PRODUCT NO.
FDBC24BAS1
MARKET
North America
SERVICE DATA SHEET # - 154414801
OWNER'S GUIDE # - 154395101
INSTALLATION INSTRUCTIONS # - 154415901
ENERGY GUIDE LABEL # - 154399001
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
BASE MODEL NO.
SERIES
FDBC24BA
Publication No.
5995374518
-EN/SERVICE /ECL
FACTORY PARTS CATALOG
COLOR
white
020618
©2002 Electrolux Home Products, Inc.
All rights reserved
821
DISHWASHER
24" Built In
DISHWASHER
Model No.
FDBC24BA
Advertisement
Related Manuals for Frigidaire FDBC24BA
Summary of Contents for Frigidaire FDBC24BA
- Page 1 PRODUCT NO. BASE MODEL NO. FDBC24BAS1 FDBC24BA MARKET North America SERVICE DATA SHEET # - 154414801 OWNER’S GUIDE # - 154395101 INSTALLATION INSTRUCTIONS # - 154415901 ENERGY GUIDE LABEL # - 154399001 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. Box 212378, Augusta, GA 30917...
- Page 2 Publication No. FDBC24BAS1 5995374518 CONTROL PANEL 06/02...
- Page 3 POS. NO # = Fast Moving Part * = Non-Illustrated Part CONTROL PANEL PART NO DESCRIPTION 154368101 Panel,control ,white 154409601 Insert,control panel ,white 154393902 Timer 154215301 Switch,selector ,2 button 154242201 Shield,switch 5303318719 Screw,mtg. 154236502 Pushbutton,white 154239504 Knob,timer ,white 154345102 Vapor Chamber Assy,w/vent gasket 154229201 Seal,chamber 154391201...
- Page 4 Publication No. FDBC24BAS1 5995374518 DOOR 06/02...
- Page 5 POS. NO 12 # # = Fast Moving Part * = Non-Illustrated Part DOOR PART NO DESCRIPTION 154345902 Spring,door ,(2) 154325201 Linkage,door spring ,(2) 154093301 Screw,arm assy ,(4) 154325304 Arm Assy,LH 154325303 Arm Assy,RH 154400601 Pin,arm assy 154079601 Nut,arm assy ,(4) 154299002 Door,inner assy 154332701...
- Page 6 Publication No. FDBC24BAS1 5995374518 06/02...
- Page 7 POS. NO 24 # 25 # 29 # # = Fast Moving Part * = Non-Illustrated Part PART NO DESCRIPTION 154209204 Tub,plastic 154429101 Strike,door 154211801 Gasket,tub 154200602 Screw,10-16 x 3/8 ,hex 154333901 Roller,tub 5303943103 Screw,w/washer ,(8) 154239801 Tubing,water inlet 5303318539 Clamp,tubing ,(2) 154411002 Hose,drain...
- Page 8 Publication No. FDBC24BAS1 5995374518 MOTOR & PUMP 06/02...
- Page 9 POS. NO 70 # # = Fast Moving Part * = Non-Illustrated Part MOTOR & PUMP PART NO DESCRIPTION 154247601 Heater 154106201 Nut,heater ,(2) 154289801 Shield,heater terminal 154359701 Bracket,heater ,(2) 154335301 Cover,volute 154246801 Gasket,sump 154365903 Housing,sump 154246502 Retainer,sump 154414201 Spray arm,lower ,w/heat shield 154335201 Nut,spray arm 154348401...
- Page 10 Publication No. FDBC24BAS1 5995374518 FRAME 06/02...
- Page 11 POS. NO # = Fast Moving Part * = Non-Illustrated Part FRAME PART NO DESCRIPTION 154373301 Valve,water 154208701 Brace,front frame 154322903 Toeplate,adjustable ,black 154397203 Kickplate Assy,black ,w/foam 5300808658 Screw,#8A x .375" ,black 154320101 Screw,serr ,#8-18 x 3/8 154419301 Screw,leveling 154209601 Cover,junction box 154041001 Screw,plask #1 ,10-10 x 9/16...
- Page 12 Publication No. FDBC24BAS1 5995374518 RACKS 06/02...
- Page 13 POS. NO # = Fast Moving Part * = Non-Illustrated Part RACKS PART NO DESCRIPTION 154331604 Rack assy,lower 5300808994 Basket,silverware 154331502 Rack assy,upper 5304407064 Wheel & bushing assy,upper rack 5300809927 Cap,slide ,(4) 154232701 Slide,rack ,(2) 154174501 Wheel & bracket assy,lower rack 5995374518 06/02...
