1. Operation manual In addition to these assembly instructions, the current version of the Operating instructions for the device is available at www.my-pv.com. Wiring diagrams at the end of the document. The following device key is required for online registration of the unit.
2. Intended use The electronic AC•THOR®9s Photovoltaic-Power-Manager (in the following, AC•THOR®9s for short) is designed for operating resistive loads such as electric immersion heater elements, electric boilers, electric convectors, electric heating mats or infrared panels. The unit controls the output voltage according to external signals (temperatures, Ethernet- and other control signals) linearly and thus the power output of the connected load.
Page 6
AC•THOR®9s Assembly Instructions, Version 200910...
3. Scope of supply • AC•THOR®9s Electronic Photovoltaic Power Manager • Wall bracket (on the rear of the unit) • Assembly set (3 screws 4.2 x 32 mm, 3 wall-plugs 6 mm) my-PV digital temperature sensor (cable length 5 m) with 8-pin •...
4. Safety instructions • Installation must be carried out by a licensed electrician in accordance with AS/NZS 3000. For water heating applications compliance with AS/NZS 3500 is • required. • Do not open the AC•THOR®9s. The device does not contain any parts that may be repaired by the user.
Do not install the device in an environment contaminated with • ammonia. Do not install the device in a dusty environment. • The ventilation holes of the housing must not be covered. • Avoid exposure to high temperatures (> 40 °C), low temperatures •...
6. Mounting 1. Remove the wall bracket from the rear of the AC•THOR®9s unit. To do this, slide the lock underneath to the right. 2. Then fix the wall bracket to the wall with three screws. Three screws and three wall-plugs are supplied. If the screws supplied are not suitable for the substrate, suitable screw must be obtained.
Page 11
5. When installing in an electrical cabinet, ensure sufficient cooling, for example through ventilation slots in the switch cabinet door. 6. A minimum lateral distance of 7cm must be observed. 7. When installing several devices side by side, a minimum distance of 10cm must be maintained 8.
7. Electrical connection The AC•THOR®9s is controlled by external signal sources by way of IP protocol using a standard Ethernet RJ45 cable. Protection of the mains connection for the AC•THOR®9s may not exceed 16 A per phase (tripping characteristic B or C). The PE conductor and the neutral conductor must be connected! Pay attention to other loads on the line circuit, this may trip the circuit breaker!
7.1. Operation on one or two phases The device is also suitable for operation on one or two phases. Phase L1 must be connected (power supply). In order to guarantee a perfect control function, outputs whose corresponding phase is not supplied on the input side must not be connected! L1 IN →...
8. Operation displays The unit has a touch screen to show operating conditions and for ease of operation. Never touch the screen with pointed objects or those having sharp edges! Use the supplied stylus for programming. The holder for the stylus can be stuck on to a surface on or close to the unit with the adhesive patch.
In a polluted environment, the air inlets and outlets should be checked regularly for cleanliness. If necessary, the device can be cleaned through the air slots with a vacuum cleaner. The AC•THOR®9s cannot work at maximum efficiency if the air supply is inadequate! 10.
This warranty covers any defects in materials for a period of 2 years from date of purchase when the product is installed and operated according to the written installation instructions. Energy Smart Water will repair or replace the covered product or any part or component that is defective in materials or workmanship subject to the terms within this document.
Where the product is installed outside the boundaries of a metropolitan area, the cost of travelling to the installed site shall be the owner’s responsibility. 12.3. Warranty Exclusions Where the product has not been installed and operated in • accordance with the instructions in this manual. •...
As soon as reasonably practicable you must contact Energy Smart Water on 1800 433 254 or email techsupport@esw.net.au and advise of the fault or issue. Energy Smart Water will arrange for the product tested and assessed on-site. If Energy Smart Water determines that you have a valid warranty claim, the unit will be repaired or replaced in accordance with this warranty.
13. EU declaration of conformity my-PV GmbH, Teichstraße 43, 4523 Neuzeug, Germany hereby declares that the products of the product AC•THOR®9s comply with the following Directives and standards: EN 55014-1, EN 55014-2, EN 60730-1, EN 62233, EN 61000-3-2, EN 61000-3-3 The company named above holds available for inspection documentation as proof of fulfilment of the safety objectives and the principal safety requirements.
14. Technical specifications my-PV AC•THOR®9s (Subject to change without notice) Mains voltage 3 x 230 V, 45-65 Hz Outputs OUT-1 0 to 230 V pure sine 0 to 3,000 W max. NOT switchable OUT-2 0 to 230 V pure sine 0 to 3,000 W max.
Page 21
Protection IP20 Protection class Temperature sensor my-PV digital temperature sensor (5 m) Display Colour graphic, touch screen 2.83“ Warranty 2 Years (extended warranty upon request) Weight (without wall 1.3 kg bracket) Dimension (W x H x D) 135 x 195 x 65 mm Interfaces Ethernet RJ45, RS485, potential-free input, PWM out, PWM in...
16. Installation Details / Product Registration Name of licenced electrician: ……………………………………………………………. Company Name: ……………………………………………………………………………….. Electrical license number: …………………………………………………………………. Date of installation: …………………………………………………………………………… Signature of installer: ………………………………………………………………………… Certificate of Electrical Safety (COES): ………………………………………………. Visit Energy Smart Water to register your product www.esw.net.au Notes: AC•THOR®9s Assembly Instructions, Version 200910...
