PRODUCT NO.
GLDB653JT0
MARKET
North America
SERVICE DATA SHEET # - 154296905
OWNER'S GUIDE # - 154255603
WIRING DIAGRAM # - 154296905
101 Masters Blvd.
Anderson, SC 29624
BASE MODEL NO.
SERIES
GLDB653J
GALLERY
Publication No.
5995341954
-EN/SERVICE /ECL
FACTORY PARTS CATALOG
COLOR
almond
000728
821
©2000 White Consolidated Industries, Inc.
All rights reserved
DISHWASHER
24" BUILT IN
DISHWASHER
Model No.
GLDB653J
Advertisement
Related Manuals for Frigidaire Gallery GLDB653J
Summary of Contents for Frigidaire Gallery GLDB653J
- Page 1 PRODUCT NO. BASE MODEL NO. GLDB653JT0 GLDB653J MARKET North America SERVICE DATA SHEET # - 154296905 OWNER’S GUIDE # - 154255603 WIRING DIAGRAM # - 154296905 101 Masters Blvd. Anderson, SC 29624 FACTORY PARTS CATALOG SERIES COLOR GALLERY almond Publication No.
-
Page 2: Control Panel
Publication No. GLDB653JT0 5995341954 CONTROL PANEL 07/00... - Page 3 POS. NO # = Fast Moving Part * = Non-Illustrated Part GLDB653JT0 CONTROL PANEL PART NO DESCRIPTION 154368205 Panel-control,almond 154372302 Insert-control pnl,almond 154295701 Timer 154131203 Shield-timer 154095701 Screw-timer,thread rolling ,(2) 154214701 Switch-selector,6 button 154248601 Shield-switch 5303318719 Screw,mtg. 154239505 Knob-timer,almond 154283701 Vapor Weldment Assy 154229201 Seal-chamber...
- Page 4 Publication No. GLDB653JT0 5995341954 DOOR 07/00...
- Page 5 POS. NO 12 # # = Fast Moving Part * = Non-Illustrated Part GLDB653JT0 DOOR PART NO DESCRIPTION 154365701 Spring-door,(2) 154325201 Spring linkage,(2) 154093301 Screw-arm assy,(4) 154325304 Arm Assy,LH 154325303 Arm Assy,RH 154211501 Pin-arm 154079601 Nut-arm assy,(4) 154299002 Door-inner assy 154226601 Liner grate 154230101...
- Page 6 Publication No. GLDB653JT0 5995341954 07/00...
- Page 7 POS. NO 24 # 25 # 28 # 28A* 29 # # = Fast Moving Part * = Non-Illustrated Part GLDB653JT0 PART NO DESCRIPTION 154209301 Tub assy,w/frame parts 154211601 Strike-door 154211801 Gasket-tub 154200602 Screw,10-16 x 3/8 ,hex 154333901 Roller-tub 5303943103 Screw w/washer,(8) 154239801 Tubing-water inlet...
-
Page 8: Motor & Pump
Publication No. GLDB653JT0 5995341954 MOTOR & PUMP 07/00... - Page 9 POS. NO 24A* 70 # # = Fast Moving Part * = Non-Illustrated Part GLDB653JT0 MOTOR & PUMP PART NO DESCRIPTION 154247601 Heater 154106201 Nut-heater,(2) 154289801 Shield-heater terminal 154359701 Bracket-heater,(2) 154245901 Macerator 154245501 Cover-volute 154245801 Impeller 154282701 Screw,ss impeller 154246801 Gasket-sump 154365902 Housing-sump...
- Page 10 Publication No. GLDB653JT0 5995341954 FRAME 07/00...
- Page 11 POS. NO # = Fast Moving Part * = Non-Illustrated Part GLDB653JT0 FRAME PART NO DESCRIPTION 154359801 Valve-water 154208701 Brace-front 154322903 Toeplate-adjustable 154370703 Kickplate/Baffle Assy,black 5300808658 Screw,#8A x .375" 154200601 Screw-#10-16 x 3/8 154210901 Screw-leveling 154209601 Cover-junction box 154227401 Guard-motor 154041001 Screw,plask #1 ,10-10 x 9/16 154200602...
- Page 12 Publication No. GLDB653JT0 5995341954 RACKS 07/00...
- Page 13 POS. NO # = Fast Moving Part * = Non-Illustrated Part GLDB653JT0 RACKS PART NO DESCRIPTION 154320904 Rack assy-lower 154295201 Basket-Silverware 154321107 Rack assy-upper 5304407064 Wheel & bushing assy,upper rack 5300809927 Cap-slide,(4) 154232701 Slide-rack,(2) 154174501 Wheel & bracket assy,lower rack 154304001 Base-funnel 154251801...
