Now to insert both the valve
support frame and the push rod
into the piston shell, use your
index finger to push on the
spring. This will set everything
into place and you will hear
a click. If the parts aren't
fitting together, just lift both
subassemblies out and try again.
Insert the upper valves into the
bottom of the upper area,
snapping them into the valve
support frame.
To test the piston pull the push
rod up and press it down a few
times. It should click in both
directions.
