Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
AGQ7000ES0
Series
Frigidaire
Market
North America
Color
white
Volts
120
Wiring Diagram
134682200
Owner's Guide
134609100
Installation Instructions 134732700
Operating Instructions 134609300
Publication No.
5995464541
06/04/03
(EN/SERVICE/WC)
361
Copyright
GAS DRYER
Model No.
AGQ7000E
©
2006 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire AGQ7000E
Summary of Contents for Frigidaire AGQ7000E
-
Page 1: Gas Dryer
Series Frigidaire Market North America Color white Volts Wiring Diagram 134682200 Owner's Guide 134609100 Installation Instructions 134732700 Operating Instructions 134609300 GAS DRYER Model No. AGQ7000E Publication No. 5995464541 06/04/03 (EN/SERVICE/WC) © Copyright 2006 Electrolux Home Products, Inc. All rights reserved. - Page 2 Publication No: 5995464541 AGQ7000ES0 CABINET/DRUM 04/06...
- Page 3 Housing, gas heater assy, w/seal Baffle, heater shield Screw, 10-16AB x 0.375 Bracket, top panel mtg., rear Drum, dryer, stainless steel, service kit Glide, drum Screw, hex washer head, 8-18 x 0 .375, cup point Screw, quadrex head, 10-14 x 1.00, vane mtg., special...
- Page 4 Publication No: 5995464541 AGQ7000ES0 FRONT PANEL/LINT FILTER 04/06...
- Page 5 POS. NO PART NO. 134417000 131168200 134382900 131845802 131633200 134440100 134440200 5308027429 134134700 134733510 131744202 134548000 26 # 131843101 131450300 134440000 134737200 131243700 134559200 134559410 131205100 134559540 134680900 134559300 134720900 134611800 134580300 134558540 134558410 134554500 134548100 131303300 134529600 134558600 134550600 58 # 131843500 58*#...
- Page 6 Publication No: 5995464541 AGQ7000ES0 CONTROLS/TOP PANEL 04/06...
- Page 7 POS. NO PART NO. 134557200 134551210 134553100 134556500 134347700 134555510 134553410 134595610 134553300 134557501 134552800 134600000 134402900 22 # 134602100 23 # 134394400 23*# 134491500 134557000 134178901 134365000 134553200 134557300 57 # 134503300 # Functional Parts * Non-Illustrated Parts AGQ7000ES0 CONTROLS/TOP PANEL DESCRIPTION Control Board, printed circuit, with housing...
- Page 8 Publication No: 5995464541 AGQ7000ES0 MOTOR 04/06...
- Page 9 Spacer, idler Thermistor, control Screw, hex head, 1/4-20T x 1.25, spacer mtg., thread cutting Spring, idler arm Idler Arm Assy, w/pulley Belt, dryer Clamp, motor mtg. Motor & Pulley Assy Screw, pan head, 8-18AB x 0.375 Bracket, motor mtg Seal, exhaust tube Screw, pan head, 8-18B x 0.31...
- Page 10 Publication No: 5995464541 AGQ7000ES0 BURNER 04/06...
- Page 11 POS. NO PART NO. 131168200 131243700 55 # 134389600 134122000 134144900 08015112 134128700 134185100 69 # 5308015194 70 # 5303207409 71 # 5303307291 72 # 5303307292 73 # 5303207410 74 # 134192000 77 # 134197700 79 # 5303281135 80 # 134200801 134315100 # Functional Parts...
-
Page 12: Wiring Diagram
