PRODUCT NO.
FDBC56BAB0
FDBC56BAS0
SERVICE DATA SHEET # - 154396201
OWNER'S GUIDE # - 154393301
INSTALLATION INSTRUCTIONS # - 154373601
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
BASE MODEL NO.
COLOR
FDBC56BA
black
FDBC56BA
white
Publication No.
5995360392
011024
-EN/SERVICE /MLR
821
FACTORY PARTS CATALOG
MARKET
North America
North America
24" Built In
DISHWASHER
Model No.
FDBC56BA
©2001 White Consolidated Industries, Inc.
All rights reserved
DISHWASHER
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FDBC56BA
Summary of Contents for Frigidaire FDBC56BA
- Page 1 PRODUCT NO. BASE MODEL NO. FDBC56BAB0 FDBC56BA FDBC56BAS0 FDBC56BA SERVICE DATA SHEET # - 154396201 OWNER’S GUIDE # - 154393301 INSTALLATION INSTRUCTIONS # - 154373601 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. Box 212378, Augusta, GA 30917 FACTORY PARTS CATALOG COLOR...
-
Page 2: Control Panel
Publication No. FDBC56BABO/S0 5995360392 CONTROL PANEL 10/01... - Page 3 A = FDBC56BAS (FDBC56BAS0) B = FDBC56BAB (FDBC56BAB0) POS. NO # = Fast Moving Part * = Non-Illustrated Part FDBC56BABO/S0 CONTROL PANEL PART NO DESCRIPTION 154368204 Panel,control ,white 154368206 Panel,control ,black 154409801 Insert,control panel 154409803 Insert,control panel 154409001 Timer 154095701 Screw,thread rolling ,(2) ,timer 154131203 Shield,timer...
- Page 4 Publication No. FDBC56BABO/S0 5995360392 DOOR 10/01...
- Page 5 A = FDBC56BAS (FDBC56BAS0) B = FDBC56BAB (FDBC56BAB0) POS. NO 12 # 12 # # = Fast Moving Part * = Non-Illustrated Part FDBC56BABO/S0 DOOR PART NO DESCRIPTION 154365701 Spring,door ,(2) 154325201 Linkage,door spring ,(2) 154093301 Screw,arm assy ,(4) 154325304 Arm Assy,LH 154325303 Arm Assy,RH...
- Page 6 Publication No. FDBC56BABO/S0 5995360392 10/01...
- Page 7 A = FDBC56BAS (FDBC56BAS0) B = FDBC56BAB (FDBC56BAB0) POS. NO 24 # 25 # 28 # 28A* 29 # # = Fast Moving Part * = Non-Illustrated Part FDBC56BABO/S0 PART NO DESCRIPTION 154209301 Tub assy,w/frame parts 154211601 Strike,door 154211801 Gasket,tub 154200602 Screw,10-16 x 3/8 ,hex 154333901...
-
Page 8: Motor & Pump
Publication No. FDBC56BABO/S0 5995360392 MOTOR & PUMP 10/01... - Page 9 A = FDBC56BAS (FDBC56BAS0) B = FDBC56BAB (FDBC56BAB0) POS. NO 24A* 70 # # = Fast Moving Part * = Non-Illustrated Part FDBC56BABO/S0 MOTOR & PUMP PART NO DESCRIPTION 154247601 Heater 154106201 Nut,heater ,(2) 154289801 Shield,heater terminal 154359701 Bracket,heater ,(2) 154245501 Cover,volute 154246801...
- Page 10 Publication No. FDBC56BABO/S0 5995360392 FRAME 10/01...
- Page 11 A = FDBC56BAS (FDBC56BAS0) B = FDBC56BAB (FDBC56BAB0) POS. NO # = Fast Moving Part * = Non-Illustrated Part FDBC56BABO/S0 FRAME PART NO DESCRIPTION 154373301 Valve,water 154208701 Brace,front frame 154322901 Toeplate,adjustable ,white 154322903 Toeplate,adjustable ,black 154397201 Kickplate Assy,white ,w/ foam 154397203 Kickplate Assy,black ,w/ foam 154371301...
- Page 12 Publication No. FDBC56BABO/S0 5995360392 RACKS 10/01...
- Page 13 A = FDBC56BAS (FDBC56BAS0) B = FDBC56BAB (FDBC56BAB0) POS. NO # = Fast Moving Part * = Non-Illustrated Part FDBC56BABO/S0 RACKS PART NO DESCRIPTION 154319708 Rack assy,lower 154295201 Basket,silverware 154319506 Rack assy-upper 5303286384 Wheel,upper rack ,(4) 5300809927 Cap,slide ,(4) 154232701 Slide,rack ,(2) 154174501 Wheel &...
