- Page 1 OPERATION AND MAINTENANCE MANUAL 5618 Copley Drive San Diego, CA 92111-7902 TEL: (858) 565-8500 FAX: (858) 565-8808 www.rosys.com 21-30134 REV A...
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARRANTY ........................III CUSTOMER ASSISTANCE ................... IV CHANGE RECORD ......................1 WARNINGS ......................2 DESCRIPTION ......................2 PART NUMBER CONFIGURATION ............... 3 PRODUCT SPECIFICATIONS ................3 INSTALLATION/ GENERAL FUNCTIONALITY ............ -
Page 3: Warranty
The laws of the State of California shall govern this warranty. In the event the defect is determined to be within the terms of this warranty then ROS agrees to repair and/or replace (at ROS' discretion) the product or defective portion at no charge to the Purchaser. -
Page 4: Customer Assistance
CUSTOMER ASSISTANCE ROS, Inc. uses a worldwide network of stocking distributors and representatives who are familiar with our products and are able to provide assistance during installation and/or operation of these products. If you have any questions or problems with this product that are not covered by this manual or instruction, please contact our agent in your area, or contact us directly by phone or FAX or e-mail. -
Page 5: Change Record
CHANGE RECORD DESCRIPTION DATE PRODUCTION RELEASE (EC-01968) 02APR14 21-30134 REV A... -
Page 6: Warnings
If the P20 is oil-filled, it is pressure compensated by use of a Bellofram seal. This provides a slight internal pressure to minimize shaft seal drag and potential leakage problems due to hydrostatic pressure. -
Page 7: Part Number Configuration
B=OIL FILLED N=NO ANODE 02=LPMBH-4-MP BRASS IMPULSE T= TITANIUM HOUSING (NO ANODE) Example: 21-30082-A01 = P20 - AIR FILLED WITH ANODE, MCBH-4-MP CONNECTOR 4 PRODUCT SPECIFICATIONS Mechanical Housing Material (optional) Hard Anodized 6061 AL (6AL-4V TI) Dimensions Air: 8.1” L x 10.4” H x 3” D Oil: 9.8”... -
Page 8: Installation/ General Functionality
To install your new positioner, use the bolt pattern provided on each output shaft or an available ROS mounting bracket. Note that your connector configuration will have a specific wiring configuration. The wiring for your positioner will be designated on the... -
Page 9: Connector Wiring/Configurations
BRASS IMPULSE 7 ROUTINE MAINTENANCE The P20 is intended to be maintenance free. Be sure to clean your positioner with fresh water after each deployment. A visual inspection is always helpful in assessing the integrity of the positioner. In the event the positioner stops working, please contact ROS customer service. -
Page 10: Reference Documents
9 REFERENCE DOCUMENTS DOC NUMBER ROS DOCUMENT DESCRIPTION 10-00234 APPLICATION NOTE, INTERCONNECTING RS-485 COMPONENTS 21-30022 RS-485 COMMUNICATION PROTOCOL 21-30034 HELIOS CONTROL SOFTWARE 21-30135 INSTALLATION AND OUTLINE DRAWING 21-03030 HELIOS MANUAL 21-30134 REV A...
