PRODUCT NO.
GLDB953CB0
GLDB953CS0
MARKET
North America
SERVICE DATA SHEET # - 154444501
OWNER'S GUIDE # - 154446701
INSTALLATION INSTRUCTIONS # - 154427301
ENERGY GUIDE LABEL # - 154399013
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
BASE MODEL NO.
SERIES
GLDB953C
24" Built-in
GLDB953C
24" Built-in
Publication No.
5995392247
-EN/SERVICE /ECL
FACTORY PARTS CATALOG
COLOR
black
white
030630
©2003 Electrolux Home Products, Inc.
821
All rights reserved
DISHWASHER
24" Built-In
DISHWASHER
Model No.
GLDB953C
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire GLDB953C
Summary of Contents for Frigidaire GLDB953C
- Page 1 PRODUCT NO. BASE MODEL NO. GLDB953CB0 GLDB953C GLDB953CS0 GLDB953C MARKET North America SERVICE DATA SHEET # - 154444501 OWNER’S GUIDE # - 154446701 INSTALLATION INSTRUCTIONS # - 154427301 ENERGY GUIDE LABEL # - 154399013 ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917...
-
Page 2: Control Panel
Publication No. GLDB953C 5995392247 CONTROL PANEL 07/03... - Page 3 A = GLDB953C (GLDB953CS0) B = GLDB953C (GLDB953CB0) POS. NO 34 # # = Fast Moving Part * = Non-Illustrated Part CONTROL PANEL PART NO DESCRIPTION 154370301 Panel,control ,white 154370303 Panel,control ,black 154445001 Insert,control panel ,white 154445003 Insert,control panel ,black...
- Page 4 Publication No. GLDB953C 5995392247 DOOR 07/03...
- Page 5 A = GLDB953C (GLDB953CS0) B = GLDB953C (GLDB953CB0) POS. NO # = Fast Moving Part * = Non-Illustrated Part DOOR PART NO DESCRIPTION 154430601 Spring,door ,(2) 154325201 Linkage,door spring ,(2) 154093301 Screw,arm assy ,(4) 154325304 Arm Assy,LH 154325303 Arm Assy,RH...
- Page 6 Publication No. GLDB953C 5995392247 07/03...
- Page 7 A = GLDB953C (GLDB953CS0) B = GLDB953C (GLDB953CB0) POS. NO 24 # 25 # 29 # # = Fast Moving Part * = Non-Illustrated Part PART NO DESCRIPTION 154209301 Tub assy,w/frame parts 154429101 Strike,door 154200602 Screw,10-16 x 3/8 ,hex 154211801...
-
Page 8: Motor & Pump
Publication No. GLDB953C 5995392247 MOTOR & PUMP 07/03... - Page 9 A = GLDB953C (GLDB953CS0) B = GLDB953C (GLDB953CB0) POS. NO 24A* 70 # # = Fast Moving Part * = Non-Illustrated Part MOTOR & PUMP PART NO DESCRIPTION 154247601 Heater 154106201 Nut,heater ,(2) 154289801 Shield,heater terminal 154359701 Bracket,heater ,(2) 154245501...
- Page 10 Publication No. GLDB953C 5995392247 FRAME 07/03...
- Page 11 A = GLDB953C (GLDB953CS0) B = GLDB953C (GLDB953CB0) POS. NO # = Fast Moving Part * = Non-Illustrated Part FRAME PART NO DESCRIPTION 154445901 Valve,water 154208701 Brace,front frame 154322901 Toeplate,adjustable ,white 154322903 Toeplate,adjustable ,black 154397201 Kickplate Assy,white ,w/foam 154397203 Kickplate Assy,black ,w/foam...
- Page 12 Publication No. GLDB953C 5995392247 RACKS 07/03...
- Page 13 A = GLDB953C (GLDB953CS0) B = GLDB953C (GLDB953CB0) POS. NO # = Fast Moving Part * = Non-Illustrated Part RACKS PART NO DESCRIPTION 154319706 Rack assy,lower 154295201 Basket,silverware 154319506 Rack assy,upper 5304407064 Wheel & bushing assy,upper rack 5300809927 Cap,slide ,(4)
