- Page 1 HA1 Hybrid Audio Kit OPERATION GUIDE...
- Page 2 About This Manual This manual covers the installation and usage of the HA1 Hybrid Audio Kit for use with the SoniClear digital recording software product and communications software products. Revision Date: 6/14/21 Printed in the United States. © Copyright 2021 Trio Systems LLC All rights reserved.
-
Page 3: Table Of Contents
Overview ............................... 5 Using Microphone and Headphone ....................... 5 Additional Usage Notes ........................6 Resetting All Controls ........................... 6 HA1 Hybrid Audio Kit Installation ......................9 Evo 4 Hardware Installation ........................9 Overview ............................... 9 USB Interface ............................9 Power Connection ..........................9 Audio Connections .......................... -
Page 5: Evo 4 Operation
Teams. It also works with softphone programs, such as 8x8 Work, Vonage, Ring Central, and Avaya. The Evo 4 must be installed correctly before use. See the section below, “HA1 Hybrid Audio Kit Installation”. After installation, the Evo 4 interface will turn on automatically when the computer is started, making it immediately ready for teleconferencing and for recording in SoniClear. -
Page 6: Additional Usage Notes
Additional Usage Notes 1. In normal use only the control button for adjusting the headphone level will need to be used. The other buttons on the Evo 4 should not be pressed. For example, the “48V” button in the upper left corner should always be on (illuminated red). - Page 7 Select “Show EVO Control” to display the Evo 4 control panel: Click on the File/Open pulldown menu selection to open the Load Mixer window:...
- Page 8 Select the SoniClear setting shown there and click the Load button to reset the Evo 4 to the default values. Note that it may appear that the Load button is disabled when it is in fact working. Hovering the mouse...
-
Page 9: Ha1 Hybrid Audio Kit Installation
Evo 4 Hardware Installation Overview The HA1 Hybrid Audio Kit is based on the Audient Evo 4 USB audio interface. It includes the parts needed for recording Windows communication software, such as a Zoom online conference IP telephone “softphone”. Included in the kit are:... -
Page 10: Evo 4 Software Installation
Download SoniClear Presets The Evo 4 requires special configuration for compatibility with SoniClear. Depending on which version you have installed, SoniClear presets for the Evo 4 may be available in the SoniClear program presets folder: C:\Program Files (x86)\SoniClear97\Presets... - Page 11 This will display the Evo 4 Control panel:...
- Page 12 Driver Settings Set the driver Sample Rate to 44.1 kHz by selecting that option from the Setup pulldown menu:...
- Page 13 Save Mixer Presets It is important to save these presets in the Evo 4 Control panel so that the SoniClear user can restore the correct settings in case they pressed one of the setting buttons by accident.
-
Page 14: Evo 4 Loopback Settings
“loop back” audio from the computer back into another program in the computer. In this case, the Zoom or softphone audio is sent to the Evo 4 device, and then sent back to SoniClear to be recorded using the “Loopback Device” provided by the Evo 4 drivers. -
Page 15: Default Headphone Settings
If you make changes to these settings, be aware that setting the values incorrectly may result in feedback or echo problems with the communications software, or loss of audio for recording in SoniClear. The way the loopback in configured in the presets, the following is happening in the mixer: Audio input from the microphone (MIC 1) and computer speaker output (MIC 2) is sent to the left loopback channel. -
Page 16: Audio Loopback Cable
Audio Loopback Cable The HA1 Hybrid Audio Kit includes a hardware audio cable for looping audio back from the computer into Channel 2 of the mixer. The purpose of this cable is to allow other programs on the computer to play audio into the teleconference software and be recorded in SoniClear. -
Page 17: Soniclear Software Configuration For Evo 4
SoniClear Software Configuration for Evo 4 The SoniClear software must be manually set to the correct configuration to work with the Evo 4 interface. To do this, start SoniClear and select Edit/Preferences from the pulldown menu. Recording Options Tab - Sound Quality In the Recording Options preferences tab, set the recording format. -
Page 18: Playback Device Selection
Default Speaker Device Selection This is the sound card that will be used for playback. To listen to SoniClear playback through the Evo 4 headphone jack, select “Main Output 1/2 (Audient EVO)”. Removable Recording Device The “Use Removable Device If Present”... - Page 19 Monitor Delay Monitor Delay should be set to the default of 3 seconds. Force Recording at 44.1KHz. This field should be set to Unchecked.
-
Page 20: Transcriber Live Software Configuration For Evo 4
Transcriber Live Software Configuration for Evo 4 When Transcriber Live is used with SoniClear Court Recorder 9, audio for a readback can be played so that it is heard by the teleconference participants. The included hardware cable sends this readback audio from the computer headphone jack into Channel 2 of the Evo 4 interface. -
Page 21: Advanced Playback Options
Advanced Playback Options These options control how playback is processed. These fields should only be changed in the event of problems with playback using the default settings. Consult SoniClear support for assistance if this happens. Monitor Delay Monitor Delay should be set to the default of 3 seconds. -
Page 22: Communication Software Configuration For Evo 4
With this configuration the audio being played back can be heard by the conference call participants and on the Evo kit monitoring headphone. The playback audio will also be recorded in SoniClear. A typical application would be to play a video file on the computer for conference participants to hear.
