- Page 1 Manual AromaStreamer ® Wi-Fi www.duftmarketing.de...
-
Page 2: Table Of Contents
CONTENT Technical Details Equipment Areas of application Control elements Initial start-up/Change of scent bottle Installation - Wall mounting Connection to air conditioning and/or ventilation system Power connection/Power on/off App-Registration Configuration of your device AromaStreamer settings - via App ® Optional usage with adapter Cleaning of your AromaStreamer ®... -
Page 3: Technical Details
1. Technical Details Model Dimension (mm) Voltage Power Coverage AS650 Wi-Fi 260*200*95 12 V 10 W 150m²; 450m³ 2. Accessories Please check the completeness of your delivery. If any of the parts listed below is missing or damaged, please contact us. - AromaStreamer ®... -
Page 4: Areas Of Application
3. Places of application Hotels, Meeting Rooms, Malls, Exhibition Halls, Brand retail stores, Bars, SPA‘s, Business places and wherever you want to enjoy a pleasant scent experience. Scent marketing with your AromaStreamer knows (almost) no limits. ® 4. Control elements... -
Page 5: Initial Start-Up/Change Of Scent Bottle
5. Initial start-up/Change of scent cartridge Please remove the atomization unit by pulling it straight up. Please use the handle (see red arrow) (1). Initial start-up: Screw the supplied scent bottle carefully into the atomization unit (2). Change of scent cartridge: Unscrew the empty scent cartridge and screw the new scent cartridge into the nebulization unit (2). -
Page 6: Installation - Wall Mounting
6. Installation - Wall mounting Take out the wall bracket as well as the screws and dowels from the box. Fix the bracket as shown (2) on the wall. Now, hang the AromaStreamer into the ® bracket. 7. Connection to air conditioning and/or ventilation system RIGHT APPLICATION Only with continuous air flow &... -
Page 7: Power Connection/Power On/Off
7. Connection to air conditioning and/or ventilation system WRONG APPLICATION 3. FALSE IF: You assemble the red marked surface against the direction of the air flow. Then, the scent will not have the desired effect and will be pressed back into the scent device. -
Page 8: App-Registration
9. App-Registration First go to your App Store/Google Play Store and install the app „Scent-WIFI“. After success- fully downloading and installing it, you can open the app and start the registration process. You can choose between an email registration or a mobile registration. 9.1 E-mail registration: Don´t have an account? Sign up - Press... - Page 9 9. App-Registration 9.2 Mobile registration: Don´t have an account? Sign up - On the start screen of the app, press (E). - Country: Select country and Phone: Enter your mobile phone number required (F) - After sending, you will receive a 6-digit activation code from TAOVIP (G) via SMS. - Now enter the following information (H): ↳...
-
Page 10: Configuration Of Your Device
10. Device configuration IMPORTANT: Before configuration make sure that Your device (smartphone, tablet,...) is at the same Wi-Fi network as the AromaStreamer will be (4+5 ) . Unlock the device by holding down E + F until you hear a ®... - Page 11 10. Device configuration - Now select the desired Wi-Fi and enter the corresponding Wi-Fi password (5). - Now press Next Step. - Follow the instructions in the app. (6-8) - Your desired AromaStreamer is now in your device list (Ungrouped device) (6). ®...
-
Page 12: Aromastreamer ® Settings - Via App
11. AromaStreamer settings - via App ® Click on the relevant AromaStreamer to open the settings menu. ® IMPORTANT: If the fill level indicator (during first start-up) does not show right, the AromaStreamer must be recalibrated. ® ↳ Remove nebulization unit (bottle can stay) ↳... - Page 13 11. AromaStreamer settings - via App ® The start time: desired start time The end of time: desired end time Set the active and inactive days (12). Green field: active days white field: inactive days Grade (intensity level): Set the intensity level. You can select from Level 1 to 20. (12) (Save): ✓...
- Page 14 11. AromaStreamer settings - via App ® - Menu - Language (language choice between Chinese & English) - Feedback - My center - Logout • Change of personal password possible - About us (current app version) If you do not want to change anything on your AromaStreamer , close the app.
-
Page 15: Optional Usage With Adapter
12. Optional usage with adapter The AromaStreamer 650 Wi-Fi can also be connected to a flexible tube, so it will ® be possible to place it invisibly, for example behind a counter. Therefore, screw the supplied adapter into the nebulization unit on top of the device. Then click the tube into the adapter and guide the tube into the room or the area that should be fragranced or into your HVAC or ventilation channel. -
Page 16: Cleaning Of Your Aromastreamer
13. Cleaning of your AromaStreamer ® We recommend a cleaning of the device in the following cases: 1. General cleaning with every scent change. 2. Cleaning when the nebulization becomes lower. Cleaning steps: 1. Fill a small amount of the system cleaner into an empty scent bottle and screw it into the nebulization unit. - Page 17 REIMA AirConcept GmbH ® Seiferitzer Allee 7 08393 Meerane/Germany Tel.: +49-3764-79560-0 Fax: +49-3764-79560-20 info@duftmarketing.de www.duftmarketing.de www.duftdisplay.de www.scent-display.com www.duftoase.de...
