Quick Start Guide
In this Guide Start Guide we're going to walk through how to set up the RapidScreen.
Right out of the box this unit will already be capable of scanning users and taking their
temperatures. Some changes may need to be made to the application based on your
individual requirements.
Compatible with the following model: RapidScreen Plus V3
TABLE OF CONTENTS
Unboxing and Stand Assembly Instruction......................................................................2
First Time Setup Notes.....................................................................................3-4
Included In The Box / Mouse Instruction..........................................................................5
Existing / Closing the Application.....................................................................................6
Connecting to WiFi.............................................................................................................7
Changing The Time Zone...................................................................................................8
Volume & Brightness Controls............................................................................9
User Manual Notes.......................................................................................10-11
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SpinTouch RapidScreen PLUS V3
Summary of Contents for SpinTouch RapidScreen PLUS V3
-
Page 1: Table Of Contents
Right out of the box this unit will already be capable of scanning users and taking their temperatures. Some changes may need to be made to the application based on your individual requirements. Compatible with the following model: RapidScreen Plus V3 TABLE OF CONTENTS Unboxing and Stand Assembly Instruction..............2 First Time Setup Notes…..…………………………………………..………………………...3-4... -
Page 2: Unboxing And Stand Assembly Instruction
RAPIDSCREEN STAND ASSEMBLY INSTRUCTIONS The videos on this page demonstrate how to unbox your new device, and assemble with a stand as well as where to put the cables. -
Page 3: First Time Setup Notes
Important First Time Setup Notes Step By Step Notes From The Video -------------------------------------- Accessing Settings Options To access the settings menu do a long press & hold at the top left of the screen (or right-click with mouse) at the scanning screen, and then enter the password which by default is 123456 Showing Temperature Results Go into the General Settings and then into Information Display Settings, turn OFF the Hide Temperature option, save &... - Page 4 Important First Time Setup Notes Continued Step By Step Notes From The Video Continued -------------------------------------- Turning Off Monocular Live (optional for faster performance) Go into Face Settings and turn OFF the Monocular Live option, save & restart. This option simply tries to determine if it is a live individual before scanning (rather than a prankster holding up a photo) but it makes the device a lot less responsive so it's best to turn it off.
-
Page 5: Included In The Box / Mouse Instruction
INCLUDED IN THE BOX RapidScreen PLUS v3 Kiosk Modular pole stand Power cable Power extension cable Data extension cable Data end cable Pole top cap Attachable camera hood Sensor cover plate Floor base plate Large pole stand nut This device does have a... -
Page 6: Existing / Closing The Application
EXITING THE APPLICATION By default the device auto launches into our scanning app called Face Recognition. To leave our app and return to the Android home-screen you need to do a long press & hold at the top left of the screen or Right click the mouse button and enter the password (default 123456) Select Software Settings at the top tab Select Exit, confirm and you will have closed the application. -
Page 7: Connecting To Wifi
CONNECTING TO WIFI After exiting the application (page 4), on the android main screen click on the settings icon on the screen. This will bring up the android settings for the device. At the top, click on the WiFi button. Select your WiFi network and enter the password when prompted. -
Page 8: Changing The Time Zone
CHANGING THE TIME ZONE Exit the application (page 4) Click on the settings icon and scroll down to find Date & Time After clicking Date & Time another menu will appear. Turn off the Automatic time zone setting if not already done, then towards the bottom click on Select Time Zone. Pick the appropriate location for your time zone and select it. -
Page 9: Volume & Brightness Controls
VOLUME AND BRIGHTNESS CONTROLS ● Screen Brightness – Adjust the screen brightness of the kiosk. Click on the Red Dot and drag to your desired brightness setting. ● Volume Settings – Adjust the Volume setting of the kiosk. Click on the Red Dot and drag to your desired Volume level. -
Page 10: User Manual Notes
User Manual Notes For more information on the advanced features of the device and also just documentation on the details of various menu options, please refer to the User Manual: While it is good to read through these sections to get a better understanding of how the device works, it is not necessary unless you run into any issues and want to troubleshoot them. - Page 11 If you purchased the premium cloud service option for your device then please contact support@spintouch.com and we will get your account created for you.
