- Page 1 P20 AC OPERATION AND MAINTENANCE MANUAL 5618 Copley Drive San Diego, CA 92111-7902 TEL: (858) 565-8500 FAX: (858) 565-8808 www.rosys.com 21-30265 REV A...
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARRANTY ........................III CUSTOMER ASSISTANCE ................... IV CHANGE RECORD ......................V WARNINGS ......................1 DESCRIPTION ......................1 PRODUCT SPECIFICATIONS ................2 INSTALLATION/ GENERAL FUNCTIONALITY ............3 CONNECTOR WIRING/CONFIGURATIONS ............ -
Page 3: Warranty
The laws of the State of California shall govern this warranty. In the event the defect is determined to be within the terms of this warranty then ROS agrees to repair and/or replace (at ROS' discretion) the product or defective portion at no charge to the Purchaser. -
Page 4: Customer Assistance
CUSTOMER ASSISTANCE ROS, Inc. uses a worldwide network of stocking distributors and representatives who are familiar with our products and are able to provide assistance during installation and/or operation of these products. If you have any questions or problems with this product that are not covered by this manual or instruction, please contact our agent in your area, or contact us directly by phone or FAX or e-mail. -
Page 5: Change Record
CHANGE RECORD DESCRIPTION DATE PRODUCTION RELEASE (EC-02661) 27MAR17 21-30265 REV A... -
Page 6: Warnings
1 WARNINGS WARNING: Assembly, disassembly, connecting cables, disconnection of cables, must only occur when the P20 is disconnected from the power source. • Be careful when handling the positioner and/or cables due to exposed male pins on the connectors. The pins can be damaged if they are bumped excessively. Any damage may result in difficulty when connecting cables or possible flooding for those connections that are underwater. -
Page 7: Product Specifications
Shell Tellus 10 or eq. Environmental Depth Rating Air: 100ft (30.5m) Oil: 20000ft (6000m) Min/Max Operating Temperature 0°C to 50°C Storage Temperature -20°C to 60°C Electrical Max Power Draw 0.14A Input Voltage 120 VAC Control System Analog w/optional ROS controller(s) available 21-30265 REV A... -
Page 8: Installation/ General Functionality
To install your new positioner, use the bolt pattern provided on each output shaft or an available ROS mounting bracket. Note that your connector configuration will have a specific wiring configuration. The wiring for your positioner will be designated on the... -
Page 9: Connector Wiring/Configurations
The P20 is intended to be maintenance free. Be sure to clean your positioner with fresh water after each deployment. A visual inspection is always helpful in assessing the integrity of the positioner. In the event the positioner stops working, please contact ROS customer service. For troubleshooting see Section 7.
