITOR General Cautions • Do not use the FM300-US Flow Monitor out of the specification ranges. Comply with the contents described in this instruction manual when using the product.
  • Page 25: Precautions For Installation

    WATERCOMPASS FM300-US FLOW MONITOR: SAFETY PRECAUTIONS Safety Precautions for the FM3000-US Flow Monitor, cont. Precautions for Installation Do not install the FM300-US Flow Monitor in locations used as footholds • Install the FM300-US Flow Monitor at a location where the inside the measuring pipe is always filled with the fluid.
  • Page 26: Precautions For Wiring

    WATERCOMPASS FM300-US FLOW MONITOR: SAFETY PRECAUTIONS Safety Precautions for the FM3000-US Flow Monitor, cont. Precautions for Wiring • Before wiring the FM300-US Flow Monitor, check the colors of wires. • Use the FM300-US Flow Monitor within the rated range. The FM300-US Flow Monitor is a product that uses a DC (direct current) power source.
  • Page 27 CUSTOMER SERVICE support@hydropoint.com Toll-free 800.362.8774 Fax 707.769.9695 ORDERING/SALES orders@hydropoint.com 707.769.9696 Fax 707.769.9695 RevA20200317 © Copyright 2019 HydroPoint Data Systems, Inc. All rights reserved. RevB 20190628...
