User Manual
In this User Manual, we're going to walk through how to set up the RapidScreen.
Right out of the box this unit will already be capable of scanning users and taking their
temperatures. Some changes may need to be made to the application based on your
individual requirements.
Compatible with the following model: RapidScreen Plus V3
TABLE OF CONTENTS
Quick Start Note..............................................................................................2
User Manual Note............................................................................................3
Connecting to the eFace software....................................................................4-7
Adding staff to facial recognition system........................................................8-10
Attribute Settings.............................................................................................11
Software Settings.............................................................................................12
Detailed Attribute Settings............................................................................13-17
Detailed Software Settings............................................................................18-22
Email Alert Setup ..........................................................................................................23
Email Alert Via Text..........................................................................................24
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SpinTouch RapidScreen PLUS V3
Summary of Contents for SpinTouch RapidScreen PLUS V3
-
Page 1: Table Of Contents
Right out of the box this unit will already be capable of scanning users and taking their temperatures. Some changes may need to be made to the application based on your individual requirements. Compatible with the following model: RapidScreen Plus V3 TABLE OF CONTENTS Quick Start Note………………………………………………………………………………….2 User Manual Note………………………………………………………………………………..3... -
Page 2: Quick Start Note
Quick Start Guide If you are just getting started you should first read the Quick Start Guide that can be found here: https://drive.google.com/file/d/184GuNMx1IZ8I2UUUPYu2gJx3l2fhG2Ed/ view?usp=sharing The Quick Start Guide section of this User Manual is designed to give you just the basic setup information you need to get started using the device as a temperature scanner. -
Page 3: User Manual Note
User Manual The rest of this document covers the advanced features of the device and also just document in detail the various menu options. While it is good to read through these sections to get a better understanding of how the device works, it is not necessary unless you run into any issues and want to troubleshoot them. -
Page 4: Connecting To The Eface Software
Connecting the Kiosk to the Eface Software Port 8085 needs to be open on your network for the Kiosk and Eface to function properly. Also you will need to register your device with its MAC in eFace before connecting this way. Pointing the Kiosk to the Eface Software: ●... - Page 5 ● With the phone, open the camera app and scan the QR code displayed. This will give you the MAC address for the Kiosk for later use in this setup process. ● Using the Eface software, login. ● click on Devices on the left hand side. ●...
- Page 6 ● Next Name your Device (reception). ● Enter in the MAC address of your Kiosk. This should be the Ethernet MAC address. ● Enter in the Department that you want your Kiosk to be associated with by clicking in the provided space.
- Page 7 ● Now your Kiosk is connected to the Eface software you can remotely view scans from the Kiosk and change and add settings as needed from the Eface software. ● When the Kiosk has successfully connected it will show Connected as below. Note: you may get an error, ignore this if it shows that you are connected.
-
Page 8: Adding Staff To Facial Recognition System
ADDING STAFF TO THE FACE DATABASE ON DEVICE You should not use this feature if you are going to use the eFace management software, instead register with eFace From the application’s main screen, press the right mouse button to bring up the password prompt. After entering the password (default 123456) click on the Personal Registration button. - Page 9 Do not register staff at the device this way if you are going to use eFace, register with eFace instead ● Personal Registration – Click the ADD button to register personnel information locally. Fill in all required fields below. Click on the person icon to add a photo for the person. Choose photograph to take a picture from the kiosk camera.
- Page 10 Adding Staff using the eFace software In the Eface software go to Registration -> Staff and then you can click on the blue Add button to register someone. Then you can click on the blue Face ID button at the right of the entry You can then upload a photo to attach to the entry - make sure the photo is no larger than 640 px * 480 px and that the file size does not exceed 500 kb.
-
Page 11: Attribute Settings
ATTRIBUTE SETTINGS *** It is VERY important that you do NOT click on the Synchronization Configuration button shown below at the top right of the Attribute Settings screen - this button is currently glitched and will cause problems ● Server Connections – Connecting the kiosk to the Eface backend software for remote management. -
Page 12: Software Settings
SOFTWARE SETTINGS *** It is VERY important that you do NOT click on the Synchronization Configuration button shown below at the top right of the Attribute Settings screen - this button is currently glitched and will cause problems ● General Settings - You can turn on card swiping, attendance, door opening, human body induction, stranger mode and save local information related settings according to your own needs ●... -
Page 13: Detailed Attribute Settings
ATTRIBUTE SETTINGS IN DETAIL ●Server Connection – See Connection Kiosk to Eface software. ●Face Settings – Be very careful what you change here, do NOT change the Distance value or else it can crash the app. It is suggest that you turn OFF the Monocular Live option, then save &... - Page 14 ATTRIBUTE SETTINGS IN DETAIL - FACE PARAMETERS 1.Mask Detection – Turn on if you require people to wear mask on premise. If turned on the kiosk will tell people who are not wearing a mask to wear a mask after taking their temperature. This will not stop them from getting their temperature taken.
- Page 15 ● Temperature Setting Be very careful what you change here. It’s best to lower the Effective Temperature down to 95 and then do a save & restart, this will help you do the automatic calibration option on this same screen. 1.Temperature Measuring peripherals –...
- Page 16 2. Display Temperature Zone – This setting is if you would like to display the temperature after the temperature is taken. 3. Temperature measurement serial port – Should always be set to ttyS3. 4. Temperature measuring rate – Should always be set to 115200. Temperature unit –...
- Page 17 ● Access records This will allow you to view all the records that the kiosk has taken. Selecting Export will allow you to save all the records to a connected USB drive to one of the kiosks USB ports. ● Speech Settings Status: Installed –...
-
Page 18: Detailed Software Settings
SOFTWARE SETTINGS IN DETAIL ● General Settings... - Page 19 ● Swipe Scene Close – Not used. Card – Swipe access card to trigger Relay connection Credit Card + Temperature measurement – Must swipe access card to take temperature. Credit Card + Face Verification – Must swipe card and be the same person associated with that card to get a temperature reading.
- Page 20 Home Screen Banner – This will display a banner at the bottom of the home screen. Pictured below Company Info – This will allow you to add a company name to the Home Screen Banner. Logo – This will allow you to add a Logo to Home Screen Banner. Display Only Stranger’s Temperature –...
- Page 21 ● Toggle Mode – Whether or not you are using the Eface software or if you are using the Kiosk as a Stand-Alone unit. ●Timer Switch - On / Off timer setting for days of the week. Select the ADD button. Click on the Boot Time Clock to select your boot on time.
- Page 22 ● Software Upgrade – Allows for updating the .apk application. Connect a USB drive with the desired .apk to one of the Kiosk USB ports and click on the Detect Upgrade button. ● Device Information – Displays information about the device ●...
-
Page 23: Email Alert Setup
EMAIL ALERT SETUP You can use any mail server that supports SMTP (Yahoo, Google, Exchange, etc). Use the Help button on the Email Alerts section of the eFace software for more information. You must either use 2-factor authentication or use an ‘app password’ to connect with the settings screen shown below: EMAIL ALERTS REQUIREMENTS Network Whitelist Items... -
Page 24: Email Alert Via Text
EMAIL ALERT VIA TEXT Enter your phone number followed by the correct carrier information. AT&T: number@txt.att.net (SMS), number@mms.att.net (MMS) T-Mobile: number@tmomail.net (SMS & MMS) Verizon: number@vtext.com (SMS), number@vzwpix.com (MMS) Sprint: number@messaging.sprintpcs.com (SMS), number@pm.sprint.com (MMS) Xfinity Mobile: number@vtext.com (SMS), number@mypixmessages.com (MMS) Virgin Mobile: number@vmobl.com (SMS), number@vmpix.com (MMS) Tracfone: number@mmst5.tracfone.com (MMS) Simple Mobile: number@smtext.com (SMS)
